Поз.
Артикул
Описание
11
RUBBER MOUNTING FRONT
20
SCREW , Replaced By: N308676016005
20
SCREW , Replaced By: N000961016097
20
SCREW SUPPORT TO TRANSMISSION M 16X1.5X60
29
WASHER CONSOLE TO FRAME
38
NUT SUPPORT TO SIDE MEMBER
47
ENGINE CROSS MEMBER FRONT
56
ENGINE STAY FRONT
65
SCREW , Replaced By: N308676012026
65
SCREW DELIVERY AND SUCTION LINES TO FRAME M 12X35
74
WASHER MOUNTING USED FOR FRAME CONNECTION PARTS
83
NUT SUPPORT TO SIDE MEMBER
92
SCREW DELIVERY AND SUCTION LINES TO FRAME M 12X35
92
SCREW , Replaced By: N308676012026
92
SCREW DELIVERY AND SUCTION LINES TO FRAME M 12X40
101
NUT SUPPORT TO SIDE MEMBER
110
SUPPORTING ARM CLUTCH END
119
SCREW , Replaced By: N304017016004
119
SCREW SUPPORTING ARM TO HOUSING M 16X35
128
RUBBER MOUNTING REAR
128
RUBBER MOUNTING REAR
137
SCREENING PLATE REAR RUBBER MOUNTING
146
SCREW SUPPORT TO SIDE MEMBER M 14X45
146
SCREW BRACKET TO SIDE MEMBER M 14X1.5X50,5 543914
146
SCREW , Replaced By: N308676014012
155
WASHER CROSS MEMBER TO SUPPORT
164
CONSOLE ENGINE LEFT SUPPORT, TO BE ADAPTED DURING ASSEMBLY
164
CONSOLE ENGINE RIGHT SUPPORT, TO BE ADAPTED DURING ASSEMBLY
173
HEXAGON HEAD BOLT. SCREW BRACKET TO CROSS MEMBER
173
SCREW BRACKET TO FRAME M 12X35
182
NUT SUPPORT TO SIDE MEMBER
191
SCREW BRACKET TO LEFT SIDE MEMBER
200
WASHER
