Поз.
Артикул
Описание
5
BEARING BRACKET BRAKE PEDAL
8
STUD
11
GASKET CLUTCH PEDAL BEARING BRACKET
11
GASKET , Replaced By: A6452940280
14
SPRING WASHER BRAKE SHOE WITH LINING
17
NUT BATTERY CASE
20
STOP CLUTCH PEDAL
23
STOP CLUTCH PEDAL STOP
26
NUT BATTERY CASE
29
SCREW CLAMP TO BRACKET
32
NUT PUMP TO BRACKET
35
STOP
38
PEDAL (CLUTCH PEDAL)
41
NEEDLE BEARING CLUTCH PEDAL
44
PIN CLUTCH PEDAL39 MM(M10) TO A6952907216
47
NUT AIR CLEANER ELEMENT
50
PAD , Replaced By: A1072910182
53
PIN CLUTCH PEDAL TO BEARING BRACKET
56
WASHER CLUTCH PEDAL TO BEARING BRACKET
59
LOCK , Replaced By: A6732920073
62
SCREW BATTERY POS. CABLE TO BRACKET,PB004444
65
WASHER PLUG SOCKET TO BRACKET
68
BEARING BRACKET
68
ROD , Replaced By: A3822908419
71
NUT GEARSHIFT LEVER KNOB TO GEARSHIFT LEVER
74
SPRING RETAINER SPRING TO PUSH ROD
77
SPRING CLUTCH PEDAL RESET,B 974885
80
SPRING RETAINER SPRING TO PUSH ROD
83
CLIP SPRING TO PUSH ROD
86
WASHER BRACKET TO FENDER BRACKET
89
LOCK RING PUSH ROD TO PEDAL
92
LOCK PLATE
