Поз.
Артикул
Описание
38
ROD
98
SHAFT
101
SCREW DISTRIBUTOR TO CAB
104
WASHER , Replaced By: N009021006208
104
WASHER COMPRESSED AIR LINE TO BRACKET
107
TOOTHED WASHER
110
NUT BALL PIVOT TO LEVER
113
THREADED PIN ROD TO ADJUSTING LINK
116
ANGLE JOINT ROD TO LEVER
119
TOOTHED WASHER BACK-UP LAMP TO BRACKET
122
NUT TACHOGRAPH TO BRACKET
125
BEARING BRACKET
128
DOWEL PIN
131
SCREW , Replaced By: N304017006026
131
SCREW , Replaced By: N304017006026
134
TOOTHED WASHER
137
WASHER , Replaced By: N009021006208
137
WASHER COMPRESSED AIR LINE TO BRACKET
168
BRACKET
171
WASHER
174
SCREW CAB FLOOR COVERING M 6X25
177
TOOTHED WASHER
180
NUT BALL PIVOT TO LEVER
183
ACCELERATOR PEDAL
186
PAD
189
SCREW
999
SPRING
999
ROD
999
HEADLESS SETSCREWM 5X6
