Поз.
Артикул
Описание
10
SHAFT HYDRAULIC PUMP
10
SHAFT HYDRAULIC PUMP
10
SHAFT HYDRAULIC PUMP
10
SHAFT HYDRAULIC PUMP
10
SHAFT , Replaced By: A4042360215
15
GEAR , EXHAUST STOCK OF OLD PARTS UP TO ENGINE 969083, Replaced By: A4421300530
15
GEAR AIR COMPRESSOR DRIVE
20
SCREW DRIVE GEAR TO CRANKSHAFT
25
FLANGE
25
FLANGE AIR COMPRESSOR,424.900-000-012333
25
FLANGE , Replaced By: A4071300445
30
BUSHING LONG 19 MM, 003192
30
BUSHING , Replaced By: A0001314250
30
BUSHING
35
FLANGE HYDRAULIC PUMP
40
SEAL RING
40
SEAL RINGTO 000 460 23 80
45
SEAL RING , Replaced By: A0149976148
45
SEAL RINGTO 388 476 71 69
50
CAP TO PLUG AIR COMPRESSOR,REAR
55
GASKET COVER TO TIMING CASE, Replaced By: A0259976947
55
GASKET , Replaced By: A3661310080
55
FLANGE GASKET COVER TO TIMING CASE
60
HEXAGON HEAD BOLT BRACKET MOUNTING M10X100
60
SCREW , Replaced By: N304017010047
60
SCREW BRACKET TO SIDE MEMBER M10X35
60
HEXAGON HEAD BOLT BRACKET TO BRACKET M10X35
65
LOCK WASHER BRACKET TO SUPPORT AND TO END PIECE
67
HEXAGON HEAD BOLT AUTOMATIC TRANSMISSION AT ENGINE M10X60
70
BUSHING AIR COMPRESSOR BEARING
70
BUSHING , EXHAUST STOCK OF OLD PARTS UP TO ENGINE 114468, Replaced By: A4030150950
75
GROOVED BALL BEARING , Replaced By: A0079813001
75
CYLINDR. ROLLER BEARING AIR COMPRESSOR BEARING
80
FLANGE
90
SCREW , 000825
95
SCREW VIBRATION ABSORBER TO SHIFTING ROD, 10/20 6 901446 50/60 5 529480
100
SPRING WASHER PROTECTIVE PLATE TO EXHAUST MUFFLER
100
SPRING WASHER , Replaced By: N000137008212
999
SLEEVETO 007 981 30 01
999
SELF-ALGN.ROLLER BEARING , Replaced By: A0009810535
999
SELF-ALGN.ROLLER BEARING DRIVE GEAR TO CRANKSHAFT
999
SEAL RING POWER STEERING PUMP
999
CAP , Replaced By: A4031310821
999
GASKET , Replaced By: A4031310480
999
FLANGE , Replaced By: A4031300845
999
FLANGE , Replaced By: A4031301045
999
DRIVE GEAR , Replaced By: A4031300030
999
SHAFT , THE OLD PART MUST NO LONGER BE INSTALLED, Replaced By: A4042360115
999
FLANGE , THE OLD PART MUST NO LONGER BE INSTALLED, Replaced By: A4042360145
999
GEAR DRIVE GEAR ON CAMSHAFT
999
FLANGE , Replaced By: A4221300045
999
GASKET
999
CAP
999
DRIVE GEAR , Replaced By: A4071300030
999
EXPANSION PLUG
999
GASKET , Replaced By: A4421312080
999
FLANGE
999
CAP COVER TO AIR COMPRESSOR HOUSING
999
GASKET COVER TO AIR COMPRESSOR HOUSING
999
GASKET INTERMEDIATE FLANGE
999
FLANGE INTERMEDIATE FLANGE
999
FLANGE HYDRAULIC PUMP
999
SCREW PIPE ELBOW TO CHARGING AIR INTERCOOLER M 10X35,5 708090
999
SCREW BRACKET TO ENGINE
999
SCREW , Replaced By: N304017008030
999
SCREW , Replaced By: N304017010047
999
SCREW PILLAR TO BRACKET AND TO FRONT PANEL
999
SCREW CONNECTOR TO REAR SHIFTING ROD
999
NUT FROM CONTROL LEVER TO INTERMEDIATE SHAFT AT ENGINE
