Поз.
Артикул
Описание
10
ENCAPSULATION FRONT
20
BRACKET LEFT, FIRST EXHAUST STOCK OF OLD PARTS UP TO IDENT NO. F 20130328, Replaced By: A2075240740
20
BRACKET LEFT
30
BRACKET RIGHT, FIRST EXHAUST STOCK OF OLD PARTS UP TO IDENT NO. F 20130328, Replaced By: A2075240840
30
BRACKET RIGHT
40
BOLT LOWER SUPPORT M6X19
60
UNDERBODY PROTECTION CENTRAL
60
ENCAPSULATION CENTRAL
60
ENCAPSULATION CENTRAL
60
PROTECTIVE PLATE CENTRAL
65
COVER F ENGINE COMP. BM CENTRAL
70
DAMPING MAT FOR PROTECTIVE SHIELD
70
DAMPING MAT FOR PROTECTIVE SHIELD
80
FASTENER BUTTON UPPER PART
90
FASTENER BUTTON LOWER PART
100
ENCAPSULATION REAR, A 20140222 G 20140228 R 20131129
110
BRACKET RIGHT
110
BRACKET RIGHT, F 84733620120119
110
BRACKET RIGHT, F 84733520120119
130
HEXAGON NUT W COLLAR BRACKET MOUNTING
150
SHEET METAL SCREW FRONT MODULE 4.8X19, J 47253520070424
160
CLIP-TYPE NUT BUMPER TO FRONT MODULE 4,8, J 47253620070424
160
LOCK. CLIP-TYPE NUT
170
SCREW BRACKET TO CROSS CONNECTION STRUT
180
SPRING-THREAD NUT PROTECTIVE PLATE
200
STRUT BETWEEN LONGITUDINAL MEMBER ANDFRAME-TYPE INTEGRAL SUPPORT
210
HEXAGON HEAD BOLT HEAT SHIELD MOUNTING M10X20
220
BOLT STRUT TO FRAME-TYPE INTEGRAL SUPPORT
250
BRACKET REAR
260
SCREW CHARGE PLUNGER UNIT
