Поз.
Артикул
Описание
5
PRESSURE REGULATORBOSCH
5
PRESSURE REGULATORWABCO
5
PRESSURE REGULATORKNORR
5
PRESSURE REGULATORBOSCH, PART IS ONLY OR ALSO SUPPLIED AS RECONDITIONED PART
5
PRESSURE REGULATORWABCO, PART IS ONLY OR ALSO SUPPLIED AS RECONDITIONED PART
5
PRESSURE REGULATORKNORR 90310
8
REPAIR KIT PRESSURE REGULATOR KNORR
8
REPAIR KIT SEAL RING BOSCH,209
8
REPAIR KIT DIAPHRAGM PART BOSCH,209
8
REPAIR KITTO 002 431 84 06, KNORR 90310
8
REPAIR KIT PRESSURE REGULATOR WABCO
11
SCREW REAR AXLE REGULATING SOLENOID VALVE
14
NUT , Replaced By: N913004008001
18
FITTING AIR DEHYDRATOR,CONNECTION: "10",5 433280
19
FITTING LINE CONNECTION
19
FITTING LINE CONNECTION
20
FITTING LINE CONNECTION
22
SCREW. UNION SCREW , Replaced By: A0009973734
22
SCREW. UNION SCREW LINE CONNECTION
24
SCREW. UNION SCREW LINE CONNECTION
28
NUT CHECK VALVE TO AIR RESERVOIR
30
THRUST RING , THE OLD PART MUST NO LONGER BE INSTALLED, Replaced By: A0009940203
30
THRUST RING CHECK VALVE TO AIR RESERVOIR
32
O-RING CHECK VALVE TO AIR RESERVOIR
36
SEAL RING LINE CONNECTION
38
SEAL RING AIR RESERVOIR,CONNECTIONS: "24,34"
42
HOSE PRESSURE REGULATOR,CONNECTION: "30", ORDER BY THE METER
46
CLAMP HOSE TO SUCTION LINE AND TO OIL TANK 20-32X13 MM
53
AIR DEHYDRATOR WITH PRESSURE REGULATOR KNORR
53
AIR DEHYDRATORBOSCH,5 937586
53
AIR DEHYDRATOR WITH PRESSURE REGULATOR BOSCH
53
AIR DRIERKNORR,5 937586
53
AIR DEHYDRATORWABCO,5 937586 PART IS ONLY OR ALSO SUPPLIED AS RECONDITIONED PART
56
AIR CLEANER COMPLETE TO BOSCH,KNORR
56
AIR CLEANER COMPLETE KNECHT:TO BOSCH,KNORR
59
SEAL RINGWABCO
62
GASKET KITWABCO
62
GASKET KIT SEAL RINGS KNORR,5 937586
62
GASKET KITKNORR
65
REPAIR KIT PRESSURE REGULATOR BOSCH,K 126821
65
REPAIR KIT PRESSURE REGULATOR KNORR,K 126821
71
BRACKET AIR DEHYDRATOR
89
SCREW , Replaced By: N308676012012
89
SCREW. HEXAGON HEAD BOLT VALVE TO BRACKET
92
SPRING WASHER CAB FLOOR
92
SPRING WASHER AIR COMPRESSOR LINE TO ENGINE,5 812731 - 5 8174215 936366 - 5 999999K 000001N 817422K 126820
98
SCREW CROSS MEMBER TO FRAME M 10X30
104
NUT , Replaced By: N910113010002
104
HEXAGON NUT
106
FITTING AIR DEHYDRATOR
108
FITTING
114
THRUST RING CHECK VALVE TO AIR RESERVOIR
116
O-RING CHECK VALVE TO AIR RESERVOIR
118
NUT CHECK VALVE TO AIR RESERVOIR
124
SCREW. UNION SCREW LINE CONNECTION
126
SCREW. UNION SCREW LINE CONNECTION
126
SCREW. UNION SCREW , Replaced By: A0009973734
128
CONNECTOR BLEEDING
128
CONNECTOR 90 DEG. OFFSET
130
PLASTIC PIPE FUEL LINE 16X2 MM, ORDER BY THE METER
130
HOSE , Replaced By: A0009872927
