Поз.
Артикул
Описание
25
ALTERNATOR WITH REGULATOR INCORPORATED AND PULLEY 28V/140A, BOSCH
30
ALTERNATOR , Replaced By: A4761547701
35
SCREW
35
SCREW , Replaced By: A0009909621
35
SCREWTO 345 150 76 50
35
SCREW , MODEL 343.919.000 FROM ENGINE 154150,MODEL 344.919.000 FROM ENGINE 822957
35
SCREW
35
SCREWTO 344 150 73 50
35
SCREW , Replaced By: A0019906420
40
SCREW
55
LOCK WASHER
55
LOCK WASHER
60
WASHER
75
BALL BEARING FRONT AND REAR
100
BEARING
120
RINGTO 009 154 72 02, 345 154 76 01
135
COVER
140
COVERTO 009 154 72 02
140
BEARINGTO 476 154 77 01, 345 154 76 01
140
BEARING , Replaced By: A0001540949, +001A0001550250
155
SPACER RING
160
SET COLLAR
165
SNAP RING
170
SEAL RING
180
ROTORTO 366 150 07 50, APPLICABLE TO ALTERNATOR HAVING BOSCH NO.0 120 469 982
180
ROTOR
180
ROTOR
180
ROTOR , Replaced By: A0001547815
185
WOODRUFF KEY
190
REPAIR KIT ROTOR
200
COIL
200
EXCITER COIL
210
RECTIFIERTO 005 154 45 02,006 154 86 02
210
RECTIFIER , Replaced By: A0001545116
210
RECTIFIER
225
SCREW
235
CONDENSER , Replaced By: A0011566701
235
CONDENSER
235
CONDENSER
250
SCREW
255
WASHER
270
REGULATOR AND CUT-OUT
270
REGULATOR AND CUT-OUT
280
CARBON BRUSH SET
290
SCREW REGULATOR MOUNTING TO 009 154 07 02
290
SCREWTO 344 150 73 50
290
SCREW
300
WASHER
320
INSULATOR TERMINALS: B+, B-, D+, W
325
NUT
325
NUT PULLEY TO ALTERNATOR
325
NUT WEAR INDICATOR
330
WASHER
355
FANTO 376 150 80 50,86 50
355
FAN
355
FAN
365
PULLEYTO 476 150 79 50
365
PULLEYTO 345 154 76 01, 476 154 76 01
370
COVER
375
RIVET
380
STUD
385
INSULATING BUSHING
390
INSULATING BUSHING
395
WASHER
400
WASHER
405
NUT
410
WASHER
415
INSULATING BUSHING
420
WASHER
425
BOOTTO 003 154 39 02
430
WASHER
435
NUT
440
INSULATING BUSHING
445
INSULATING PLATE
450
PLATE
455
PLATETO 009 154 72 02
460
HEX. NUT M 5 DIN 934-5 S. NUT PLUG SOCKET TO FRAME
465
CLAMPING BOLT
470
SPACER
999
BALL BEARING TIGHTENER PULLEY
999
BALL BEARING
999
V-BELT LOW TENSIBILITY 12.5X1718 MM, FROM IDENT NO. 004703 ALSO INSTALLED ON 004316,004586,004634,004640,004650,004662,004673
999
V-BELT12.5X1675
999
ALTERNATORN1 28V 10/55A, PART IS ONLY OR ALSO SUPPLIED AS RECONDITIONED PART
999
CLAMPING PIECE TIGHTENER PULLEY TO LEVER
999
HUBTO 343 150 73 50,376 150 87 50,82 50
999
PULLEYTO 343 150 73 50, 376 150 83 50
999
ALTERNATOR
999
ALTERNATOR
999
NUT TIGHTENER PULLEY TO LEVER
999
SUPPORT TIGHTENER PULLEY
999
TIGHTENER PULLEY
999
CLAMPING PIECE
999
CAP
999
BRACKET BELT TENSION READJUSTMENT
999
SPACER TUBE BRACKET AND FILLER NECK ON WATER PUMP
999
ALTERNATOR28V 35A, WITH TERMIANL "W"
999
CLAMPING BOLT FOR V-BELT TENSIONING
999
SUPPORT
999
BRACKET CLAMPING BOLT
999
CLAMPING BOLT
999
CLAMPING BOLT (CLAMPING BOLT)
999
ALTERNATOR
999
WASHER SUPPORT TO FRAME,D 127794
999
LOCK RING
999
SCREW PIPE ELBOW TO CHARGING AIR INTERCOOLER M 10X35,5 708090
999
SCREW FENDER TO BRACKET, NOT USED
999
SCREW
999
SCREW TORSION BAR TO SHACKLE,5 903514
