Поз.
Артикул
Описание
5
BREATHER LINE ENGINE BREATHING
8
LINE COOLING WATER LINE TO OIL COOLER, TO BE ORDERED ONLY FROM MTU-FRIEDRICHSHAFEN
14
FLANGE ENGINE BREATHING
14
FLANGE COOLING WATER FEED LINE LOCK
14
FLANGE ENGINE COOLING
14
FLANGE , Replaced By: A4419975165
14
FLANGE ENGINE BREATHING
17
FLANGE TO OIL COOLER
20
FLANGE COOLING WATER FEED LINE LOCK
23
FLANGE , Replaced By: A4419975165
23
FLANGE ENGINE BREATHING
23
FLANGE HEATING CONNECTION
23
FLANGE
26
FLANGE
29
FLANGE ENGINE BREATHING
32
PIPE SOCKET CYLINDER CRANKCASE
32
OUTLET , Replaced By: A4242000056, +001A3559970149, +001A4079975250, +002N000933010244, +002N912004010102
35
FLANGE ENGINE BREATHING
38
OUTLET ,000562
38
INTAKE PIPE SOCKET RETARDER
38
INTAKE PIPE SOCKET RETARDER
38
PIPE SOCKET RETARDER
41
PIPE SOCKET COOLING WATER LINE
41
PIPE SOCKET CYLINDER CRANKCASE
44
THREADED INSERT ,5 462573
47
DOUBLE FITTING HEATING CONNECTION
47
DOUBLE FITTING
47
FITTING HEATING CONNECTION
50
BRACKET OIL FILTER
53
CONNECTOR OIL COOLER HOUSING
53
CONNECTOR OIL COOLER HOUSING
56
CONNECTOR FROM ENGINE TO EXPANSION TANK
59
GASKET HEATING PIPE TO ENGINE
62
GASKET HEATING PIPE TO ENGINE
62
GASKET OUTLET TO ENGINE
62
GASKET. SEAL DE-AERATION PIPE TO ENGINE
62
GASKET FLANGE TO CYLINDER CRANKCASE
62
GASKET , Replaced By: A4412010080
62
GASKET , Replaced By: N917003040006
62
GASKET. SEAL , THE OLD PART MUST NO LONGER BE INSTALLED, Replaced By: A3559970149
65
HOLLOW SCREW
68
SEAL RING
71
BOLT. SCREW CONNECTOR TO CYLINDER CRANKCASE M10 X 105
71
SCREW SUPPORT TO FENDER
71
SCREW FLANGE TO CYLINDER CRANKCASE M10 X 22
71
SCREW BRACKET TO CROSS MEMBER
71
SCREW
71
HEXAGON HEAD BOLT BRACKET TO DISTRIBUTOR
71
SCREW BRACKET TO APPARATUS SUPPORT
71
SCREW ANGLE TO CROSS MEMBER M 10X30
71
SCREW AT FRAME
71
SCREW , Replaced By: N910105010017
71
SCREW , Replaced By: N000912010224
71
SCREW , Replaced By: N304017008018
71
SCREW , Replaced By: N304017010030
71
SCREW , Replaced By: N304017010051
71
HEXAGON HEAD BOLT. SCREW BRACKET TO TRANSMISSION M 10X50
71
SCREW
74
SPRING WASHER , Replaced By: N000137008212
74
SPRING WASHER PROTECTIVE PLATE TO EXHAUST MUFFLER
77
CONNECTOR
77
CONNECTOR PIPE SOCKET TO THERMOSTAT HOUSING
77
CONNECTOR , Replaced By: A6012030008
80
INTAKE PIPE FROM CYLINDER HEAD COVER TO AIR COMPRESSOR
83
CONNECTOR ENGINE BREATHING
83
SCREW FITTING
86
SEAL RING GEAR DISPLAY
86
SEAL RING VALVE TO VALVE,K 025179
86
SEAL RING SUPPORT TO CYLINDER CRANKCASE
89
LOCKING CONE
89
LOCKING CONE CONNECTOR
92
SCREW PLUG
92
SCREW PLUG FUEL TANK
92
SCREW PLUG SECONDARY CONSUMING UNIT AIR RESERVOIR
92
SCREW PLUG AT TANK
92
SCREW PLUG , Replaced By: N007604014110
95
SCREW PLUG HOUSING,BOTTOM, Replaced By: N000908018011
95
SCREW PLUG, FILLING HOUSING,BOTTOM M18X1.5
98
SEAL RING FROM FUEL TANK TO FUEL TANK
98
SEAL RING INJECTION PUMP
98
SEAL RING LINE CONNECTION
98
SEAL RING VALVE TO VALVE,K 025179
98
SEAL RINGTO 376 131 74 01
98
SEAL RINGTO 000 553 03 05,000 553 18 05,
98
SEAL RING POWER STEERING PUMP
98
SEAL RING GEAR DISPLAY
101
NUT CHECK VALVE TO AIR RESERVOIR
104
UNION NUT OIL COOLER HOUSING
104
UNION NUT LINE CONNECTION
999
OIL COOLER , ORDER NUMBER: 002 188 23 01/33
999
FLANGE HEATING CONNECTION LOCK
999
COVER OIL COOLER
999
FITTING PREHEATING CONNECTION AT OIL COOLER COVER
999
WASHER RADIATOR TO RUBBER MOUNTING
999
SPRING WASHERTO 000 268 46 01
999
SPRING WASHER STEERING COLUMN BRACKET TO CAB
999
WASHER , Replaced By: N000433010510
999
WASHER VIBRATION ABSORBER TO BRACKET
999
HOSE LINE , TO BE ORDERED ONLY FROM MTU-FRIEDRICHSHAFEN
999
HOSE LINE , TO BE ORDERED ONLY FROM MTU-FRIEDRICHSHAFEN
999
THREADED INSERT
999
LOCK WASHER BRACKET TO SUPPORT AND TO END PIECE
