Поз.
Артикул
Описание
5
PARABOLIC CONTROL ARM
5
PARABOLIC CONTROL ARM ,5 407667
8
SPRING BOLTM 12X90
8
SPRING BOLT ,5 227450
11
SHIM BETWEEN THE SPRING LEAVES, TO BE ADAPTED DURING ASSEMBLY
11
SHIM BETWEEN THE SPRING LEAVES, TO BE ADAPTED DURING ASSEMBLY
11
SHIM , Replaced By: A9703210184
11
SHIM , Replaced By: A9703210184
17
HEXAGON NUT. NUT SPRING BOLT
17
NUT , Replaced By: N910113012005
20
BUSHING SPRING EYE,FRONT
20
BUSHING SPRING EYE,REAR
20
BUSHING SPRING EYE,REAR
23
RUBBER BUFFER BETWEEN THE SPRING EYES
26
SPRING CLAMP ,5 940410
27
WEB AT SPRING LEAF NO.2
29
RIVET SPRING CLAMP TO SPRING LEAF,5 407667
32
SPACER TUBE SPRING CLAMP
35
SCREW SPRING CLAMP,5 533057
38
NUT END PIECE TO EXHAUST PIPE
41
THRUST WASHER REAR SPRING TO REAR SPRING FRONT BRACKET
44
NUT INTERMEDIATE LEVER TO STEERING SUPPORT
44
NUT , Replaced By: N910113018004
47
SHACKLE (SPRING SHACKLE)
50
BUSHING REAR SPRING TO REAR SPRING REAR BRACKET
53
SCREW CONTROL ARM TO REAR SPRING REAR BRACKET
56
NUT , Replaced By: N910113018004
56
NUT INTERMEDIATE LEVER TO STEERING SUPPORT
59
SHIM CONTROL ARM TO REAR AXLE
59
SHIM REAR SPRING
59
SHIM CONTROL ARM TO REAR AXLE
62
DOWEL PIN (CENTERING CONE),5 361887, Replaced By: A9303230574
62
DOWEL PIN FRONT AXLE TO FRONT SPRINGS
62
DOWEL PIN BETWEEN SPRING AND FRONT AXLE
62
CENTERING BOLT (CENTERING CONE),5 361887
65
PLATE REAR SPRING TO REAR AXLE
68
U-BOLT
68
U-BOLT REAR SPRING TO REAR AXLE 320 MM
68
U-BOLT REAR SPRING TO REAR AXLE 400 MM,5 201988
68
U-BOLT REAR SPRING TO REAR AXLE 340 MM
71
WASHER FRONT SPRINGS TO FRONT AXLE
74
NUT FRONT SPRINGS WITH TORSION BAR TO FRONT AXLE
108
RUBBER MOUNTING AXLE STOP
999
PULL ROD PNEUMATIC SUSPENSION CONTROL
999
NUT BALL SOCKET TO ROD
999
NUT
999
SCREW PLUGROCKINGER,TYP 59 U150
999
SCREW PLUGROCKINGER TYP 59 G140,59 G150, Replaced By: N007604012105
999
SEAL RING LINE CONNECTION
999
BRACKET REDUCTION VALVE, SIMPLE PART-PLEASE HAVE SHOP MADE
999
VALVE (REDUCTION VALVE) 1,15:1
999
VALVE (THROTTLE CHECK VALVE)
999
REPAIR KIT REDUCTION VALVE
999
BALL JOINT LEFT-HAND THREAD,BALL DIAMETER 10 MM
999
BALL JOINT TRAVEL SENSOR
