Поз.
Артикул
Описание
285
WIRE CABLE
290
PULL ROD FROM CONTROL SHAFT BEARING TO INTERMEDIATE LEVER 400 MM, TO BE ADAPTED DURING ASSEMBLY
295
TURNBUCKLE
300
BALL SOCKET PULL ROD TO INTERMEDIATE LEVER
305
SNAP RING SPRING-LOADED PUSH ROD
310
CIRCLIP. SECURING CLIP BALL SOCKET TO ROD
315
BRACKET
315
BRACKET , THE OLD PART MUST NO LONGER BE INSTALLED, Replaced By: A6732682140
320
BALL PIVOT CONTROL LEVER TO INJECTION PUMP LEVER, Replaced By: N000000004467
320
SCREW CONTROL LEVER TO INJECTION PUMP LEVER
325
NUT BALL PIVOT TO LEVER
330
NUT , Replaced By: N913004006001
330
NUT PUMP TO BRACKET
335
NUT L.H. THREAD
340
BRACKET WIRE CABLE
340
BRACKET , THE OLD PART MUST NO LONGER BE INSTALLED, Replaced By: A6732682740
340
BRACKET , THE OLD PART MUST NO LONGER BE INSTALLED, Replaced By: A6732682540
345
SCREW BRACKET TO SIDE MEMBER
345
SCREW , Replaced By: N304017010002
350
NUT STRAP TO BRACKET
350
NUT , Replaced By: N910113010000
355
BRACKET WIRE CABLE
355
BRACKET WIRE CABLE
355
BRACKET , THE OLD PART MUST NO LONGER BE INSTALLED, Replaced By: A6732682240
355
BRACKET , THE OLD PART MUST NO LONGER BE INSTALLED, Replaced By: A6762680240
360
LOCK WASHERROCKINGER TYP 59 G140,59 G150
365
SCREW , Replaced By: N304017016011
365
SCREWM 16X25
370
SCREW , Replaced By: N007985006580
370
SCREW APPARATUS PLATE TO CAB,K 062140
375
LOCK WASHER CONTROL LEVER TO INJECTION PUMP LEVER
380
NUT , Replaced By: N913004006001
380
NUT PUMP TO BRACKET
385
CLAMP WIRE CABLE TO SIDE MEMBER AND TO TRANSMISSION
390
SCREW CLAMP MOUNTING M 6X16
390
SCREW , Replaced By: N000000001146
395
NUT PUMP TO BRACKET
395
NUT , Replaced By: N913004006001
400
CLAMP WIRE CABLE TO SIDE MEMBER AND TO TRANSMISSION
405
SCREW CLAMP MOUNTING M 6X16
405
SCREW , Replaced By: N000000001146
410
NUT PUMP TO BRACKET
410
NUT , Replaced By: N913004006001
415
LOOM TIE LINE MOUNTING
420
BRACKET , THE OLD PART MUST NO LONGER BE INSTALLED, Replaced By: A6732601462
420
BRACKET (REVERSING LEVER)
425
BRACKET (REVERSING LEVER),5 538555
425
BRACKET (REVERSING LEVER),5 378420
425
BRACKET (REVERSING LEVER)
425
BRACKET , THE OLD PART MUST NO LONGER BE INSTALLED, Replaced By: A6762600162
425
BRACKET , THE OLD PART MUST NO LONGER BE INSTALLED, Replaced By: A6762600262
425
BRACKET (REVERSING LEVER),5 538556
430
SCREW , Replaced By: N304017008021
430
SCREW PIPE CLAMP
435
SCREW SHACKLE TO CONSOLE
440
WASHER BRACKET TO SIDE MEMBER
445
LOCK WASHERROCKINGER TYP 59 G140,59 G150
450
NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET, Replaced By: N910113008003
450
NUT , Replaced By: N913004008001
455
THREADED INSERT BRACKET TO TRANSMISSION
460
NUT SUPPORT TO SIDE MEMBER
465
PULL ROD LOAD SENSOR CONTROL, TO BE ADAPTED DURING ASSEMBLY
470
BALL SOCKET PULL ROD TO INTERMEDIATE LEVER
475
SNAP RING SPRING-LOADED PUSH ROD
480
CIRCLIP. SECURING CLIP BALL SOCKET TO ROD
485
NUT BALL PIVOT TO LEVER
490
LEVER GEARSHIFT,TRANSMISSION
490
LEVER , THE OLD PART MUST NO LONGER BE INSTALLED, Replaced By: A6732600637
495
LEVER , THE OLD PART MUST NO LONGER BE INSTALLED, Replaced By: A6762600537
495
LEVER GEARSHIFT,TRANSMISSION
500
BALL PIVOT , Replaced By: A3129910120
500
BALL PIVOT LEVER
500
BALL PIVOT LEVER
505
PIN
510
BUSHING
515
WASHER , Replaced By: N000433010510
520
LOCK PLATE LEVER TO BRACKET
525
PULL ROD LOAD SENSOR CONTROL, TO BE ADAPTED DURING ASSEMBLY
525
PULL ROD AT CONTROL LEVER, TO BE ADAPTED DURING ASSEMBLY
530
NUT BALL PIVOT TO LEVER
535
BALL SOCKET PULL ROD TO INTERMEDIATE LEVER
540
CIRCLIP. SECURING CLIP BALL SOCKET TO ROD
545
CONNECTOR FROM LEVER TO VALVE BODY ASSEMBLY
545
CONNECTOR FROM LEVER TO VALVE BODY ASSEMBLY
545
CONNECTOR , THE OLD PART MUST NO LONGER BE INSTALLED, Replaced By: A6762600175
550
BUSHING FROM LEVER TO VALVE BODY ASSEMBLY
555
LOCK PLATE RELEASE LEVER TO SHAFT
560
CLAMP , Replaced By: N071555090502
560
CLAMP INTERMEDIATE PIPE TO PARTICLE FILTER
565
SCREW , Replaced By: N304017010002
565
SCREW BRACKET TO SIDE MEMBER
570
NUT , Replaced By: N910113010000
570
NUT STRAP TO BRACKET
999
BRACKET FRONT EXHAUST PIPE TO BRACKET,5 528483
999
WIRE CABLE GEARSHIFT MECHANISM
999
BRACKET FRONT EXHAUST PIPE TO BRACKET,5 528483
999
BRACKET ,5 337343 FIRST EXHAUST STOCK OF OLD PARTS UP TO IDENT NO. 5 478323, Replaced By: A6744913641, +001A6744913541, +002N000933010145, +002N007349010003, +002N913004010008
999
BRACKET , FIRST EXHAUST STOCK OF OLD PARTS UP TO IDENT NO. 5 422640
999
BOOT , Replaced By: A6732600172
999
WIRE CABLE GEARSHIFT MECHANISM
999
STOP FULL THROTTLE
