Поз.
Артикул
Описание
20
BRACKET EXHAUST MUFFLER
23
BRACKET EXHAUST MUFFLER
29
CONSOLE REAR EXHAUST MUFFLER 276 MM
32
CONSOLE REAR EXHAUST MUFFLER 126 MM
53
SCREW , Replaced By: N910105010009
53
SCREW PROTECTIVE PLATE TO EXHAUST MUFFLER
62
NUT , Replaced By: N910113010000
62
NUT EXHAUST PIPE TO SIDE MEMBER
65
SCREW EXHAUST PIPE TO BRACKET
65
SCREW , Replaced By: N308676012013
68
NUT FRONT SPRING FRONT BRACKET TO SIDE MEMBER
68
NUT STRAP TO SUPPORT
72
STRAP EXHAUST MUFFLER TO BRACKET
119
BRACKET TAIL PIPE
152
CLAMP REAR EXHAUST PIPE TO BRACKET
155
SCREW STRUT TO FRAME, LEFT
155
SCREW EXHAUST PIPE TO BRACKET
158
NUT , Replaced By: N910113010000
158
NUT EXHAUST PIPE TO SIDE MEMBER
161
SCREW STRUT TO SUPPORT
161
SCREW BRACKET TO BELL HOUSING
167
NUT , Replaced By: N910113010000
167
NUT EXHAUST PIPE TO SIDE MEMBER
170
HEXALOBULAR BOLT TRAVEL SENSOR TO BRACKET,K 186868
170
SCREW , Replaced By: N910143008021
170
SCREW EXHAUST MUFFLER TO STRAP
173
WASHER , Replaced By: N000125008443
176
NUT BRACKET TO BRACKET
176
NUT , Replaced By: N913004008001
