Поз.
Артикул
Описание
15
THROTTLE HOUSING PARTS KIT,K 181318N 817421 - N 825202
15
THROTTLE HOUSING , Replaced By: A3661405353
22
VALVE PARTS KIT,K 181318N 817421 - N 825202
29
BUSHING
29
BUSHING THROTTLE VALVE SHAFT
36
LEVER EXHAUST-BRAKE THROTTLE VALVE
36
LEVER , Replaced By: A3661400232, +001N913017006000, +001N914126006025
43
BALL PIVOT BOTTOM B13X5 MM
50
SCREW LONGITUDINAL DIFFERENTIAL LOCK VALVE TO BRACKET,5 963747
50
HEXALOBULAR BOLT. SCREW LINE MOUNTING M 6X30
50
SCREW , Replaced By: N000000001479
50
SCREW , Replaced By: N910105006005
57
NUT , Replaced By: N913023006001
57
NUT , Replaced By: N910112006001
57
NUT BALL PIVOT TO LEVER
57
NUT LEVER TO THROTTLE VALVE SHAFT TO 366 140 02 32
78
CYLINDER
78
CYLINDER , Replaced By: A0004304926
78
CYLINDER , Replaced By: A0004303026
78
CYLINDER INCREASE IN NUMBER OF REVOLUTIONS KNORR
78
CYLINDER INTERMEDIATE SPEED STOP
78
CYLINDER (POWER CYLINDER),EXHAUST BRAKE, Replaced By: A0004307926
78
CYLINDER , Replaced By: A0004305926
78
WORKING CYLINDER (POWER CYLINDER),EXHAUST BRAKE
85
BUSHING , Replaced By: A0004340850
85
BUSHINGTO 000 430 30 26/32 26
85
BUSHING"WABCO"
92
REPAIR KIT SHIFTING CYLINDER TO KNORR, SZ 1130 I/74963,000 430 3026
92
REPAIR KIT , Replaced By: A0024300060
92
REPAIR KITTO 000 430 48 26,KNORR
99
NUT SHUT-OFF CYLINDER
106
BALL SOCKET
113
SECURING CLIP. CIRCLIP
120
PIN CYLINDER TO BRACKET
120
PIN , Replaced By: A4421440574
127
WASHER , Replaced By: N000125008443
127
WASHER EXHAUST MUFFLER TO STRAP
134
NUT SHIFTING CYLINDER TO PIN,5 353829
141
WASHER SUPPORTING RAIL TO SUPPORT,5 429712
148
NUT
155
BRACKET POWER CYLINDER, TO BE ADAPTED DURING ASSEMBLY
155
BRACKET , FIRST EXHAUST STOCK OF OLD PARTS UP TO IDENT NO. K 077169/N 817421 - 825202, Replaced By: A3661440440
162
SCREW BRACKET TO THROTTLE HOUSING M 8X16
999
SCREW BRACKET TO BATTERY/APPARATUS SUPPORT
999
WASHER INTERMEDIATE SPEED STOP
999
BALL SOCKET SHIFTING CYLINDER TO SHIFT LEVER
999
PIN INTERMEDIATE SPEED STOP
999
SCREW EXHAUST PIPE TO BRACKET
999
BRACKET , Replaced By: A6504920241
999
EXHAUST PIPE FRONT,REAR PART
999
EXHAUST PIPE FRONT,FRONT PART,5 308040
999
PROTECTIVE PLATE FRONT EXHAUST PIPE
999
BRACKET , Replaced By: A6524911141
999
BRACKET FRONT EXHAUST PIPE
999
STRAP EXHAUST MUFFLER TO BRACKET,FRONT AND REAR
999
BRACKET EXHAUST MUFFLER TO SIDE MEMBER
999
PROTECTIVE PLATE FRONT EXHAUST PIPE
999
BRACKET FRONT EXHAUST PIPE,5 502998
999
BRACKET , Replaced By: A6764901040
999
WASHER , Replaced By: N000125008443
999
SCREW , Replaced By: N000961012208
999
SCREW , Replaced By: N308676012012
999
SCREW BRACKET TO CONSOLE
999
SCREW , Replaced By: N308676014020
999
SCREW. HEXAGON HEAD BOLT VALVE TO BRACKET
999
SCREW BRACKET TO SIDE MEMBER M 14X1.5X35
999
HEXAGON NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET
999
NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET, Replaced By: N910113008003
999
NUT , Replaced By: N913004008001
