Поз.
Артикул
Описание
80
VALVE PNEUMATIC SUSPENSION BOSCH, PART IS ONLY OR ALSO SUPPLIED AS RECONDITIONED PART
80
VALVE TRAILING AXLE SELF-LEVELLING DEVICE
83
VALVE INTAKE
86
VALVE EXHAUST
87
SHAFT87 MM
89
LEVER (PARTS KIT)
92
REPAIR KIT
95
HEXAGON HEAD BOLT. SCREW LEVEL ADJUSTMENT VALVE TO SUBSTRUCTURE
107
HEXAGON NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET
110
ELBOW FITTING 3/2-WAY VALVE,CONNECTION: "20",5 765577
116
T-FITTING 3/2-WAY VALVE,CONNECTION: "33", UP TO IDENT NO. 5 385481 FROM IDENT NO. SEE STANDARD VERSION
119
FITTING LINE CONNECTION
119
FITTING LINE CONNECTION, Replaced By: N000000006446
122
NUT LOAD/NO-LOAD VALVE,CONNECTION: "20",5 727400
125
THRUST RING , THE OLD PART MUST NO LONGER BE INSTALLED, Replaced By: A0009940103
128
SEALING CORD COMPRESSED-AIR-LINE PLUG-CONNECTION
128
SEAL RING 3/2-WAY VALVE
134
VALVE LEVEL ADJUSTMENT VALVE,CONNECTION: "10"
137
SEAL RING LINE CONNECTION
137
SEAL RING PRESSURE REGULATOR,CONNECTION: "23",5 161701
140
BREATHER FILTER. FILTER TRAILER CONTROL VALVE,CONNECTION: "4"
149
NUT
149
NUT , Replaced By: N304035008001
152
NUT FRONT AXLE LEVEL ADJUSTMENT
155
NUT L.H. THREAD
155
NUT , Replaced By: N304035008002
158
BALL SOCKET POWER CYLINDER TO LEVER
161
BALL STUD. BALL PIVOT PULL ROD TO BRACKET
167
LOCK WASHER CLAMP TO BRACKET AND TO PIPE
170
NUT , Replaced By: N304032008006
