Поз.
Артикул
Описание
17
LINE CLUTCH 8 X 1, LENGTH AVAILABLE 3000 MM
18
FITTING (PARTS KIT),LINE RUPTURE
18
FITTING , Replaced By: A0029905971
19
UNION NUT LINE CONNECTION
20
GLAND LINE CONNECTION
21
SLEEVE LINE CONNECTION
26
T-FITTING LIFTING SYSTEM BRANCH-OFF
29
ELBOW FITTING 3/2-WAY VALVE,CONNECTION: "20",5 765577
32
GROMMET CLUTCH LINE TO BRACKET
35
HOSE LEAK LINE 4X6 MM, ORDER BY THE METER
35
PLASTIC PIPE RISING PIPE 4X6 MM
38
FITTING (PARTS KIT),LINE RUPTURE,5 909352K 169122
41
UNION NUT
44
GLAND , Replaced By: A0019901667
47
SLEEVE LEAK LINE
56
FITTING HYDRAULIC LINE TO BRACKET,K 130132
59
NUT FROM 3/2-WAY VALVE TO QUICK BREATHER VALVE,5 431227
62
VALVE (TEST VALVE),035318
66
ADAPTER FITTING CENTRAL AND REAR AXLES
68
NUT LOAD/NO-LOAD VALVE,CONNECTION: "20",5 727400
71
T-FITTING 3/2-WAY VALVE
74
TEST CONNECTION SOLENOID VALVE,CONNECTION: "20"
74
TEST CONNECTION
74
TEST CONNECTION SOLENOID VALVE,CONNECTION: "20"
74
TEST CONNECTION SOLENOID VALVE,CONNECTION: "20"
74
TEST CONNECTION SOLENOID VALVE,CONNECTION: "20"
78
GUIDE SIGN REAR AXLE AIR-SPRING BELLOWS PRESSURE, LEFT
78
GUIDE SIGN AT BRACKET
78
GUIDE SIGN AT BRACKET
78
GUIDE SIGN REAR AXLE AIR-SPRING BELLOWS PRESSURE, RIGHT
78
GUIDE SIGN AT BRACKET
78
GUIDE SIGN AT BRACKET
80
VALVE PNEUMATIC SUSPENSION BOSCH, PART IS ONLY OR ALSO SUPPLIED AS RECONDITIONED PART
80
VALVE TRAILING AXLE SELF-LEVELLING DEVICE
83
VALVE INTAKE
86
VALVE EXHAUST
86
VALVE , Replaced By: A0003282125
98
SCREW VALVE TO CAB M 8X85
101
SHIM LEVEL ADJUSTMENT VALVE TO SUBSTRUCTURE
104
LOCK WASHER CLAMP TO BRACKET AND TO PIPE
119
FITTING LINE CONNECTION
119
FITTING LINE CONNECTION, Replaced By: N000000006446
131
HOLLOW SCREW LINE CONNECTION
134
VALVE LEVEL ADJUSTMENT VALVE,CONNECTION: "10"
137
SEAL RING PRESSURE REGULATOR,CONNECTION: "23",5 161701
137
SEAL RING LINE CONNECTION
140
BREATHER FILTER. FILTER TRAILER CONTROL VALVE,CONNECTION: "4"
146
BALL SOCKET R.H. THREAD 255 MM
146
BALL SOCKET R.H. THREAD 116 MM
149
NUT
149
NUT , Replaced By: N304035008001
152
NUT FRONT AXLE LEVEL ADJUSTMENT
155
NUT L.H. THREAD
155
NUT , Replaced By: N304035008002
158
BALL SOCKET POWER CYLINDER TO LEVER
161
BALL STUD. BALL PIVOT PULL ROD TO BRACKET
168
LOCK WASHER CLAMP TO BRACKET AND TO PIPE
170
NUT , Replaced By: N304032008006
999
SEAL RING
999
SEAL RING
