Поз.
Артикул
Описание
5
CROSS MEMBER REAR SPRING BRACKET NO.9
20
SPRING BRACKET REAR SPRING FRONT BRACKET
35
CONSOLE BODY MOUNTING
38
CONSOLE SPRING TO CAB
41
BEARING SHACKLE TO FRAME
44
CROSS MEMBER SHOCK ABSORBER
50
SUPPORT AIR SPRING BELLOWS,TOP NO.12
53
CROSS MEMBER IN FRONT OF REAR CROSS MEMBER
56
SPRING BRACKET (REAR SPRING BRACKET),REAR,5 905404
56
SPRING BRACKET (REAR SPRING BRACKET),REAR,5 905404
59
BUSHING SPRING EYE,REAR,5 905404
62
SCREW BRACKET TO SIDE MEMBER
62
SCREW BRACKET TO SIDE MEMBER M 14X55,5 543914
62
SCREW SUPPORT TO SIDE MEMBER M 14X45
65
NUT , Replaced By: N910113014001
65
NUT BRACKET TO SIDE MEMBER
80
CROSS MEMBER (REAR CROSS MEMBER),H.D., NOT INCLUDED IN RANGE OF DELIVERY OF FRAME
83
SCREW , Replaced By: N308676014020
83
SCREW BRACKET TO SIDE MEMBER M 14X1.5X35
86
NUT , Replaced By: N910113014001
86
NUT BRACKET TO SIDE MEMBER
89
CONSOLE BODY MOUNTING
92
SCREW BRACKET TO SIDE MEMBER
92
SCREW , Replaced By: N304017010002
95
WASHER , Replaced By: N000125010532
95
WASHER RADIATOR TO RUBBER MOUNTING
98
NUT STRAP TO BRACKET
98
NUT , Replaced By: N910113010000
