Поз.
Артикул
Описание
250
VALVE (3/2-WAY SOLENOID VALVE)
255
REPAIR KIT 3/2-WAY SOLENOID VALVE
260
FITTING LINE CONNECTION
270
FITTING PARKING BRAKE VALVE,CONNECTION: "23"
272
FITTING FROM PUMP TO CYLINDER
272
ELBOW FITTING FROM PUMP TO CYLINDER, Replaced By: N000000006197
274
HOLLOW SCREW LINE CONNECTION
274
HOLLOW SCREW LINE CONNECTION
277
HOLLOW SCREW FITTING REAR AXLE 3/2-WAY VALVE
277
HOLLOW SCREW FUEL LINE TO FEED PUMP
277
HOLLOW SCREW , Replaced By: N915036010108
280
SEAL RING , Replaced By: N007603010110
280
SEAL RING 4/2-WAY VALVE 10X13.5
280
SEAL RING PNEUMATIC VALVE
282
ELBOW FITTING POWER CYLINDER
285
SEAL RING FRONT AXLE/REAR AXLE 3/2-WAY VALVE
286
THRUST RING FROM 3/2-WAY VALVE TO QUICK BREATHER VALVE,5 431227
288
SEAL RING FROM 3/2-WAY VALVE TO QUICK BREATHER VALVE,5 431227
290
SCREW 3/2-WAY VALVE TO BRACKET, UP TO IDENT NO. 5 385481 FROM IDENT NO. SEE STANDARD VERSION
300
WASHER CABLE CONNECTOR TO BRACKET AND TO FRAME,RESP.
300
WASHER , Replaced By: N009021005205
310
NUT TWO-WAY VALVE TO BRACKET
420
BANJO UNION HOSE WIDTH, / I.D., 4/10 MM
430
LOOM TIE LINE MOUNTING
440
VALVE 4/3-WAY
450
CONSOLE PNEUMATIC-SUSPENSION CONTROL LINE
460
HOLLOW SCREW LINE CONNECTION
470
SEAL RING PNEUMATIC VALVE
470
SEAL RING , Replaced By: N007603010110
480
KNOB 3/2-WAY VALVE
490
BRACKET 4/3-WAY VALVE
500
NUT 4/3-WAY VALVE TO SUBSTRUCTURE
510
SCREW DIODE CASE TO OPERATING UNIT CASE
520
NUT HOOK TO BRACKET
520
NUT , Replaced By: N910113005001
525
EXPANSION PLUG ,030090
530
INSTRUCTION PLATE 4/3-WAY VALVE
535
GROOVED NAIL GUIDE SIGN TO INSTRUMENT PANEL, UP TO CHASSIS 038985 EXCEPT FOR 036983
540
PLASTIC PIPE AERATION, ORDER BY THE METER
540
PLASTIC PIPE. HOSE AERATION 6X8 MM, ORDER BY THE METER
545
FITTING (PARTS KIT),LINE RUPTURE
550
UNION NUT LINE CONNECTION
560
GLAND LINE CONNECTION
570
SLEEVE LINE CONNECTION
580
BANJO UNION HEATING CONNECTION,K 169122
999
ROD
999
COVERING PARKING BRAKE VALVE
999
SEAL RING , Replaced By: N007603010110
