Поз.
Артикул
Описание
30
HOSE FEED & RETURN 8X11MM, ORDER BY THE METER
33
BANJO UNION , Replaced By: N000000000363
33
BANJO UNION HOSE WIDTH, / I.D., 8/22 MM
33
BANJO UNION FROM PRESSURE REGULATOR TO ANTI-FREEZE DEVICE,6 900001-6 900006
81
PROTECTIVE CAP COMPRESSED AIR LINE MOUNTING
460
BRAKE MASTER CYLINDER , Replaced By: A0034309401
460
BRAKE MASTER CYLINDERSCHAEFER
461
SCREWTO 003 430 72 01,SCHAEFER
462
SEAL RINGTO 002 430 69 01
463
THREADED UNIONTO 003 430 72 01,SCHAEFER
464
SEAL RINGTO 002 430 72 01,SCHAEFER
465
VALVE DISCTO 003 430 72 01,SCHAEFER
466
SPRINGTO 002 430 69 01
467
SPRING RETAINERTO 003 430 72 01,SCHAEFER
468
SPRINGTO 003 430 72 01,SCHAEFER
469
SPRINGTO 003 430 72 01,SCHAEFER
470
WASHERTO 003 430 72 01,SCHAEFER
471
THREADED UNIONTO 003 430 72 01,SCHAEFER
472
SEAL RINGTO 002 430 69 01
473
BLEEDER VALVE , Replaced By: A0004310265
473
VALVE , Replaced By: A3075530107
473
VALVE CLUTCH SLAVE CYLINDER
474
PROTECTIVE CAP , Replaced By: A0004210887
474
PROTECTIVE CAP , Replaced By: A0004217187
474
PROTECTIVE CAP ,5 962906
474
PROTECTIVE CAP , Replaced By: A0004217187
475
REPAIR KIT , Replaced By: A0035860143
475
REPAIR KITTO 003 430 94 01,003 430 72 01
477
CONNECTOR MASTER CYLINDER,CONNECTION "2.1",4 338292
478
SEAL RING FUEL LINE TO FEED PUMP
479
HOHLSCHRAUBE FUR. HOLLOW SCREW MASTER CYLINDER,CONNECTION "2.1",4 338292
481
FITTING TWO-WAY VALVE "12",4 4121264 691315
483
SEAL RING LINE CONNECTION
483
SEAL RING LINE CONNECTION
487
HOLLOW SCREW , Replaced By: N915036010108
487
HOLLOW SCREW FUEL LINE TO FEED PUMP
490
SEAL RING FUEL LINE TO FEED PUMP
495
BRACKET MASTER CYLINDER TO BRAKE BOOSTER,4 373946
502
SCREW HAND PUMP TO BRACKET
507
BRACKET BRAKE MASTER CYLINDER,4 373947
510
BRACKET DELIVERY AND SUCTION LINES TO ENGINE, FRONT
510
BRACKET DELIVERY AND SUCTION LINES TO ENGINE, FRONT
512
SCREW , Replaced By: N304014008001
512
SCREW FRONT AXLE REGULATING SOLENOID VALVE M 8X75
515
NUT , Replaced By: N913004008001
515
NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET, Replaced By: N910113008003
520
TEST CONNECTION REAR AXLE BRAKE CIRCUIT
520
TEST CONNECTION REAR AXLE BRAKE CIRCUIT
522
SCREWM 8X40
524
NUT , Replaced By: N913004008001
524
NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET, Replaced By: N910113008003
530
RESERVOIR WITH WARNING DEVICE,4 314610
535
FILLER CAP , Replaced By: A0004313733
535
FILLER CAP , Replaced By: A0004316533
535
FILLER CAP , Replaced By: A0004317633
535
FILLER CAPTO 001 431 38 02,000 431 58 02
538
STRAINERTO 001 431 38 02
541
CLAMPTO 000 431 58 02
546
SCREW COVER PLATE TO BRACKET
546
SCREW COVER PLATE TO BRACKET
549
WASHER COMPRESSED AIR LINE TO BRACKET, Replaced By: N000125006449
552
NUT , Replaced By: N913004006001
552
NUT PUMP TO BRACKET
553
LINE FROM CLUTCH MASTER CYLINDER TO CLUTCH HOSE
554
LINE FROM VALVE TO BRAKE HOSE 1500 MM
554
LINE1750 MM, UP TO IDENT NO. 721608 EXCEPT FOR:500001-599999
555
BRACKET , Replaced By: A3812950440
555
BRACKET , EXHAUST STOCK OF OLD PARTS NUMBER FIRST UP TO CHASSIS 4 493018, Replaced By: A3812950440
555
BRACKET COMPRESSED AIR LINE TO FOUR-CIRCUIT PROTECTIVE VALVE,5 720506
556
CLAMP , Replaced By: N916016008200
556
CLAMP ,K 147121, Replaced By: N000000000319
558
SCREW CONNECTOR
562
SCREW VALVE TO BRACKET
564
SPACER TUBE FRONT AXLE REGULATING SOLENOID VALVE
566
NUT , Replaced By: N913004008001
566
NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET, Replaced By: N910113008003
568
LINE FROM BRAKE POWER REGULATOR TO REAR AXLE BRAKE HOSE
570
LINE FROM CONNECTOR TO TEST CONNECTION 2800 MM,4 478330
594
BRAKE HOSE AT REAR AXLE
596
BRACKET. LOCK , Replaced By: A6525040038
596
MOUNTING PLATE FROM EXPANSION TANK TO RADIATOR
598
ANGLE AT FRAME, FRONT
600
GROMMET BATTERY CASE
602
SCREW END PIECE TO EXHAUST PIPE M 10X25
602
SCREW END PIECE TO EXHAUST PIPE M 10X25
604
NUT , Replaced By: N910113010000
604
NUT STRAP TO BRACKET
612
CLAMP , Replaced By: N916016008200
612
CLAMP ,K 147121, Replaced By: N000000000319
613
SCREW CONNECTOR
614
NUT , Replaced By: N913004006001
614
NUT PUMP TO BRACKET
620
TUBE. BUSHING CAB FLOOR COVERING
624
LINE1750 MM, UP TO IDENT NO. 721608 EXCEPT FOR:500001-599999
624
LINE
625
ANGLE LINE MOUNTING
626
SCREW , Replaced By: N304017008021
626
SCREW PIPE CLAMP
628
SCREW , Replaced By: N304017006026
628
SCREW , Replaced By: N304017006026
632
SCREW PLATE TO VALVE M 6X70
632
SCREW , Replaced By: N304014006005
634
WASHER COMPRESSED AIR LINE TO BRACKET, Replaced By: N000125006449
636
NUT PUMP TO BRACKET
636
NUT , Replaced By: N913004006001
638
GUIDE BUSHING TWO-WAY VALVE TO FRAME
638
SPACER TUBE , Replaced By: A3094310249
640
LINE FROM BRAKE POWER REGULATOR,CONNECTION "2",TO BRAKE HOSE 1250 MM
640
LINE FROM BRAKE POWER REGULATOR TO REAR AXLE BRAKE HOSE
641
LINE FROM BRAKE POWER REGULATOR TO BRAKE PRESSURE RELIEF 1200 MM
642
BRACKET DELIVERY AND SUCTION LINES TO ENGINE, TOP
642
BRACKET FUEL LINES
644
SCREW COVER PLATE TO BRACKET
646
NUT PUMP TO BRACKET
646
NUT , Replaced By: N913004006001
647
BRACKET DELIVERY AND SUCTION LINES TO ENGINE, TOP
650
LINE FROM BRAKE POWER REGULATOR TO BRAKE PRESSURE RELIEF 600 MM
650
LINE FROM TEST CONNECTION TO RIGHT WHEEL CYLINDER 700 MM,4 644237
652
BRAKE HOSE
652
BRAKE HOSE
654
ANGLE AT FRAME, FRONT
656
MOUNTING PLATE FROM EXPANSION TANK TO RADIATOR
656
BRACKET. LOCK , Replaced By: A6525040038
657
SCREW END PIECE TO EXHAUST PIPE M 10X25
658
NUT STRAP TO BRACKET
658
NUT , Replaced By: N910113010000
659
BRACKET LEFT,6028918 000001
659
BRACKET , Replaced By: A3184280340
660
BRACKET RIGHT,7914218 000001
660
BRACKET , Replaced By: A3184280440
662
SCREW OIL-DIPSTICK GUIDE TUBE TO BRACKET
662
SCREW , Replaced By: N304017008016
664
LOCK WASHER CLAMP TO BRACKET AND TO PIPE
666
CLAMP BRAKE LINE MOUNTING
668
HOSE BRAKE LINE TO REAR AXLE,4 644238
670
TEST CONNECTION FRONT AXLE
671
SCREW BRACKET TO CROSS CONNECTION STRUT
671
SCREW , Replaced By: N304017008034
999
COUPLING PIECE AT CAB FLOOR,4 383114 ALSO INSTALLED ON 4 366280,4 366695,4 367047.
999
COUPLING PIECE ,4 383114 ALSO INSTALLED ON 4 366280,4 366695,4 367047.
999
VALVE GASKET KIT TO 003 429 16 44,BOSCH,UP TO 03.82
999
VALVEBOSCH
999
BLEEDER VALVE , Replaced By: A0004310265
999
PROTECTIVE CAP , Replaced By: A0004210887
999
BRAKE HOSE
999
BRAKE HOSE , Replaced By: A0004280535
999
THRUST RING , THE OLD PART MUST NO LONGER BE INSTALLED, Replaced By: A0009940203
999
AIR CLEANER
999
THRUST RING , THE OLD PART MUST NO LONGER BE INSTALLED, Replaced By: A0009940103
999
THRUST RING LOAD/NO-LOAD VALVE,CONNECTION: "20"
999
LINE FROM FOUR-CIRCUIT PROTECTIVE VALVE TO AIR RESERVOIR 9X12 MM, LENGTH AVAILABLE 3000 MM
999
HANDLE (PARTS KIT) TO 001 430 07 81/20 81, UP T0 BOSCH CHARACTERISTIC NUMBER 045
999
HANDLETO 001 430 17 81,KNORR
999
REPAIR KITTO 001 430 18 81/78 81
999
REPAIR KITTO 001 431 47 06,WABCO 2210, 620.415 UP TO CHASSIS 5 014668 620.416 UP TO CHASSIS 5 000515 620.417 UP TO CHASSIS 4 972023
999
REPAIR KIT BLEEDER VALVE TO 001 431 67 05,BOSCH
999
REPAIR KITBOSCH
999
GASKET KIT FOUR-CIRCUIT PROTECTIVE VALVE BOSCH
999
REPAIR KITTO 001 431 84 06,KNORR, 620.415 UP TO CHASSIS 5 014668 620.416 UP TO CHASSIS 5 000515 620.417 UP TO CHASSIS 4 972023
999
REPAIR KIT SEAL RING BOSCH,209
999
VALVE , Replaced By: A0004310265
999
FILTER BOTTOMTO 000 431 24 14
999
COVERTO 001 431 85 14,4 282708
999
GUIDE BUSHING
999
ACTUATING PARTTO 001 430 37 81/46 81,BOSCH, WITH HAND BRAKE VALVE ON ENGINE TUNNEL, FROM IDENT NO. SEE MF 26032
999
VALVE PART
999
COVERTO 001 430 37 81/46 81,BOSCH, WITH HAND BRAKE VALVE ON ENGINE TUNNEL, FROM IDENT NO. SEE MF 26032
999
SEAL RINGTO 000 431 77 14,KNORR
999
ACTUATING PARTTO 001 430 07 81/20 81
999
DIAPHRAGMTO 001 431 90 06,GRAU,5 148812
999
GASKETTO 000 431 77 14,KNORR
999
GASKET34X2X6 MM,GRAU
999
TEST CONNECTION
999
BRAKE CYLINDERBOSCH, PART IS ONLY OR ALSO SUPPLIED AS RECONDITIONED PART
999
LEVER , Replaced By: A0034302881
999
VALVE DISCTO 001 431 90 06,GRAU,5 148812
999
VALVE DISCTO 001 431 90 06,GRAU,5 148812
999
CUPTO 000 431 21 14,BOSCH, WITH BOSCH CHARACTERISTIC NUMBER 724
999
VALVE SEATGRAU
999
VALVE SEATTO 001 431 90 06,GRAU,5 148812
999
VALVE SEATTO 001 431 68 06,GRAU 37001, 620.415 UP TO CHASSIS 5 014668 620.416 UP TO CHASSIS 5 000515 620.417 UP TO CHASSIS 4 972023
999
VALVETO 001 431 90 06,GRAU,5 148812
999
STRAINERTO 001 431 90 06,GRAU,5 148812
999
SEAL RING , Replaced By: A0129975448
999
TEST CONNECTION SOLENOID VALVE,CONNECTION: "20"
999
STRAINER , Replaced By: A0004313134
999
TEST CONNECTION SOLENOID VALVE,CONNECTION: "20"
999
CUPTO 000 431 66 14
999
CUP
999
TEST CONNECTION SOLENOID VALVE,CONNECTION: "20"
999
TEST CONNECTION FRONT AXLE
999
BRAKE CYLINDER SPRING LOAD ACCUMULATOR CYLINDER KNORR
999
PROTECTIVE CAP
999
PISTONTO 001 431 85 14,001 431 86 14,4 282708
999
CUP , Replaced By: A0015864342
999
BRAKE CYLINDER , EXHAUST STOCK OF OLD PARTS NUMBER FIRST UP TO CHASSIS 4 847617, Replaced By: A0014318514
999
BRAKE CYLINDER , FIRST EXHAUST STOCK OF OLD PARTS UP TO IDENT NO. 4 847617, Replaced By: A0014318514
999
PISTONTO 000 431 21 14,BOSCH
999
PROTECTIVE CAPTO 000 431 24 14
999
PROTECTIVE CAPTO 001 431 90 06,GRAU,5 148812
