Поз.
Артикул
Описание
5
STOPPING SOLENOID24 V
5
STOPPING SOLENOID24 V
5
STOPPING SOLENOID
5
STOPPING SOLENOID , EXHAUST STOCK OF OLD PARTS UP TO ENGINE 771777, Replaced By: A4420660102
5
STOPPING SOLENOID , EXHAUST STOCK OF OLD PARTS UP TO ENGINE 011455, Replaced By: A4440660202
5
STOPPING SOLENOID , Replaced By: A4420660202
5
STOPPING SOLENOID , EXHAUST STOCK OF OLD PARTS UP TO ENGINE 421,422,441,442 771777 444 015780 447 054642, Replaced By: A4420660102
5
STOPPING SOLENOID , Replaced By: A4030660102
14
NUT FROM CONTROL LEVER TO INTERMEDIATE SHAFT AT ENGINE
14
NUT
14
NUT , Replaced By: N304035008001
23
KNOB
44
SPACER RING
44
SPACER RING
47
SCREW PUMP TO BRACKET
47
SCREW COVER PLATE TO BRACKET
47
HEXAGON HEAD BOLT
47
HEXALOBULAR BOLT. SCREW LINE MOUNTING M 6X30
47
SCREW , Replaced By: N000000001479
47
SCREW , Replaced By: N304017006016
47
SCREW , Replaced By: N304017006018
47
SCREW STOPPING MAGNET TO BRACKET M 5X14
50
WASHER , Replaced By: N000433005304
50
WASHER BOOT TO CAB FLOOR
50
WASHER SWITCH TO FIRE WALL
65
BRACKET STOPPING MAGNET
65
BRACKET STOPPING MAGNET
65
BRACKET STOPPING MAGNET
65
BRACKET STOPPING MAGNET
65
BRACKET STOPPING MAGNET
65
BRACKET
65
BRACKET STOPPING MAGNET
65
BRACKET STOPPING MAGNET
65
BRACKET STOPPING MAGNET
65
BRACKET STOPPING MAGNET,694973
65
BRACKET STOPPING MAGNET
65
BRACKET , EXHAUST STOCK OF OLD PARTS UP TO ENGINE 020532, Replaced By: A4440662740
65
BRACKET , Replaced By: A4420662640
80
BRACKET STOPPING MAGNET
89
BRACKET BEARING TUBE
95
SCREW LICENSE PLATE TO BRACKET
95
SCREW STEERING COLUMN MOUNTED SWITCH PLUGCONNECTION
95
SCREW PUMP TO BRACKET
95
SCREW FROM BACK-UP LAMP TO REAR CROSS MEMBER
95
HEXAGON HEAD BOLT
95
COMBINATION BOLT , UP TO TRANSMISSION: 023 766040 UP TO CHASSIS: 009860
95
HEXAGON HEAD BOLT. SCREW BATTERY MOUNTING M5X12
95
SCREW LEVER TO SHAFT
95
SCREW COVER PLATE TO BRACKET
95
SCREW , Replaced By: N304017006016
95
SCREW , Replaced By: N304017006020
95
SCREW , Replaced By: N304017006018
95
SCREW , Replaced By: N304017005002
95
SCREW , Replaced By: N304017005011
95
SCREW COVER PLATE TO COVER PLATE M 6 X 12
98
WASHER , Replaced By: N000433005304
98
WASHER BOOT TO CAB FLOOR
98
WASHER SEALING WASHER AND CYLINDER HEAD COVER MOUNTING
98
WASHER SWITCH TO FIRE WALL
107
NUT SPRING-LOADED PUSH ROD
110
SCREW RELEASE SPRING, UP TO ENGINE 438288 YEAR OF MANUFACTURE 1996
119
HEXALOBULAR BOLT. SCREW SUPPORT TO CYLINDER HEAD
152
YOKE SHIFTING ROD TO INTERMEDIATE LEVER
158
NUT
158
NUT , Replaced By: N304035008001
224
BRACKET
230
HEXAGON HEAD BOLT. SCREW CLUTCH TO FLYWHEEL M8X16 MM
230
HEXAGON HEAD BOLT BRACKET TO BRACKET M8X25
230
SCREW VALVE TO CAB M 8X85
230
SCREW STOP TO BATTERY CASE
230
SCREW , Replaced By: N304017008016
233
NUT , Replaced By: N304032008006
233
NUT FROM CONTROL LEVER TO INTERMEDIATE SHAFT AT ENGINE
233
NUT
236
WASHER EXHAUST MUFFLER TO STRAP
251
BEARING TUBE
251
BEARING TUBE
257
BUSHING MOUNTING
278
SCREW
281
SCREW FRONT AXLE REGULATING SOLENOID VALVE
281
HEXALOBULAR BOLT. SCREW CLAMP ON BRACKET M 6X35
281
BOLT. SCREW BRACKET TO PUSH ROD CHAMBER COVER
281
SCREW
281
HEXAGON HEAD BOLT BRACKET TO BRACKET M8X25
281
HEX. HEAD SCREW. SCREW AT BRAKE BOOSTER CONSOLE,4 208907
281
HEXAGON HEAD BOLT. SCREW REAR EXHAUST PIPE TO MUFFLER M8 X 110 MM
281
COMBINATION BOLT BEARING TUBE TO BRACKET
281
SCREW STOP TO BATTERY CASE
281
SCREW SLAVE CYLINDER TO BELL HOUSING M 10X200
281
COMBINATION BOLT , Replaced By: A0079902201
281
HEXAGON HEAD BOLT SHIFT LEVER TO CAB FLOOR M 8X45
281
SCREW. HEXAGON HEAD BOLT BATTERY AND ENGINE CABLE HARNESSES TO BRACKET M6X35
281
SCREW , Replaced By: N304017008034
281
SCREW , Replaced By: N000931010479
281
SCREW , Replaced By: N304014008011
281
SCREW , Replaced By: N000933008134
287
NUT SPRING-LOADED PUSH ROD
287
NUT FROM CONTROL LEVER TO INTERMEDIATE SHAFT AT ENGINE
293
BRACKET BEARING TUBE
296
SPACER TUBE 3/2-WAY VALVE TO BRACKET
308
SHAFT BEARING TUBE,694973
308
SHAFT BEARING TUBE,824720
308
SHAFT BEARING TUBE,694972
308
SHAFT BEARING TUBE,824721
308
SHAFT BEARING TUBE
308
SHAFT BEARING TUBE, TO BE ORDERED ONLY FROM MTU-FRIEDRICHSHAFEN
308
SHAFT BEARING TUBE
308
SHAFT BEARING TUBE
314
BALL PIVOT ROD TO INJECTION PUMP LEVER
314
BALL PIVOT LEVER
314
BALL STUD. BALL PIVOT TOP B10X4,5 MM
314
SCREW CONTROL LEVER TO INJECTION PUMP LEVER
314
BALL PIVOT CONTROL LEVER TO INJECTION PUMP LEVER, Replaced By: N000000004467
314
BALL PIVOT , Replaced By: A3129910120
323
COVERING , Replaced By: A4073015088
323
COVERING
326
WOODRUFF KEY
338
PULL ROD BRAKE POWER REGULATOR CONTROL 200 MM, TO BE ADAPTED DURING ASSEMBLY
338
PULL ROD BRAKE POWER REGULATOR CONTROL, TO BE ADAPTED DURING ASSEMBLY
341
BALL PIN PULL ROD, UP TO ENGINE 387047 YEAR OF MANUFACTURE 1995
344
NUT FROM CONTROL LEVER TO INTERMEDIATE SHAFT AT ENGINE
344
NUT
344
NUT , Replaced By: N304035008001
347
PIN SHIFT LEVER TO PIVOT PIN
350
HEXAGON HEAD BOLT. SCREW CLUTCH TO FLYWHEEL M8X16 MM
350
HEXALOBULAR BOLT. SCREW SUPPORT TO CYLINDER HEAD
350
SCREW BRACKET TO CROSS CONNECTION STRUT
350
HEXAGON HEAD BOLT BRACKET TO BRACKET M8X25
350
HEXAGON HEAD BOLT. SCREW CABLE HARNESS TO BRACKET M8X40
350
SCREW , Replaced By: N304017008016
350
SCREW , Replaced By: N304017008034
356
NUT FROM CONTROL LEVER TO INTERMEDIATE SHAFT AT ENGINE
359
BUSHING BALL PIN TO CONTROL LEVER
377
SPRING RELEASE SPRING, UP TO CHASSIS 556499 EXCEPT FOR 553795,555902,556120
377
SPRING ACCELERATOR CONTROL LINKAGE RELEASE SPRING
377
SPRING RELEASE SPRING
383
LEVER CONTROL SHAFT
383
LEVER CONTROL SHAFT
383
LEVER , EXHAUST STOCK OF OLD PARTS UP TO ENGINE 553967, Replaced By: A4420703421
407
SCREW CLAMP MOUNTING M 6X16
407
HEXALOBULAR BOLT. SCREW CLAMP ON BRACKET M 6X35
407
SCREW CLAMP ON BRACKET
407
SCREW. HEXAGON HEAD BOLT BATTERY AND ENGINE CABLE HARNESSES TO BRACKET M6X35
407
SCREW , Replaced By: N914146006102
413
NUT , Replaced By: N913004006001
413
NUT SPRING-LOADED PUSH ROD
413
NUT
413
NUT PUMP TO BRACKET
563
PULL ROD AT CONTROL LEVER, TO BE ADAPTED DURING ASSEMBLY
563
PULL ROD FROM ACCELERATOR PEDAL TO CONTROL SHAFT BEARING, TO BE ADAPTED DURING ASSEMBLY
563
PULL ROD6X180X30/30
566
BALL SOCKET PULL ROD TO INTERMEDIATE LEVER
569
NUT SPRING-LOADED PUSH ROD
572
CIRCLIP. SECURING CLIP BALL SOCKET TO ROD
575
BALL PIVOT ROD TO INJECTION PUMP LEVER
575
BALL PIVOT
578
NUT SPRING-LOADED PUSH ROD
581
SEAL RING MODULATION PRESSURE CONTROL
999
NUT LEVER TO THROTTLE VALVE SHAFT TO 366 140 02 32
999
NUT , Replaced By: N913023006001
999
SCREWM 10X20
999
SCREW LEVER TO ENGINE CONTROL SHAFT
999
SCREW. HEXAGON HEAD BOLT BATTERY AND ENGINE CABLE HARNESSES TO BRACKET M6X35
999
SCREW. HEXAGON HEAD BOLT GGVS-COMPONENT IN BATTERY CARRIER M6X10
999
SCREW SUPPORT TO CYLINDER CRANKCASE M 10X20
999
HEADLESS SETSCREW
999
THREADED PIN , NOT USED
999
SCREW , Replaced By: A4429906301
999
SCREW
999
BRACKET
999
SCREW BRACKET TO INJECTION PUMP,012077 NOT USED
999
BRACKET
999
PULL ROD
999
SUPPORT STOPPING MAGNET
999
SUPPORT STOPPING MAGNET, NOT USED
999
STOP , NOT USED
999
SHAFT , NOT USED
999
CONNECTING PIPE
999
ROD (PUSH ROD)
999
PULL ROD ,557099
999
ROD (PUSH ROD)
999
PULL ROD
999
PULL ROD , TO BE ADAPTED DURING ASSEMBLY
999
PULL ROD
999
PULL ROD
999
SCREW SUPPORT TO INTAKE PIPE
999
SCREW WIRING HARNESS FIXTURE AT AIR PIPE
999
ROD END
