Поз.
Артикул
Описание
11
BRACKET
15
BRACKET FUEL TANK PIPING
17
BRACKET BRACKET TO CONSOLE
20
BRACKET RING MOUNT CONNECTION
32
SCREW PUMP TO BRACKET
32
SCREW CAB FLOOR COVERING M 6X25
32
SCREW , Replaced By: N304017006016
32
SCREW CONTROL VALVE TO BRACKET
38
SCREW APPARATUS PLATE M 6X80
38
SCREW LONGITUDINAL DIFFERENTIAL LOCK VALVE TO BRACKET,5 963747
47
SCREW , Replaced By: N304017008021
53
WASHER BOOT TO CAB FLOOR
53
WASHER , Replaced By: N000433005304
56
WASHER COMPRESSED AIR LINE TO BRACKET
56
WASHER , Replaced By: N009021006208
65
NUT TWO-WAY VALVE TO BRACKET
68
NUT , Replaced By: N913004006001
68
NUT PUMP TO BRACKET
71
NUT , Replaced By: N913004008001
86
BRAKE HOSE BETWEEN THE LINES
86
BRAKE HOSE SPRING LOAD ACCUMULATOR UNIT, FROM IDENT NO. 036592 FOR USE WITH MERCEDES-BENZ BODY, FROM IDENT NO. 036521 NOT FOR USE WITH MERCEDES-BENZ BODY
86
BRAKE HOSE , Replaced By: A0004298735
86
BRAKE HOSE REAR AXLE,LEFT AND RIGHT
112
NUT INTERMEDIATE SPEED STOP
113
WASHER
116
NUT BRACKET TO SIDE MEMBER
118
WASHER COVERING TO BEARING BRACKET
122
BRAKE HOSE ACCELERATOR PEDAL CONNECTION
128
NUT FROM 3/2-WAY VALVE TO QUICK BREATHER VALVE,5 431227
130
WASHER STRUT TO EXHAUST PIPE AND TO SIDE MEMBER
130
WASHER , Replaced By: N000125015019
132
BRAKE HOSE , Replaced By: A0004299135
132
BRAKE HOSE FRONT AXLE
134
FITTING FITTING TO SUBSTRUCTURE
134
FITTING SHUTTLE VALVE
136
FITTING BETWEEN THE LINES
137
FITTING DELIVERY LINE TO FRAME
140
T-FITTING POWER STEERING
145
MUFFLER AT AIR COMPRESSOR
147
SCREW OIL-DIPSTICK GUIDE TUBE TO BRACKET
147
SCREW , Replaced By: N304017008016
148
LOCK WASHER CLAMP TO BRACKET AND TO PIPE
151
CONNECTION FITTING ENGINE AIR COMPRESSOR,CONNECTION: "15"
152
THRUST RING COMPRESSED AIR LINE TO AIR RESERVOIR AND TO T-FITTING
153
SEAL RING TO 18-MM-DIA. COMPRESSED AIR LINES
154
LINE ,077652
156
HOSE MUFFLER
158
CLAMP
161
TEST CONNECTION SOLENOID VALVE,CONNECTION: "20"
161
TEST CONNECTION SOLENOID VALVE,CONNECTION: "20"
161
TEST CONNECTION SOLENOID VALVE,CONNECTION: "20"
161
TEST CONNECTION SOLENOID VALVE,CONNECTION: "20"
161
TEST CONNECTION
164
PLUG
167
FITTING FROM 3/2-WAY VALVE TO PRESSURE CONTROL VALVE
167
FITTING , Replaced By: A0009977172
168
FITTING TEST CONNECTIONS
172
TEST CONNECTION
173
BRACKET TEST CONNECTION
174
SCREW PUMP TO BRACKET
174
SCREW , Replaced By: N304017006016
175
NUT , Replaced By: N913004006001
175
NUT PUMP TO BRACKET
176
FITTING AT BRACKET
179
NUT FROM 3/2-WAY VALVE TO QUICK BREATHER VALVE,5 431227
180
COUPLING SPRING-LOAD-ACCUMULATOR RELEASE/ EMERGENCY-RELEASE PRESSURE
182
WASHER COILED TUBE TO BRAKE LINE COUPLING SUPPORT
183
NUT FROM 3/2-WAY VALVE TO QUICK BREATHER VALVE,5 431227
185
T-FITTING EXHAUST-BRAKE POWER CYLINDER
188
WASHER
191
NUT LOAD/NO-LOAD VALVE,CONNECTION: "20",5 727400
