Поз.
Артикул
Описание
106
PROTECTIVE PLATE WHEEL CYLINDER, 003861
110
LOCK WASHER BRACKET TO SUPPORT AND TO END PIECE
143
BUSHING ,3 096825
148
LOCK , 344.030,032,033,040,041,057,058 UP TO IDENT NO. 415524, FROM IDENT NO. SEE SPARE PARTS LIST 732.7
157
SPRING SHORT
162
FILLER
163
SPRING , UP TO CHASSIS 910369 ALSO INSTALLED ON 500001-501455,FROM CHASSIS 910370 AND 501456-599999 SEE SPARE PARTS LIST 103
164
FILLER
165
LOCK WASHER CLAMP TO BRACKET AND TO PIPE
166
NUT
199
GREASE NIPPLE PROTECTIVE TUBE
204
LOCK WASHERROCKINGER TYP 59 G140,59 G150
205
SCREW SHOCK ABSORBER TO UPPER BEARING BRACKET,5 261497
999
REPAIR KIT BRAKE CAMSHAFT BEARING, FROM CHASSIS 674068 ALSO INSTALLED ON, 500001-599999,673550,673631,673890,673916-673918,673922,673927 UP TO CHASSIS 910369 ALSO INSTALLED ON 500001-501414,FROM CHASSIS 910370 AND 501415-599999 SEE SPARE PARTS LIST 744.3
999
BRAKE ANCHOR PLATE , Replaced By: A3024201316
999
THRUST SHACKLE , UP TO REAR AXLE029311, Replaced By: A3024201419, +001A3024230874, +001A3024940109, +001N000933008106, +001N912004008102
999
ADJUSTER , Replaced By: A3025860442
999
BRAKE ANCHOR PLATE RIGHT, 601567
999
THRUST SHACKLE , Replaced By: A3834200389
999
BRAKE ANCHOR PLATE , Replaced By: A3024204317
999
BRAKE ANCHOR PLATE , Replaced By: A3024204417
999
REPAIR KIT BRAKE READJUSTMENT
999
BRAKE ANCHOR PLATE RIGHT
999
PIVOT PIN , Replaced By: A3024210118
999
SLIDE IN ITS PLACE,YOU MAY ALSO USE MERCEDES-BENZ PART NO.: 302 421 01 29
999
PIN , Replaced By: A3024210174
999
SLIDE , Replaced By: A3024210229
999
SLIDE , Replaced By: A3024210329
999
SLIDE BRAKE READJUSTMENT
999
PIVOT PIN , Replaced By: A3024230518
999
PIN , Replaced By: A3024230774
999
ADJUSTING LEVER RIGHT
999
PIVOT PIN , Replaced By: A3024230418
999
PIN , Replaced By: A3024230874
999
PIN , Replaced By: A3024230974
999
PIN THRUST SHACKLE TO BRAKE SHOE
999
REPAIR KIT , Replaced By: A3024200067
999
REPAIR KIT , Replaced By: A3534200067
999
REPAIR KIT , Replaced By: A3024203138
999
EXPANSION PLUG
999
BASE , Replaced By: A3142030084
999
INSPECTION HOLE COVER
999
SPRING , Replaced By: A3029930310
999
RIVET
999
RIVET
999
SPRING
999
PROTECTIVE CAP , Replaced By: A0004210887
999
PIN
999
STOP , 020105
999
PAWL
999
CABLE PULLEY , Replaced By: A3224200293
999
PAWL
999
BRAKE LINING10.6 MM, UP TO CHASSIS 013362 ON SPECIAL REQUEST, H.D. FRONT AXLE
999
WASHER AS REQUIRED 2.00MM, UP TO CHASSIS 674067 EXCEPT FOR 500001-599999,673550,673631,673890,673916-673918,673922,673927
999
BUSHING , UP TO CHASSIS 674067 EXCEPT FOR 500001-599999,673550,673631,673890,673916-673918,673922,673927
999
PIN PAWL LEVER
999
WASHER AS REQUIRED 2.3MM, UP TO CHASSIS 674067 EXCEPT FOR 500001-599999,673550,673631,673890,673916-673918,673922,673927
999
WASHER , Replaced By: A3214270176
999
WASHER , Replaced By: A3214270276
999
CABLE PULLEY , UP TO IDENT NO. 674067 EXCEPT FOR 500001-599999, 673432, 673497, 673628,673629,673921
999
HANDLE , Replaced By: A3214270126
999
BRAKE ANCHOR PLATE , 344.032,033,040,041,132,133,140,141 UP TO FRONT AXLE 1915444, 344.055,057,058 UP TO FRONT AXLE 1903739, Replaced By: A3444207116, +004A3094210211
999
SPRING , Replaced By: A3224210392
999
THRUST SHACKLE , Replaced By: A3444207027
999
BRAKE ANCHOR PLATE , Replaced By: A3374200017
999
BRAKE ANCHOR PLATE , Replaced By: A3374200117
999
LINE FROM DISTRIBUTOR TO LEFT REAR WHEEL 6X0.7 MM, USED WITH HYDRAULIC BRAKE,345.000-008,021,024,025,033 UP TO IDENT NO. FB588185
999
LINE , Replaced By: A3404204629
999
LINE , Replaced By: A3404201829
999
LINE FROM DISTRIBUTOR TO RIGHT REAR WHEEL 6X0.7 MM, USED WITH HYDRAULIC BRAKE,345.000-008,021,024,025,033 UP TO IDENT NO. FB588185
999
LINE , Replaced By: A3404204929
999
LINE , Replaced By: A3404203329
999
LINE , Replaced By: A3404204629
999
BRAKE LEVER , Replaced By: A3384205012
999
SPHERICAL PIECE , Replaced By: A3025860242
999
BRACKET , Replaced By: A3044270412
999
LINE , Replaced By: A0004290201
999
LINE , Replaced By: A0004290201
999
BRACKET
999
LINE , Replaced By: A0004290401
999
LINE , Replaced By: A3404204429
999
LINE , Replaced By: A3404202029
999
LINE , Replaced By: A3404204229
999
LINE , Replaced By: A3404203529
999
LINE , Replaced By: A3404204329
999
LINE , Replaced By: A3404204529
999
LINE , Replaced By: A3404203329
999
LINE , Replaced By: A3404204229
999
LINE , Replaced By: A3404203529
999
LINE , Replaced By: A3404204129
999
LINE , Replaced By: A3404201829
999
LINE , Replaced By: A3404202029
999
LINE , Replaced By: A3404204029
999
LINE , Replaced By: A3404203829
999
LINE , Replaced By: A3404204829
999
LINE , Replaced By: A3404203829
999
LINE , Replaced By: A3404204229
999
LINE , Replaced By: A3404204129
999
LINE , Replaced By: A0004290201
999
LINE , Replaced By: A0004290201
999
LINE , Replaced By: A0004290201
999
LINE , Replaced By: A0004290201
999
LINE , Replaced By: A0004290201
999
LINE , Replaced By: A0004290201
999
BRACKET
999
FITTING , Replaced By: A0019972772
999
REPAIR KIT BRAKE SHOE SHACKLE SPACER PIN
999
REPAIR KIT BRAKE SHOE SHACKLE, UP TO CHASSIS 910369 ALSO INSTALLED ON 500001-501455,FROM CHASSIS 910370 AND 501456-599999 SEE SPARE PARTS LIST 103
999
BRAKE LEVER
999
YOKE
999
BRAKE CABLE
999
LINE , Replaced By: A3404203929
999
LINE , Replaced By: A3404204329
999
ROD
999
LINE , Replaced By: A3404204129
999
BRAKE INTERMEDIATE SHAFT
999
LINE , Replaced By: A3404204029
999
ROD870 MM
999
GUIDE
999
PAWL ROD , Replaced By: A3274275330
999
BEARING BRACKET
999
LINE , Replaced By: A0004290201
999
LINE , Replaced By: A0004290201
999
LINE , Replaced By: A0004290401
999
LINE , Replaced By: A0004290401
999
LINE , Replaced By: A0004290201
999
LINE , Replaced By: A0004290201
999
LINE , Replaced By: A0004290201
999
LINE , Replaced By: A0004290201
999
LINE , Replaced By: A0004290201
999
LINE , Replaced By: A0004290201
999
LINE , Replaced By: A0004290201
999
LINE , Replaced By: A0004290201
999
LINE , Replaced By: A0004290201
999
LINE , Replaced By: A0004290201
999
LINE , Replaced By: A0004290201
999
LINE , Replaced By: A0004290201
999
LINE , Replaced By: A0004290401
999
LINE , Replaced By: A0004290201
999
LINE , Replaced By: A0004290201
999
LINE , Replaced By: A0004290201
999
LINE , Replaced By: A0004290201
999
LINE , Replaced By: A0004290201
999
LINE , Replaced By: A0004290201
999
BRACKET
999
LINE FROM PRESSURE CONTROL VALVE TO FRONT AXLE BRAKE HOSE,LEFT
999
LINE FROM TEST CONNECTION TO RIGHT FRONT WHEEL 2200 MM,4 478329
999
LINE FROM TEST CONNECTION TO RIGHT FRONT WHEEL BRAKE HOSE
999
LINE FROM MASTER CYLINDER TO FRONT AXLE TEST CONNECTION 2600 MM
999
LINE FROM CONNECTOR TO TEST CONNECTION 2800 MM,4 478330
999
LINE FROM DISTRIBUTOR TO VALVE 3000 MM
999
LINE FROM DISTRIBUTOR TO VALVE 3200 MM
999
LINE FROM CONNECTOR TO TEST CONNECTION 3400 MM,4 478330
999
LINE FROM DISTRIBUTOR TO VALVE 3600 MM,4 478330
999
LINE FROM TEST CONNECTION TO BRAKE POWER REGULATOR 3800 MM,4 478329
999
LINE FROM DISTRIBUTOR TO VALVE 4200 MM,4 478330
999
SPRING , Replaced By: A3524210192
999
SPRING , Replaced By: A3029930610
999
REPAIR KIT , Replaced By: A3585860242
999
PLUG PROTECTIVE PLATE
999
SCREW PLUG AT TANK
999
REPAIR KIT , Replaced By: A3534200167
999
BALL CUP BRAKE INTERMEDIATE SHAFT BEARING
999
BEARING BRACKET , 660649, Replaced By: A3544206278, +001A3434200181
999
BRAKE DRUM ,K085757, Replaced By: A3544210301, +020A3274010471
999
BRAKE DRUM , Replaced By: A3544210301
999
LEVER RIGHT
999
REPAIR KIT BRAKE SHOE MOUNTING BOLT
999
REPAIR KIT , Replaced By: A3584200182
999
BRAKE LINING (PARTS KIT) (BRAKE LINING 17.70 MM)
999
HEXALOBULAR BOLT WIRE CABLE TO BRACKET
999
SCREW
999
SCREWM 5X20
999
SCREW , Replaced By: N007985005175
999
SCREW SHIFT CASE TO SLOTTED GATE
999
SCREW , Replaced By: A0029903712
999
COTTER PIN
999
COTTER PIN
999
COTTER PIN CYLINDER TO BRACKET
999
COTTER PINTO 345 431 70 16, USED WITH HYDRAULIC BRAKE,345.000-008,021,024,025,033 UP TO IDENT NO. FB588185
999
COTTER PINROCKINGER TYP 260 G140
999
WASHER , Replaced By: N000433005304
999
WASHER COMPRESSED AIR LINE TO BRACKET, Replaced By: N000125006449
999
WASHER , Replaced By: N000125010532
999
WASHER RADIATOR TO RUBBER MOUNTING
999
WASHER GROUND STRAP TO ENGINE, UP TO CHASSIS 4 602752,EXCEPT FOR 551570-599999
999
WASHER
999
WASHER BOOT TO CAB FLOOR
999
LOCK RING
999
SCREW , Replaced By: N304017008018
999
SCREW "BRAKE" SHUT-OFF COCK
999
SCREWM 8X40
999
SCREW , Replaced By: N000933008337
999
SCREW CLAMP TO BRACKET AND TO PIPE
999
SCREW , Replaced By: N304017008027
999
SCREW , Replaced By: N304017008034
999
SCREW , Replaced By: N304017008021
999
SCREW , Replaced By: N304017008040
999
SCREW , Replaced By: N304017008016
999
SCREW , Replaced By: A0099900101
