Поз.
Артикул
Описание
5
BRACKET COOLING WATER HOSE TO OIL FILLER PIPE BRACKET,5 509582
5
BRACKET COOLING WATER HOSE TO OIL FILLER PIPE BRACKET,5 509581
8
SCREW OIL FILLER NECK TO BRACKET,5 458408
11
WASHER SUPPORTING RAIL TO SUPPORT,5 429712
14
BRACKET COOLING WATER HOSE TO OIL FILLER PIPE BRACKET
17
CLAMP HOSE TO FIRE WALL
20
SHEET METAL SCREW
20
SHEET METAL SCREW , Replaced By: N007981003214
23
BRACKET COOLING WATER LINE TO FIRE WALL
26
CLAMP FEED LINE TO THERMOSTAT
29
SHEET METAL SCREW BRACKET TO CAB
32
BRACKET HOSE TO FIRE WALL
35
SHEET METAL SCREW BRACKET TO CAB,5 906887
38
BRACKET HOSE TO FIRE WALL
41
SHEET METAL SCREW BRACKET TO FIRE WALL 6.3X22
44
WASHER COVER PLATE TO COVER PLATE
47
BRACKET DE-AERATION LINE, UP TO IDENT NO.5 448662, FROM IDENT NO. 5 448663 SEE UNIT MICROFICHE
50
SCREW PROTECTIVE PLATE TO EXHAUST MUFFLER
59
SCREW , Replaced By: N304017008018
59
SCREW SUPPORT TO FENDER
68
PIPE SOCKET (HEATING LINE),FROM ENGINE TO HEATER
71
GASKET PIPE SOCKET TO CYLINDER HEAD, UP TO IDENT NO.5 448662, FROM IDENT NO. 5 448663 SEE UNIT MICROFICHE
71
GASKET , Replaced By: A3662030380
74
HOSE (HEATING LINE),FROM ENGINE TO HEATER
77
PIPE (HEATING LINE),FROM ENGINE TO HEATER
80
HOSE (HEATING LINE),FROM ENGINE TO HEATER
83
CLAMP HOSE TO SUCTION LINE AND TO OIL TANK 20-32X13 MM
83
CLAMP HOSE TO FITTING AND TO OIL TANK
83
CLAMP , Replaced By: N000000000667
83
CLAMP HOSE TO FITTING AND TO OIL TANK 16-27X13 MM
89
HOSE (HEATING LINE) FROM EXPANSION TANK TO HEATER
92
CLAMP HOSE TO FITTING AND TO OIL TANK 16-27X13 MM
92
CLAMP HOSE TO FITTING AND TO OIL TANK
95
CLAMP HOSE TO SUCTION LINE AND TO OIL TANK 20-32X13 MM
95
CLAMP , Replaced By: N000000000667
