Поз.
Артикул
Описание
600
SUCTION LINE SUCTION LINE TO EXPANSION VALVE
600
SUCTION LINE SUCTION LINE TO EXPANSION VALVE
600
SUCTION LINE SUCTION LINE TO EXPANSION VALVE
600
SUCTION LINE SUCTION LINE TO EXPANSION VALVE
602
SEALING RING17X2MM, Replaced By: A1409970945
604
SEALING RING SUCTION LINE 13.7X2.5 MM
605
VALVE INSERT TO REFRIGERANT LINE OF COMPRESSOR TO CONDENSER
610
SEALING RING SUCTION LINE 13.7X2.5 MM
615
CAP , NOT USED
620
LINE HOLDER REFRIGERANT LINE TO WHEELHOUSE
627
SEALING RING REFRIGERANT LINE 14.0X2.0
630
SUCTION LINE
635
PROFILE SEALING RING PIPE LINE TO REFRIGERANT COMPRESSOR, V 00027520130717
640
PRESSURE SENSOR
650
HEXAGON NUT ELECTRIC CABLE TO ALTERNATOR TERMINAL B-
650
NUT , Replaced By: N913023006001
660
BRACKET
670
NUT , Replaced By: N913023006001
700
PRESSURE LINE AT CONDENSER, 20110517
700
PRESSURE LINE AT CONDENSER, K 40749620100531
702
O-RING PRESSURE LINE TO CONDENSER 9.5X2.6
705
VALVE INSERT TO REFRIGERANT LINE OF COMPRESSOR TO CONDENSER
710
SEALING RING PIPE LINE TO REFRIGERANT COMPRESSOR 10.6X2 MM
715
CAP
720
PRESSURE SENSOR
730
PRESSURE LINE , K 64236920120917
730
PRESSURE LINE , K 64236820120917, Replaced By: A4518301700, +001A4518301800
737
O-RING PRESSURE LINE TO CONDENSER 9.5X2.6
738
PRESSURE LINE , K 64236820120917, Replaced By: A4518301800, +001A4518301700
738
PRESSURE LINE , K 64236920120917
739
PROFILE SEALING RING PIPE LINE TO REFRIGERANT COMPRESSOR
740
LINE HOLDER VENT LINE MOUNTING TO RIGHT REAR WHEELHOUSE, A 02430720090731
760
BRACKET FRONT
780
BRACKET
790
THREADED BUSHING CABLE HOLDER
800
HEX NUT GUIDE AT REAR FENDER
