Поз.
Артикул
Описание
5
LINE CLUTCH 8 X 1, LENGTH AVAILABLE 3000 MM
10
UNION NUT LINE CONNECTION
15
GLAND LINE CONNECTION
20
SLEEVE LINE CONNECTION
25
PLASTIC PIPE. HOSE AERATION 6X8 MM, ORDER BY THE METER
25
PLASTIC PIPE AERATION, ORDER BY THE METER
30
BANJO UNION HOSE WIDTH, / I.D., 6/12 MM
35
FITTING (PARTS KIT),LINE RUPTURE
35
FITTING , Replaced By: A0029905971
40
BRAKE HOSE SPRING-LOAD ACCUMULATOR CYLINDER TWOWAY VALVE,LEFT
40
BRAKE HOSE RETARDER
45
VALVE SOLENOID VALVE,5 450429 PART IS ONLY OR ALSO SUPPLIED AS RECONDITIONED PART
45
VALVE , Replaced By: A0049975736
45
VALVE (3/2-WAY SOLENOID VALVE) EKS
50
VALVE ENGINE SHUT-OFF
54
SEAL RINGWABCO
72
SEAL RING24X2 MM
90
SEAL RING VALVE TO VALVE
116
VALVE PARTTO 004 997 00 36,5 757289 AUSSERDEM EINGEBAUT IN 5 759173
120
PROTECTIVE CAPWABCO
125
SEAL RINGTO 000 429 24 30
130
REPAIR KITTO 003 997 14 36,WABCO 472 123 19 80
132
T-FITTING 3/2-WAY VALVE,CONNECTION: "33", UP TO IDENT NO. 5 385481 FROM IDENT NO. SEE STANDARD VERSION
134
HOLLOW SCREW HEATING CONNECTION
138
SEAL RING PRESSURE REGULATOR,CONNECTION: "23",5 161701
144
FITTING LINE CONNECTION
144
FITTING LINE CONNECTION, Replaced By: N000000006446
162
SEAL RING LINE CONNECTION
180
SCREW PLUG SOCKET TO BRACKET BEHIND CAB
198
NUT BRACKET TO SIDE MEMBER
204
CLAMP BATTERY CABLE MOUNTING
204
CLAMP IDLING ADJUSTMENT WIRE CABLE,K 147121
204
CLAMP ,K 147121, Replaced By: N000000000319
999
VALVETO 003 997 11 36/12 36
