Поз.
Артикул
Описание
100
PROPELLER SHAFT FROM TRANSMISSION TO TRANSFER CASE 650 MM, PART IS ONLY OR ALSO SUPPLIED AS RECONDITIONED PART
100
PROPELLER SHAFT , FIRST EXHAUST STOCK OF OLD PARTS UP TO IDENT NO. K 364932, Replaced By: A6564106802, +002A9424100031
100
PROPELLER SHAFT FROM TRANSMISSION TO TRANSFER CASE 650 MM, PART IS ONLY OR ALSO SUPPLIED AS RECONDITIONED PART
115
DRIVE FLANGE , Replaced By: A6564110311
115
DRIVE FLANGE , Replaced By: A3954111211
115
DRIVE FLANGE , Replaced By: A3954111011
115
DRIVE FLANGE STAGGERED TEETH
115
DRIVE FLANGE STAGGERED TEETH
118
UNIVERSAL JOINT CROSS WITH BUSHINGS, IF REQUIRED,ORDER LOCK RINGS ADDITIONALLY
118
UNIVERSAL JOINT CROSS , Replaced By: A9424100031
118
UNIVERSAL JOINT CROSS , Replaced By: A9404100031
118
UNIVERSAL JOINT CROSS WITH BUSHINGS, IF REQUIRED,ORDER LOCK RINGS ADDITIONALLY
121
GREASE NIPPLE
124
LOCK AS REQUIRED 2.10 MM
124
LOCK AS REQUIRED 3.25 MM
124
LOCK AS REQUIRED 2.00 MM
124
LOCK AS REQUIRED 3.10 MM
124
LOCK AS REQUIRED 2.20 MM
124
LOCK AS REQUIRED 2.90 MM
124
LOCK AS REQUIRED 3.30 MM
124
LOCK AS REQUIRED 3.20 MM
124
LOCK , Replaced By: A6564110673
124
LOCK AS REQUIRED 3.00 MM
127
SEAL RING PROTECTIVE TUBE 123X17 MM
127
SEAL RING PROTECTIVE TUBE 102.5X22 MM
127
SEAL RING PROTECTIVE TUBE 105X17 MM
130
GREASE NIPPLE
130
GREASE NIPPLE , Replaced By: N071412008102
139
SCREW STEERING SUPPORT TO FRAME M 14X50
142
LOCK WASHER BRACKET TO SIDE MEMBER,5 703114
145
NUT BRACKET TO SIDE MEMBER
200
PROPELLER SHAFT FROM PROPELLER SHAFT BEARING TO REAR AXLE I 1400 MM, PART IS ONLY OR ALSO SUPPLIED AS RECONDITIONED PART
200
PROPELLER SHAFT , Replaced By: A9734100202, +002A9734100031
215
DRIVE FLANGE , Replaced By: A6504110411
215
DRIVE FLANGE STAGGERED TEETH
218
UNIVERSAL JOINT CROSS WITH BUSHINGS
218
UNIVERSAL JOINT CROSS , Replaced By: A9734100031
221
GREASE NIPPLE
224
LOCK AS REQUIRED 1.65 MM
224
LOCK AS REQUIRED 1.80 MM
224
LOCK AS REQUIRED 1.85 MM
224
LOCK AS REQUIRED 1.70 MM
227
SEAL RING PROTECTIVE TUBE 95X14.5 MM
230
GREASE NIPPLE
230
GREASE NIPPLE , Replaced By: N071412008102
239
SCREW , Replaced By: A3609903101
239
SCREW MOUNTING USED FOR FRAME CONNECTION PARTS
242
LOCK WASHER FITTING TO BRACKET
245
NUT PROPELLER SHAFT TO COUPLING FLANGE
504
PROPELLER SHAFT FROM TRANSFER CASE TO REAR AXLE 1068 MM, PART IS ONLY OR ALSO SUPPLIED AS RECONDITIONED PART
504
PROPELLER SHAFT , Replaced By: A6564107302, +002A9424100031
504
PROPELLER SHAFT FROM PROPELLER SHAFT BEARING TO REAR AXLE I 1289 MM
515
DRIVE FLANGE , Replaced By: A6564110311
515
DRIVE FLANGE STAGGERED TEETH
515
DRIVE FLANGE STAGGERED TEETH
518
UNIVERSAL JOINT CROSS WITH BUSHINGS
518
UNIVERSAL JOINT CROSS , Replaced By: A9424100031
518
UNIVERSAL JOINT CROSS WITH BUSHINGS, IF REQUIRED,ORDER LOCK RINGS ADDITIONALLY
521
GREASE NIPPLE
524
LOCK AS REQUIRED 3.10 MM
524
LOCK AS REQUIRED 2.70 MM
524
LOCK AS REQUIRED 2.60 MM
524
LOCK AS REQUIRED 2.90 MM
524
LOCK AS REQUIRED 3.25 MM
524
LOCK AS REQUIRED 2.50 MM
524
LOCK AS REQUIRED 2.80 MM
524
LOCK AS REQUIRED 3.30 MM
524
LOCK AS REQUIRED 2.90 MM
524
LOCK AS REQUIRED 3.00 MM
524
LOCK AS REQUIRED 3.20 MM
524
LOCK , Replaced By: A6564110673
524
LOCK AS REQUIRED 3.00 MM
527
SEAL RING PROTECTIVE TUBE 123X17 MM
527
SEAL RING PROTECTIVE TUBE 105.6X12 MM
527
SEAL RING PROTECTIVE TUBE 102.5X22 MM
527
SEAL RING PROTECTIVE TUBE 105X17 MM
530
GREASE NIPPLE
530
GREASE NIPPLE , Replaced By: N071412008102
539
SCREW STEERING SUPPORT TO FRAME M 14X50
542
LOCK WASHER BRACKET TO SIDE MEMBER,5 703114
545
NUT BRACKET TO SIDE MEMBER
600
PROPELLER SHAFT , Replaced By: A6544103902, +002A9424100131
600
PROPELLER SHAFT , Replaced By: A3894103302
615
DRIVE FLANGE , Replaced By: A6544110511
615
DRIVE FLANGE STAGGERED TEETH
618
UNIVERSAL JOINT CROSS WITH BUSHINGS
618
UNIVERSAL JOINT , Replaced By: A9424100131
618
UNIVERSAL JOINT CROSS , Replaced By: A0004101628
621
GREASE NIPPLE
624
LOCK AS REQUIRED 2.00 MM
624
LOCK AS REQUIRED 2.20 MM
624
LOCK AS REQUIRED 2.10 MM
627
GASKET PROTECTIVE TUBE
633
SCREW PLUG PROTECTIVE TUBE
639
SCREW MOUNTING USED FOR FRAME CONNECTION PARTS
639
SCREW , Replaced By: A3609903101
642
LOCK WASHER FITTING TO BRACKET
645
NUT PROPELLER SHAFT TO COUPLING FLANGE
