Поз.
Артикул
Описание
5
GROMMET , Replaced By: A3219970081
5
GROMMET
8
BRAKE HOSE FROM QUICK-RELEASE VALVE TO COMBINATION CYLINDER,RIGHT
8
BRAKE HOSE LEFT AND RIGHT FRONT WHEEL BRAKE CYLINDERS
8
BRAKE HOSE LEFT AND RIGHT FRONT WHEEL BRAKE CYLINDERS
8
BRAKE HOSE LEFT AND RIGHT FRONT WHEEL BRAKE CYLINDERS
11
LINE RIGHT FRONT WHEEL BRAKE CYLINDER 12X1 MM
11
LINE LEFT FRONT WHEEL BRAKE CYLINDER 12X1 MM
14
UNION NUT LINE CONNECTION, Replaced By: N000000006239
17
GLAND , Replaced By: A0019901967
20
BRAKE HOSE , Replaced By: A3864207548
20
BRAKE HOSE FROM RELAY VALVE,CONNECTION "2",TO LEFT SPRING-LOAD ACCUMULATOR
20
BRAKE HOSE FROM COMPRESSED AIR LINE TO REAR WHEEL BRAKE CYLINDER,D 030552
20
BRAKE HOSE , Replaced By: A3864207348
20
BRAKE HOSE FROM BULKHEAD FITTING TO REAR AXLE COMBINATION CYLINDER
20
BRAKE HOSE FROM COMPRESSED AIR LINE TO REAR WHEEL BRAKE CYLINDER
20
BRAKE HOSE FROM BULKHEAD FITTING TO REAR AXLE COMBINATION CYLINDER
20
BRAKE HOSE FROM COMPRESSED AIR LINE TO REAR WHEEL BRAKE CYLINDER,D 030552
20
BRAKE HOSE FROM RELAY VALVE,CONNECTION "2",TO LEFT SPRING-LOAD ACCUMULATOR
23
BRACKET FUEL LINE TO SIDE MEMBER
23
BRACKET , Replaced By: A3812950440
29
SCREW CLAMP TO BRACKET
34
WASHER BRACKET TO INJECTION PUMP
35
NUT , Replaced By: N913004006001
41
SCREW LINES TO BRACKET
44
HEXAGON NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET
47
CLAMP
50
CLAMP STAY TO BRACKET
53
SCREW MOUNTING CLAMP TO BRACKET AND TO FRAME
56
WASHER TRAILER PLUG SOCKET TO BRACKET
59
HEXAGON NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET
62
BRACKET AT TRANSMISSION,B 965920
70
BRACKET AT CROSS MEMBER,D 030553
74
CLAMP , Replaced By: A3129952420
77
SCREW CLAMP TO BRACKET
77
SCREW PROPELLER SHAFT BEARING TO CROSS MEMBER
89
NUT BRACKET TO CROSS MEMBER
89
NUT , Replaced By: N913004006001
91
CONNECTION FITTING ,TB108828
92
SWITCH SUPPLY PRESSURE,5 966147
93
T-FITTING FITTING,5 461950
95
BRACKET LINE MOUNTING
95
BRACKET , Replaced By: A3454288540
98
CLAMP PEDAL BEARING BRACKET,1B 961216
98
CLAMP BRAKE HOSE BRACKET
98
CLAMP BATTERY CABLE TO BRACKET
101
SCREW CLAMP TO BRACKET
104
LOCK WASHER CABLE TO FUSE BOX
107
NUT
110
CONNECTION FITTING
113
BRAKE HOSE , Replaced By: N071435006002
116
GLAND , Replaced By: A0019901667
119
UNION NUT
122
FITTING , Replaced By: A0019909871
125
CONNECTION FITTING ,TB108828
128
BRACKET COMPRESSED AIR LINE TO BRAKE CYLINDER
131
CLAMP DELIVERY AND SUCTION LINES TO ENGINE, FRONT
131
CLAMP DELIVERY AND SUCTION LINES TO FRAME 12/15
131
CLAMP DELIVERY AND SUCTION LINES TO FRAME 12/15
134
SCREW CONTROL UNIT
137
WASHER PLUG SOCKET TO BRACKET
140
NUT
143
LOCK WASHER CABLE TO FUSE BOX
146
TEST CONNECTION SOLENOID VALVE,CONNECTION: "20"
146
TEST CONNECTION TIRE INFLATING CONNECTION KNORR
146
TEST CONNECTION SOLENOID VALVE,CONNECTION: "20"
146
TEST CONNECTION
146
TEST CONNECTION SOLENOID VALVE,CONNECTION: "20"
146
TEST CONNECTION SOLENOID VALVE,CONNECTION: "20"
146
TEST CONNECTION SOLENOID VALVE,CONNECTION: "20"
146
TEST CONNECTION SOLENOID VALVE,CONNECTION: "20"
146
TEST CONNECTION SOLENOID VALVE,CONNECTION: "20"
146
TEST CONNECTION SOLENOID VALVE,CONNECTION: "20"
146
TEST CONNECTION SOLENOID VALVE,CONNECTION: "20"
146
TEST CONNECTION SOLENOID VALVE,CONNECTION: "20"
146
TEST CONNECTION SOLENOID VALVE,CONNECTION: "20"
147
ELBOW FITTING DIAPHRAGM CYLINDER,CONNECTION: "1,11"
148
NUT LOAD/NO-LOAD VALVE,CONNECTIONS: "10,20"
149
T-FITTING DIAPHRAGM CYLINDER,CONNECTION: "11",5 272559
149
T-FITTING DIAPHRAGM CYLINDER,CONNECTION "1"
152
NUT LOCKING VALVE TO TRAILER CONTROL VALVE,CONNECTION: "42"
155
SEAL RING LOAD/NO-LOAD VALVE,CONNECTION: "20"
158
THRUST RING LOAD/NO-LOAD VALVE,CONNECTION: "20"
161
T-FITTING AIR RESERVOIR,CONNECTION: "31"
161
T-FITTING TRAILER CONTROL VALVE,CONNECTION: "1"
164
NUT LOAD/NO-LOAD VALVE,CONNECTIONS: "10,20"
167
SEAL RING LOAD/NO-LOAD VALVE,CONNECTION: "20"
170
THRUST RING LOCKING VALVE
173
HOLLOW SCREW LINE CONNECTION TO TRANSMISSION
174
HOLLOW SCREW FOUR-CIRCUIT PROTECTIVE VALVE, CONNECTION: "24"
176
SEAL RINGTO 006 997 00 72
179
HOLLOW SCREW FITTING LOCKING VALVE,CONNECTION: "11"
180
HOLLOW SCREW FITTING RELAY VALVE,CONNECTION "20",LEFT
182
SEAL RINGTO 006 997 00 72
185
CONNECTOR SOLENOID VALVE,CONNECTION: "2" TOA388 997 81 36 / 88 36
191
SEAL RING PRESSURE REGULATOR,CONNECTION: "23",5 161701
