Поз.
Артикул
Описание
10
OUTLET WATER PUMP
10
OUTLET WATER PUMP
25
OUTLET , 401-403,421-423,441-443547323 404,424,444011529 FROM ENGINE SEE SPECIAL VERSION 018473 OR 018650
25
OUTLET , Replaced By: A4232010431
25
OUTLET , EXHAUST STOCK OF OLD PARTS UP TO ENGINE 891911, Replaced By: A4412000056
25
OUTLET , 401-403,421-423,441-443547323 404,424,444011529 FROM ENGINE SEE SPECIAL VERSION 018473 OR 018650
25
PIPE SOCKET
30
PIPE SOCKET WATER PUMP
30
OUTLET
40
OUTLET FROM ENGINE TO CONNECTION HOSE, FEED,003426
40
LINE COOLING WATER INLET
40
PIPE SOCKET HEATING FEED
40
PIPE SOCKET WATER PUMP
40
PIPE SOCKET , EXHAUST STOCK OF OLD PARTS UP TO ENGINE 061568, Replaced By: A4472000356
42
SCREW PLUG , Replaced By: N000908014009
42
SCREW PLUGTO 000 553 03 05,000 553 18 05,
43
SEAL RINGTO 000 553 03 05,000 553 18 05,
50
INTAKE PIPE SOCKET COOLING WATER INLET
50
LINE COOLING WATER LINE TO WATER PUMP
50
INTAKE PIPE SOCKET WATER PUMP
50
INTAKE PIPE SOCKET WATER PUMP
50
INTAKE PIPE SOCKET COOLING WATER INLET
50
PIPE SOCKET , Replaced By: A4272030230
50
PIPE SOCKET , THIS NOTE OF REPLACEMENT APPLIES ONLY TO THE ITEM LISTED OPPOSITE, Replaced By: A4072000259
60
PIPE SOCKET COOLING WATER INLET
65
INTAKE PIPE SOCKET RETURN LINE TO ENGINE
65
INTAKE PIPE SOCKET , Replaced By: A4032011930
70
THREADED INSERT
75
CONNECTOR AT COOLING WATER OUTLET
75
FITTING SCREW FITTING TO COOLING WATER INTAKE PIPE SOCKET
75
FITTING WATER PUMP
75
FITTING COOLING WATER OUTLET
80
SEAL RINGTO 376 131 74 01
80
SEAL RING OIL DRAIN 30X36 MM
80
SEAL RING FROM FUEL TANK TO FUEL TANK
90
LOCKING CAP TO LOCK COOLING WATER BOTTOM OUTLET
90
DUST CAP , THIS NOTE OF REPLACEMENT APPLIES ONLY TO THE ITEM LISTED OPPOSITE, Replaced By: A4212010008
90
LOCKING CAP , Replaced By: A4229870245
90
LOCKING CAP
95
CLAMP INTERMEDIATE PIPE TO PARTICLE FILTER
110
SCREW PLUG OIL DRAIN
115
SEAL RING
120
SCREW PLUG AT TANK
120
SCREW PLUGTO 000 553 03 05,000 553 18 05,
120
SCREW PLUG FUEL TANK
120
SCREW PLUG , Replaced By: N007604014110
120
SCREW PLUG , Replaced By: N000908014009
125
SEAL RINGTO 000 553 03 05,000 553 18 05,
125
SEAL RING LINE CONNECTION
125
SEAL RING INJECTION PUMP
125
SEAL RING FILTER BOWL TO FILTER HEAD
130
SCREW PLUG, FILLING HOUSING,BOTTOM M18X1.5
130
SCREW PLUG BELL HOUSING
130
SCREW PLUG HOUSING,BOTTOM, Replaced By: N000908018011
135
SEAL RING VALVE TO VALVE,K 025179
140
SCREW OUTLET TO WATER PUMP M 8X140
140
SCREW OIL FILTER TO CYLINDER CRANKCASE
140
HEXAGON HEAD BOLT. SCREW CLUTCH SLAVE CYLINDER TO BELL HOUSING
140
SCREW EXHAUST PIPE TO MUFFLER AND TO HEATER UNIT M 8X55
140
SPRING WASHER PROTECTIVE PLATE TO EXHAUST MUFFLER
140
SCREW OUTLET TO WATER PUMP M 8X70
140
SCREW OUTLET TO WATER PUMP M 8X70
140
SCREW CONTROL VALVE
140
SCREW
140
SCREW GRIP RAIL MOUNTING M 8 X 25
140
HEXAGON HEAD BOLT BRACKET TO BRACKET M8X25
140
SCREW DISTRIBUTOR TO FRAME SIDE MEMBER
140
SCREW
140
HEXAGON HEAD BOLT RESONATOR TO TRANSMISSION CASE,K 138633
140
HEXALOBULAR BOLT. SCREW SUPPORT TO CYLINDER HEAD
140
SCREW. CAP BOLT SEAT MOUNTING M8X35
140
HEXAGON HEAD BOLT. SCREW BRACKET TO SIDE MEMBER M10X25
140
SCREW VALVE TO BRACKET
140
HEXAGON HEAD BOLT. SCREW ON STOP M 8X50
140
SCREW BRACKET TO RIGHT SIDE MEMBER,5 434014
140
SCREW BRACKET TO INTAKE MANIFOLD M 8X135
140
SCREW BRACKET TO SIDE MEMBER
140
HEXAGON HEAD BOLT. SCREW CLUTCH PRESSURE PLATE TO FLYWHEEL M 8X1,25X60
140
SCREW BEARING BRACKET TO TRANSMISSION M 8X47,556500
140
HEXAGON HEAD BOLT. SCREW CABLE HARNESS TO BRACKET M8X40
140
HEXAGON HEAD BOLT. SCREW CLUTCH TO FLYWHEEL
140
SCREW , Replaced By: N304014008002
140
SCREW , Replaced By: N304017008040
140
SCREW , Replaced By: N304017008034
140
SCREW , Replaced By: N304017008053
140
SCREW , Replaced By: N304017008067
140
SCREW , Replaced By: N000000000190
140
SCREW , Replaced By: N000912008204
140
SPRING WASHER , Replaced By: N000137008212
145
COMBINATION BOLT , Replaced By: N304017008029
145
HEXAGON HEAD BOLT. SCREW , Replaced By: N910143008016
145
SCREW , Replaced By: N304017010053
145
SCREW BRACKET TO SIDE MEMBER
145
SCREW SUPPORT TO FENDER
145
SCREW , Replaced By: N304017010002
145
SCREW , Replaced By: N304017010030
145
SCREW , Replaced By: N304017008034
145
SCREW , Replaced By: N304017008018
145
SCREW , Replaced By: N304017008021
145
SCREW , Replaced By: N304017010030
145
SCREW , Replaced By: N304014008007
145
SPRING WASHER , Replaced By: N000137008212
145
SCREW , THIS NOTE OF REPLACEMENT APPLIES ONLY TO THE ITEM LISTED OPPOSITE, Replaced By: N914126010005
145
SCREW REAR EXHAUST PIPE TO BRACKET M 10X80
145
SCREW INTERMEDIATE FLANGE TO TRANSMISSION CASE
145
HEXAGON HEAD BOLT BRACKET TO NO.1 CROSS MEMBER M8X35
145
SCREW BRACKET TO TRANSMISSION,4 411810
145
SCREW FRONT AXLE REGULATING SOLENOID VALVE
145
HEXAGON HEAD BOLT. SCREW BRACKET TO SIDE MEMBER M10X25
145
HEXAGON HEAD BOLT RESONATOR TO TRANSMISSION CASE,K 138633
145
SCREW , Replaced By: N910105010017
145
LOCK WASHER CLAMP TO BRACKET AND TO PIPE
145
SCREW CLAMP ON BRACKET
145
HEXAGON HEAD BOLT CLAMP AT SUPPORTING RAIL M 8X30
145
HEXAGON HEAD BOLT BRACKET TO DISTRIBUTOR
145
HEXAGON HEAD BOLT BRACKET TO BRACKET M8X25
145
HEXAGON HEAD BOLT BRACKET TO BRACKET M10X35
145
HEXAGON HEAD BOLT. SCREW BRACKET TO TRANSMISSION M 10X50
145
SCREW PIPE CLAMP
145
SCREW , Replaced By: N000931010462
145
SCREW INTAKE PIPE SOCKET TO WATER PUMP
145
HEXAGON HEAD BOLT. SCREW CLUTCH SLAVE CYLINDER TO BELL HOUSING
145
SPRING WASHER PROTECTIVE PLATE TO EXHAUST MUFFLER
145
HEXAGON HEAD BOLT. SCREW TRAILER COUPLING TO BRACKET M10 X 120
145
SCREW BRACKET TO SIDE MEMBER M10X35
145
SPRING WASHER STEERING COLUMN BRACKET TO CAB
145
HEXALOBULAR BOLT BRACKET TO SUPPORT M8X80
145
SCREW INTAKE PIPE SOCKET TO WATER PUMP M 10X35
150
SPRING WASHER STEERING SHAFT BEARING TO CAB
150
SPRING WASHER STEERING COLUMN BRACKET TO CAB
150
WASHER STRUT TO CROSS MEMBER
150
SPRING WASHER PROTECTIVE PLATE TO EXHAUST MUFFLER
150
SPRING WASHER , Replaced By: N000137008212
155
SPRING WASHER , Replaced By: N000137008212
155
SPRING WASHER PROTECTIVE PLATE TO EXHAUST MUFFLER
155
LOCK WASHER CLAMP TO BRACKET AND TO PIPE
170
FLANGE COOLING WATER OUTLET
175
GASKET
175
GASKET FLANGE TO PUMP
180
GASKET COOLING WATER INTAKE PIPE SOCKET
180
GASKET , Replaced By: A4442010080
185
GASKET CONNECTOR, Replaced By: A0002011080
185
GASKET , Replaced By: A4422010480
185
GASKET CONNECTOR, Replaced By: A0002011280
185
GASKET CONNECTOR, Replaced By: A0002011180
185
GASKET CONNECTOR
195
GASKET FLANGE TO PUMP
195
GASKET , Replaced By: A4422010280
200
FLANGE TO LOCK COOLING WATER CONNECTION
200
FLANGE TO LOCK COOLING WATER CONNECTION
200
FLANGE HEATING CONNECTION LOCK
200
FLANGE WATER DRAIN
205
GASKET. SEAL DE-AERATION PIPE TO ENGINE
205
GASKET TO LOCK COOLING WATER CONNECTION
205
GASKET
205
GASKET HEATING PIPE TO ENGINE
205
GASKET , Replaced By: A4440720180
210
SCREW , Replaced By: N304017008016
210
SCREW , Replaced By: N304017008034
210
SCREW , Replaced By: N304017006018
210
SCREW OIL-DIPSTICK GUIDE TUBE TO BRACKET
210
HEXAGON HEAD BOLT BRACKET TO BRACKET M8X25
210
SCREW BRACKET TO CROSS CONNECTION STRUT
210
SCREW COVER PLATE TO COVER PLATE M 6 X 12
290
BRACKET AT FITTING
290
BRACKET OUTLET
295
WASHER FRONT AXLE, NOT USED
295
SPACER TUBE AT FITTING
305
HEXAGON HEAD BOLT BRACKET TO DISTRIBUTOR
305
HEXAGON HEAD BOLT RESONATOR TO TRANSMISSION CASE,K 138633
305
SCREW BRACKET TO SIDE MEMBER
305
SCREW , Replaced By: N304017010002
310
HEXAGON HEAD BOLT BRACKET TO BRACKET
310
SCREW BEARING BRACKET TO FRONT AXLE M 10X40
320
NUT GUSSET PLATES AND REAR CROSS MEMBER TO SIDE MEMBERS
320
NUT
325
WASHER STRUT TO CROSS MEMBER
325
WASHER RADIATOR TO RUBBER MOUNTING
335
SPRING WASHER STEERING COLUMN BRACKET TO CAB
999
SCREW GUSSET PLATES AND REAR CROSS MEMBER TO SIDE MEMBERS
999
FLANGE COOLING WATER FEED LINE LOCK
999
BRACKET , THE OLD PART MUST NO LONGER BE INSTALLED, Replaced By: A4422001240
999
BRACKET
999
INTAKE PIPE SOCKET WATER PUMP
999
INTAKE PIPE SOCKET WATER PUMP
999
OUTLET
999
OUTLET
999
OUTLET
999
BRACKET RIGHT,795970
999
BRACKET RIGHT
999
FLANGE COOLING WATER LINE
999
SCREW , Replaced By: A0009903204
999
SCREW , Replaced By: N304017010002
999
SCREW BRACKET TO SIDE MEMBER
999
THREADED INSERT
