Поз.
Артикул
Описание
12
SHAFT HYDRAULIC PUMP
12
SHAFT HYDRAULIC PUMP
12
SHAFT HYDRAULIC PUMP
16
DRIVE GEAR ON AIR COMPRESSOR CRANKSHAFT
16
DRIVE GEAR ON AIR COMPRESSOR CRANKSHAFT
16
DRIVE GEAR ON AIR COMPRESSOR CRANKSHAFT
17
SPACER TUBE
18
CYLINDR. ROLLER BEARING AIR COMPRESSOR BEARING
18
SELF-ALGN.ROLLER BEARING DRIVE GEAR TO CRANKSHAFT
18
SELF-ALGN.ROLLER BEARING , Replaced By: A0009810535
18
CYLINDR. ROLLER BEARING , Replaced By: A0079813001
22
SCREW DRIVE GEAR TO CRANKSHAFT
28
FLANGE POWER STEERING PUMP
28
FLANGE , Replaced By: A4221300145
30
BUSHING , Replaced By: A0001314250
30
BUSHING LONG 19 MM, 003192
30
BUSHING
48
SCREW INTERMEDIATE GEAR
48
SCREW , Replaced By: N910105010017
48
SCREW , Replaced By: N007984010038
110
HOUSING , Replaced By: A4471310215, +001A4471310121, +001A4471310280, +002N000931008210
110
HOUSING , Replaced By: A4071300610
110
HOUSING
120
THREADED INSERT
130
THREADED INSERT ,5 462573
140
LOCK BEARING FLANGE IN TIMING CASE & AIR COMPRESSOR HOUSING,RESP.
150
CAP TO PLUG AIR COMPRESSOR OPENING,128243
150
CAP , Replaced By: A4031311021
150
CAP , Replaced By: A4421310021
160
GASKET , Replaced By: A4421310080
160
GASKET
160
GASKET , THE OLD PART MUST NO LONGER BE INSTALLED, Replaced By: A4421312080
160
GASKET TO PLUG AIR COMPRESSOR CONNECTION ON CYLINDER CRANKCASE
160
GASKET OIL FILTER TO CYLINDER CRANKCASE
160
GASKET OIL FILTER TO CYLINDER CRANKCASE
170
HEXAGON HEAD BOLT. SCREW COMPRESSED AIR LINE TO LEFT SIDE MEMBER
170
HEXAGON HEAD BOLT CLAMP AT SUPPORTING RAIL M 8X30
180
SPRING WASHER , Replaced By: N000137008212
180
SPRING WASHER PROTECTIVE PLATE TO EXHAUST MUFFLER
190
CAP COVER TO AIR COMPRESSOR HOUSING,048083048474
200
SEAL RING COVER TO AIR COMPRESSOR HOUSING
210
SCREW BRACKET TO APPARATUS SUPPORT
220
SPRING WASHER PROTECTIVE PLATE TO EXHAUST MUFFLER
220
SPRING WASHER , Replaced By: N000137008212
230
GASKET , Replaced By: A4071310580
230
GASKET
240
HEXAGON HEAD BOLT BRACKET TO BRACKET M8X25
250
SCREW EXHAUST PIPE TO MUFFLER AND TO HEATER UNIT M 8X55
260
SCREW FAN TO CRANKSHAFT PULLEY
270
SPRING WASHER PROTECTIVE PLATE TO EXHAUST MUFFLER
270
SPRING WASHER , Replaced By: N000137008212
280
COUPLING
290
LOCK RING ,4 208907
300
FLANGE HYDRAULIC PUMP
310
SEAL RING BEARING FLANGE TO TIMING CASE AND TO AIR COMPRESSOR HOUSING,RESP.
320
HEXAGON HEAD BOLT. SCREW BRACKET TO SIDE MEMBER M10X25
330
SEAL RING BEARING FLANGE TO TIMING CASE AND TO AIR COMPRESSOR HOUSING,RESP.
340
CAP BEARING FLANGE TO TIMING CASE AND TO AIR COMPRESSOR HOUSING,RESP.
350
GASKET BEARING FLANGE TO TIMING CASE AND TO AIR COMPRESSOR HOUSING,RESP.
350
GASKET , Replaced By: A4471310180
360
SCREW STOP TO BATTERY CASE
999
SLEEVETO 007 981 30 01
999
SELF-ALGN.ROLLER BEARING , Replaced By: A0009810535
999
SEAL RING POWER STEERING PUMP
999
CAP , Replaced By: A4031310821
999
GASKET , Replaced By: A4031310480
999
FLANGE , Replaced By: A4031300845
999
FLANGE , Replaced By: A4031301045
999
FLANGE
999
DRIVE GEAR , Replaced By: A4031300030
999
SHAFT , THE OLD PART MUST NO LONGER BE INSTALLED, Replaced By: A4042360115
999
FLANGE , THE OLD PART MUST NO LONGER BE INSTALLED, Replaced By: A4042360145
999
GEAR DRIVE GEAR ON CAMSHAFT
999
FLANGE , Replaced By: A4221300045
999
GASKET
999
CAP
999
DRIVE GEAR , Replaced By: A4071300030
999
EXPANSION PLUG
999
GASKET , Replaced By: A4421312080
999
FLANGE
999
CAP COVER TO AIR COMPRESSOR HOUSING
999
GASKET COVER TO AIR COMPRESSOR HOUSING
999
GASKET INTERMEDIATE FLANGE
999
FLANGE INTERMEDIATE FLANGE
999
FLANGE HYDRAULIC PUMP
999
SCREW PIPE ELBOW TO CHARGING AIR INTERCOOLER M 10X35,5 708090
999
SCREW BRACKET TO ENGINE
999
SCREW , Replaced By: N304017008030
999
SCREW , Replaced By: N304017010047
999
SCREW PILLAR TO BRACKET AND TO FRONT PANEL
999
SCREW CONNECTOR TO REAR SHIFTING ROD
999
NUT FROM CONTROL LEVER TO INTERMEDIATE SHAFT AT ENGINE
