2633,3333 B/K - 624.048 - 52 SHEET METAL,AIR INTAKE
Поз.
Артикул
Описание
196
FRONT FENDER REAR RIGHT
203
REINFORCEMENT LEFT, TO BE ADAPTED DURING ASSEMBLY
210
SCREW , Replaced By: N304017008034
210
SCREW BRACKET TO CROSS CONNECTION STRUT
217
LOCK WASHER CLAMP TO BRACKET AND TO PIPE
224
WASHER BRACKET TO CONSOLE
231
SPLASH GUARD REAR FENDER
238
FRONT FENDER FRONT RIGHT
245
STIFFENING RIGHT
252
ROPE FENDER FLAP
252
ROPE , Replaced By: A3818810165
