Поз.
Артикул
Описание
9
BRACKET , EXHAUST STOCK OF OLD PARTS UP TO ENGINE 616806, Replaced By: A4420700140
9
BRACKET INTERMEDIATE AXLE
13
SCREW CLUTCH LINE TO FLYWHEEL HOUSING M16 X 30
13
SCREW BRACKET TO ENGINE
15
LOCK WASHERROCKINGER TYP 59 G140,59 G150
19
LEVER (DOUBLE LEVER), FROM ENGINE 616807,ALSO INSTALLED ON 616100
19
LEVER (DOUBLE LEVER)
19
LEVER , Replaced By: A4030700522
19
LEVER , UP TO ENGINE 616806 EXCEPT FOR 616100, Replaced By: A4420700122, +001A4420700140
19
LEVER , Replaced By: A4030700422
21
BUSHING , Replaced By: A4039920001
21
BUSHING MOUNTING
22
GREASE NIPPLE
25
BALL STUD. BALL PIVOT TOP B10X4,5 MM
25
BALL PIVOT LEVER
25
BALL PIVOT , Replaced By: A3129910120
29
WASHER
29
WASHER BEARING BRACKET TO BRACKET
35
LOCK RINGTO 000 553 37 01,000 553 39 01,
35
LOCK RING SHOCK ABSORBER TO BRACKET,1D 006005
36
PULL ROD LOAD SENSOR CONTROL, TO BE ADAPTED DURING ASSEMBLY
36
PULL ROD FROM REAR CONTROL LEVER TO CONTROL SHAFT 600 MM, TO BE ADAPTED DURING ASSEMBLY
36
PULL ROD FROM CONTROL SHAFT BEARING TO INTERMEDIATE LEVER 400 MM, TO BE ADAPTED DURING ASSEMBLY
36
PULL ROD AT CONTROL LEVER, TO BE ADAPTED DURING ASSEMBLY
36
PULL ROD325 MM
39
BALL SOCKET PULL ROD TO INTERMEDIATE LEVER
39
BALL SOCKET PULL ROD TO LEVER
39
BALL SOCKET ACCELERATOR CONTROL
42
CIRCLIP. SECURING CLIP BALL SOCKET TO ROD
45
NUT BALL PIVOT TO LEVER
45
NUT SPRING-LOADED PUSH ROD
45
NUT L.H. THREAD
73
SHAFT
73
SHAFT (INTERMEDIATE SHAFT), 401.901-50401.05.96 441.901-504884025
73
SHAFT , EXHAUST STOCK OF OLD PARTS UP TO ENGINE 616806, Replaced By: A4420700123
73
SHAFT INTERMEDIATE CONTROL SHAFT
73
SHAFT
77
BALL PIVOT
77
BALL STUD. BALL PIVOT TOP B10X4,5 MM
77
BALL PIVOT
77
BALL PIVOT LEVER
77
BALL PIVOT , Replaced By: A3129910120
82
BEARING BRACKET , UP TO ENGINE 616806 EXCEPT FOR 616100, Replaced By: A4420700124, +001A4420700123
82
BEARING BRACKET , FROM ENGINE 616807,ALSO INSTALLED ON 616100
92
BUSHING MOUNTING
94
GREASE NIPPLE
100
SCREW CLAMP TO CONNECTING PIPE AND TO EXHAUST HOSE M 8X30
100
SCREW STOP TO BATTERY CASE
100
SCREW , Replaced By: N304017008027
102
SPRING WASHER , Replaced By: N000137008212
102
SPRING WASHER PROTECTIVE PLATE TO EXHAUST MUFFLER
116
LEVER
116
LEVER (LOCKING LEVER)
120
BUSHING MOUNTING
126
BALL PIVOT
136
LEVER ,253412
136
LEVER ,253411
144
BALL PIVOT LEVER
144
BALL PIVOT
144
BALL PIVOT , Replaced By: A3129910120
149
SCREW , Replaced By: N000000001479
149
HEXALOBULAR BOLT. SCREW LINE MOUNTING M 6X30
154
NUT BALL PIVOT TO LEVER
154
NUT SPRING-LOADED PUSH ROD
159
SPRING RELEASE SPRING, UP TO CHASSIS 556499 EXCEPT FOR 553795,555902,556120
315
CYLINDER INCREASE IN NUMBER OF REVOLUTIONS KNORR
315
WORKING CYLINDER (POWER CYLINDER),EXHAUST BRAKE
315
CYLINDER SHUT-OFF CYLINDER
315
CYLINDER , Replaced By: A0004301926
315
CYLINDER , Replaced By: A0004302726, +001A4039910222
315
CYLINDER , Replaced By: A0004301826, +001A4039910222
315
CYLINDER , Replaced By: A0004303026
315
CYLINDER
315
CYLINDER , Replaced By: A0004304926
315
CYLINDER (POWER CYLINDER),EXHAUST BRAKE, Replaced By: A0004307926
315
CYLINDER , Replaced By: A0004305926
315
CYLINDER INTERMEDIATE SPEED STOP
339
REPAIR KIT POWER CYLINDER TO 000 430 60 26
339
REPAIR KIT SHIFTING CYLINDER TO KNORR, SZ 1130 I/74963,000 430 3026
339
REPAIR KIT
339
REPAIR KIT , Replaced By: A0024300060
339
REPAIR KIT
339
REPAIR KIT POWER CYLINDER
339
REPAIR KITTO 000 430 48 26,KNORR
345
BALL SOCKET
345
BALL SOCKET ROD TO BALL PIVOT
345
BALL SOCKET , Replaced By: A4039910222
351
SECURING CLIP. CIRCLIP
357
NUT STEP TO APPARATUS SUPPORT
357
NUT , Replaced By: N304035008001
357
NUT
358
SPACER WASHER SHIFTING CYLINDER TO SHIFT LEVER
359
BOOT (POWER CYLINDER),EXHAUST BRAKE
367
PIN POWER CYLINDER TO BRACKET TO 000 430 48 26,49 26
367
PIN ,006476, Replaced By: A4031440674, +001N007349008002
367
PIN , Replaced By: A4221440174, +001N999900008004
367
PIN , Replaced By: A4421440574
367
PIN CYLINDER TO BRACKET
369
LOCK WASHER CLAMP TO BRACKET AND TO PIPE
371
NUT POWER CYLINDER TO BRACKET
371
NUT
371
NUT , Replaced By: N304032008006
371
NUT POWER CYLINDER TO BRACKET
375
WASHER , Replaced By: N000125008443
375
WASHER INTERMEDIATE SPEED STOP
375
WASHER EXHAUST MUFFLER TO STRAP
375
WASHER
381
COTTER PIN CYLINDER TO BRACKET
381
COTTER PIN STRAP TO CONSOLE
381
COTTER PIN LEVER TO ROD
381
COTTER PIN LEVER TO ROD, Replaced By: N000094002060
429
LEVER , Replaced By: A4410700321
429
LEVER , Replaced By: A4410700621
429
LEVER , EXHAUST STOCK OF OLD PARTS UP TO ENGINE 671974, Replaced By: A4420703021
429
LEVER LOAD CONTROL, TO BE ADAPTED DURING ASSEMBLY
429
LEVER
435
BALL PIVOT LEVER
435
BALL PIVOT
435
BALL PIVOT , Replaced By: A3129910120
450
SEAL RING MODULATION PRESSURE CONTROL
456
NUT , Replaced By: N913004006001
456
NUT PUMP TO BRACKET
462
HEXAGON HEAD BOLT
462
SCREW , Replaced By: N910105006002
505
ROD (PUSH ROD),SPRING-LOADED
505
ROD (PUSH ROD),SPRING-LOADED
510
ROD (PUSH ROD),SPRING-LOADED
510
ROD
510
ROD
510
ROD
510
ROD
520
ROD , Replaced By: A6583001715
520
ROD FROM ACCELERATOR PEDAL TO CONTROL SHAFT BEARING
525
BALL SOCKET PULL ROD TO INTERMEDIATE LEVER
530
CIRCLIP. SECURING CLIP BALL SOCKET TO ROD
535
THREADED UNION
535
TURNBUCKLE TURNBUCKLE
540
NUT BALL PIVOT TO LEVER
545
NUT L.H. THREAD
999
CYLINDER , Replaced By: A0000702183
999
CYLINDER , Replaced By: A0000702183
999
REPAIR KITTO 000 070 17 83
999
BUFFER BUFFER TO SUPPORT
999
HOLLOW SCREW FOR HORIZONTAL MOUNTING OF HAND PUMP TO FEED PUMP
999
RUBBER BUFFER BUFFER TO SUPPORT
999
FITTING
999
BALL PIVOT INJECTION PUMP
999
BEARING BRACKET
999
LEVER (CONTROL LEVER),INJECTION PUMP
999
ROD (PUSH ROD)
999
LEVER
999
BRACKET COMPRESSED AIR CYLINDER
999
LEVER
999
PIVOT PIN
999
SPACER TUBE CONTROL
999
BUSHING
999
BRACKET FINAL CONTROL ELEMENT
999
SCREENING PLATE
999
BEARING TUBE
999
SHIM
999
SHAFT
999
LEVER
999
LEVER
999
BEARING BRACKET
999
THREADED UNION , Replaced By: A4470720082
999
BEARING BRACKET
999
BRACKET
999
DIAL
999
PIN (INTERMEDIATE SHAFT)
999
BEARING BRACKET
999
BEARING TUBE
999
LEVER (CONTROL LEVER),INJECTION PUMP
999
LEVER (CONTROL LEVER),INJECTION PUMP
999
BRACKET BRACKET TO TIMING CASE COVER
999
BRACKET BRACKET TO INJECTION PUMP
999
SPRING
999
SHAFT (INTERMEDIATE SHAFT)
999
BRACKET INTERMEDIATE AXLE
999
BEARING TUBE
999
LEVER FINAL CONTROL ELEMENT
999
CAP TO PLUG AIR COMPRESSOR OPENING,128243
999
ROD ACCELERATOR PEDAL TO LEVER
999
THREADED UNION OPERATING ROD
999
WASHER , Replaced By: N000125008443
999
NUT , Replaced By: N304035008001
999
SCREW , Replaced By: N304017006012
999
SCREW BRACKET TO SIDE MEMBER
999
SCREW , Replaced By: N304017010028
999
NUT L.H. THREAD
999
NUT , Replaced By: N304032008006
999
SEALING RING. SEAL RING DELIVERY LINE TO STEERING
999
BALL PIVOT , Replaced By: A3129910120
999
HEXAGON HEAD BOLT RUBBER MOUNTING TO SIDE MEMBER AND TO SUPPORT M10X20
999
PULL ROD FROM ACCELERATOR PEDAL TO CONTROL SHAFT BEARING, TO BE ADAPTED DURING ASSEMBLY
999
PULL ROD BRAKE POWER REGULATOR CONTROL, TO BE ADAPTED DURING ASSEMBLY
999
PULL ROD SHIFTING ROD
999
PULL ROD FROM CONTROL SHAFT BEARING TO ENGINE SHAFT, TO BE ADAPTED DURING ASSEMBLY
999
NUT HEATING PIPE TO BRACKET
999
LOCK WASHER CONTROL LEVER TO INJECTION PUMP LEVER
