Поз.
Артикул
Описание
23
HOSE , Replaced By: A0009872827
23
PLASTIC PIPE FUEL LINE 12X1,5 MM, ORDER BY THE METER
37
BANJO UNION , Replaced By: N915052009009
37
BANJO UNION HOSE WIDTH, / I.D., 9/16 MM
42
LOOM TIE LINE MOUNTING 280 MM
42
LOOM TIE LINE MOUNTING
42
LOOM TIE LINE MOUNTING 280 MM
98
BATTERY SUPPORT
98
BATTERY SUPPORT ,5 161700
98
BATTERY SUPPORT ,5 161700
98
BATTERY SUPPORT , Replaced By: A6205400016
98
BATTERY SUPPORT , FOR THE NEW PART NO.,SEE STANDARD VERSION, Replaced By: A6205400016
98
BATTERY SUPPORT , FOR THE NEW PART NO.,SEE STANDARD VERSION, Replaced By: A6205400016
99
CLAMP , Replaced By: N916016011202
99
CLAMP AT BRACKET
101
SCREW PROTECTIVE PLATE TO EXHAUST MUFFLER
103
NUT , Replaced By: N910113010000
103
NUT STRAP TO BRACKET
158
STRAINER FILTER ELEMENT
161
SEAL RING
163
STRAINER
165
SEAL RING
167
VALVE SOLENOID SWITCH
168
ANGLETO 000 431 46 15
168
ANGLETO 000 431 46 15
173
FITTING AIR RESERVOIR,CONNECTION: "11"
173
FITTING REAR AXLE REGULATING SOLENOID VALVE, CONNECTIONS: "10"
175
ELBOW FITTING ANTI-FREEZE DEVICE,CONNECTION: "10", BUTT CONNECTION
175
ELBOW FITTING ANTI-FREEZE DEVICE,CONNECTION: "10", BUTT CONNECTION
175
ELBOW FITTING ANTI-FREEZE DEVICE,CONNECTION: "10", BUTT CONNECTION
175
ELBOW FITTING ,5 433281
177
NUT CHECK VALVE TO AIR RESERVOIR
177
NUT CHECK VALVE TO AIR RESERVOIR
179
O-RING CHECK VALVE TO AIR RESERVOIR
181
THRUST RING , THE OLD PART MUST NO LONGER BE INSTALLED, Replaced By: A0009940203
181
THRUST RING CHECK VALVE TO AIR RESERVOIR
182
HOLLOW SCREW FRONT AXLE REGULATING SOLENOID VALVE, CONNECTION: "10",K 009079
182
HOLLOW SCREW FRONT AXLE REGULATING SOLENOID VALVE, CONNECTION: "10",K 009079
184
SEAL RING LOAD/NO-LOAD VALVE,CONNECTION: "20"
280
HOLLOW SCREW FOUR-CIRCUIT PROTECTIVE VALVE, CONNECTION: "24"
287
SEAL RING LOAD/NO-LOAD VALVE,CONNECTION: "20"
999
COVERING ANTI-FREEZE DEVICE,6 900023
999
BATTERY SUPPORT , Replaced By: A6165400316
999
BRACKET AIR CLEANER,5 088361
999
RUBBER SECTION , Replaced By: A3634750320
999
VALVE ,5 161700, Replaced By: A0024314706
999
PRESSURE REGULATOR ,5 161700, Replaced By: A0024314606
999
FITTING SHUTTLE VALVE,CONNECTION: "20"
999
FITTING AIR RESERVOIR,CONNECTION: "13"
999
T-FITTING PRESSURE RELIEF VALVE,CONNECTION: "10"
999
SEAL RING LOAD/NO-LOAD VALVE,CONNECTION: "20"
999
FILTER , Replaced By: A0004315934
999
RESERVOIR , Replaced By: A0034321201
999
RESERVOIR , Replaced By: A0014327501
999
ANTI-FREEZE DEVICE , Replaced By: A0004314615
999
AIR CLEANERBOSCH
999
THRUST RING LOAD/NO-LOAD VALVE,CONNECTION: "20"
