Поз.
Артикул
Описание
36
PLASTIC PIPE FUEL LINE 12X1,5 MM, ORDER BY THE METER
36
HOSE , Replaced By: A0009872827
42
UNION NUT LINE CONNECTION, Replaced By: N000000006239
42
UNION NUT LINE CONNECTION
48
GLAND , Replaced By: A0019901967
48
SEAL CONE LINE CONNECTION
54
SLEEVE LINE CONNECTION
60
BANJO UNION HOSE WIDTH, / I.D., 9/16 MM
66
FITTING (PARTS KIT),LINE RUPTURE
104
CONNECTOR COMPRESSED-AIR-LINE PLUG-CONNECTION
106
CONNECTOR HOSE WIDTH, 6 MM, TO M22
108
COUPLING SPRING-LOAD-ACCUMULATOR RELEASE/ EMERGENCY-RELEASE PRESSURE
110
SCREW. UNION SCREW LINE CONNECTION
110
SCREW. UNION SCREW , Replaced By: A0009973734
112
WASHER , Replaced By: N000125015019
112
WASHER STRUT TO EXHAUST PIPE AND TO SIDE MEMBER
114
NUT FROM 3/2-WAY VALVE TO QUICK BREATHER VALVE,5 431227
174
T-FITTING POWER STEERING
204
ELBOW FITTING DELIVERY LINE TO PUMP
210
RESERVOIR STEEL 20L, D246MM
210
COMPRESSED AIR RESERVOIR COMPRESSED AIR 20 L.
210
RESERVOIR , Replaced By: A0034321201
210
RESERVOIR , 070817, Replaced By: A0034321101
210
RESERVOIR COMPRESSED AIR 20 L., Replaced By: A0064329801
210
RESERVOIR COMPRESSED AIR,5 295503
222
VALVE (OVERFLOW VALVE),5 548795
224
FITTING LINE CONNECTION
226
FITTING LINE CONNECTION
228
NUT CHECK VALVE TO AIR RESERVOIR
230
THRUST RING , THE OLD PART MUST NO LONGER BE INSTALLED, Replaced By: A0009940203
232
O-RING CHECK VALVE TO AIR RESERVOIR
234
SCREW. UNION SCREW LINE CONNECTION
240
FITTING FRONT AXLE REGULATING SOLENOID VALVE, CONNECTION: "20"
240
FITTING FRONT AXLE REGULATING SOLENOID VALVE, CONNECTION: "20", Replaced By: N000000006191
244
SCREW RESERVOIR TO BRACKET M 22X1.5X50
300
HOLLOW SCREW FRONT AXLE REGULATING SOLENOID VALVE, CONNECTION: "10",K 009079
306
SEAL RINGTO 006 997 00 72
336
VALVE DRAIN, Replaced By: A0004322407
336
VALVE DRAIN, Replaced By: A0004322107
336
VALVE. DRAIN VALVE DRAIN
342
SEAL RING LINE CONNECTION
999
FITTING , Replaced By: A0029905971
999
FITTING , Replaced By: A0029906171
999
BANJO UNION , Replaced By: N915052009009
