Поз.
Артикул
Описание
101
BRACKET FRAME MOUNTED CABLE HARNESS TO CAB
103
RIVET BRACKET TO CAB
105
BRACKET BREATHER LINE TO SIDE MEMBER
107
SCREW BRACKET TO CROSS CONNECTION STRUT
107
SCREW , Replaced By: N304017008034
109
NUT , Replaced By: N913004008001
111
BRACKET CABLE HARNESS MOUNTING
113
SPRING WASHER ALTERNATOR CONNECTION D+
115
NUT TACHOGRAPH TO BRACKET
117
SPRING WASHER , Replaced By: N000137008212
117
SPRING WASHER ELECTRIC CABLE TO ALTERNATOR
117
SPRING WASHER , Replaced By: N000137008204
117
SPRING WASHER PROTECTIVE PLATE TO EXHAUST MUFFLER
117
SPRING WASHER HEATER PLUG CABLE HARNESS
117
SPRING WASHER ALTERNATOR CONNECTION D+
117
SPRING WASHER ALTERNATOR CONNECTION W
119
NUT BALL PIVOT TO LEVER
119
NUT TACHOGRAPH TO BRACKET
119
NUT BOOT TO AIR DUCT AND TO AIR CLEANER
119
NUT
121
WASHER , Replaced By: N000125008443
121
WASHER EXHAUST MUFFLER TO STRAP
123
BRACKET LINE MOUNTING
123
BRACKET LINE MOUNTING
125
BRACKET CABLE HARNESS
128
SCREW END PIECE TO EXHAUST PIPE M 10X25
131
NUT STRAP TO BRACKET
131
NUT , Replaced By: N910113010000
134
WASHER BRACKET TO LEFT SIDE MEMBER
140
BRACKET , Replaced By: A3274925819
140
BRACKET , Replaced By: A6735460443
140
BRACKET FEED AND RETURN LINES TO RETARDER 110 MM LANG, TO BE ADAPTED DURING ASSEMBLY
140
BRACKET DELIVERY AND SUCTION LINES TO ENGINE, FRONT
140
BRACKET DELIVERY AND SUCTION LINES TO ENGINE, FRONT
140
BRACKET DELIVERY AND SUCTION LINES TO ENGINE, FRONT
141
BRACKET OIL LINE MOUNTING
146
SCREW BRACKET TO SIDE MEMBER
146
SCREW , Replaced By: N308676012012
146
SCREW. HEXAGON HEAD BOLT VALVE TO BRACKET
152
NUT SUPPORT TO SIDE MEMBER
152
NUT STRAP TO BRACKET
152
NUT , Replaced By: N910113010000
155
CLAMP , Replaced By: A0005462675
155
CLAMP BATTERY CABLE TO FRAME SIDE MEMBER NEAR TRANSMISSION
164
SCREW BRACKET TO CROSS MEMBER
164
SCREW , Replaced By: N304017006026
164
SCREW , Replaced By: N304017006026
164
SCREW , Replaced By: N304014006004
167
WASHER COMPRESSED AIR LINE TO BRACKET, Replaced By: N000125006449
167
WASHER COMPRESSED AIR LINE TO BRACKET, Replaced By: N000125006449
170
NUT , Replaced By: N913004006001
170
NUT PUMP TO BRACKET
170
NUT PUMP TO BRACKET
173
SCREW BRACKET TO SIDE MEMBER
176
WASHER RADIATOR TO RUBBER MOUNTING
176
WASHER , Replaced By: N000125015019
176
WASHER , Replaced By: N000125010532
176
WASHER STRUT TO EXHAUST PIPE AND TO SIDE MEMBER
176
WASHER , Replaced By: N009021008213
176
WASHER BRACKET TO LEFT SIDE MEMBER
179
NUT , Replaced By: N910113010000
179
NUT STRAP TO BRACKET
999
ELECTRIC CABLE FROM CHASSIS/CAB PLUG-CONNECTION TO DUMPER TELL-TALE LAMP
999
ELECTRIC CABLE FROM CHASSIS/CAB PLUG-CONNECTION TO DUMPER TELL-TALE LAMP
999
SWITCH SUPPLY PRESSURE
