Поз.
Артикул
Описание
7
COVERING LEFT,4 960378
7
COVERING LEFT,4 960379
7
COVERING LEFT,4 960379
7
COVERING LEFT
7
COVERING RIGHT,4 960379
7
COVERING RIGHT
7
COVERING RIGHT
7
COVERING RIGHT
7
COVERING LEFT
7
COVERING LEFT
7
COVERING RIGHT,4 960378
7
COVERING RIGHT,4 960379
13
BRACKET LEFT COVERING,4 960379
13
BRACKET LEFT COVERING,4 960379
13
BRACKET RIGHT COVERING,4 960379
13
BRACKET RIGHT COVERING,4 960379
13
BRACKET RIGHT COVERING,4 960379
13
BRACKET , THE OLD PART MUST NO LONGER BE INSTALLED, Replaced By: A6205244940
13
BRACKET LEFT COVERING,5 120171
13
BRACKET LEFT COVERING,5 120172
13
BRACKET RIGHT COVERING,5 120171
13
BRACKET RIGHT COVERING,5 120172
13
BRACKET , Replaced By: A6205243940
13
BRACKET , Replaced By: A6205241640
19
SCREW , Replaced By: N304017008027
19
SCREW CLAMP TO CONNECTING PIPE AND TO EXHAUST HOSE M 8X30
19
SCREW , Replaced By: N308676012015
25
NUT , Replaced By: N913004008001
25
NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET, Replaced By: N910113008003
25
NUT SUPPORT TO SIDE MEMBER
31
SCREW CLAMP TO BRACKET AND TO PIPE
37
WASHER , Replaced By: N000125008443
37
WASHER EXHAUST MUFFLER TO STRAP
43
COVERING ENGINE,BOTTOM,4 960378
43
COVERING ENGINE,BOTTOM,4 960379
43
COVERING ENGINE,BOTTOM,4 960379
43
COVERING ENGINE,BOTTOM
48
COVERING ENGINE,BOTTOM
49
SCREW , Replaced By: N304017006034
49
SCREW COVER PLATE TO COVER PLATE M 6 X 10
49
SCREW , Replaced By: N304017006018
49
SCREW COVER PLATE TO COVER PLATE M 6 X 12
49
SCREW COVER PLATE TO COVER PLATE M 6 X 12
55
LOCK WASHER CONTROL LEVER TO INJECTION PUMP LEVER
61
WASHER , Replaced By: N009021006208
61
WASHER COMPRESSED AIR LINE TO BRACKET
67
COVERING ENGINE,BOTTOM,4 960378
67
COVERING ENGINE,BOTTOM,4 960379
67
COVERING ENGINE,BOTTOM,4 960379
67
COVERING ENGINE,BOTTOM
67
COVERING ENGINE,BOTTOM
67
COVERING ENGINE,BOTTOM
76
COVERING ANTINOISE CAPSULE
79
REINFORCEMENT , NOT USED
85
BRACKET COVER PLATE,4 960378
85
BRACKET LEFT COVERING,4 960379
85
BRACKET LEFT COVERING,4 960379
85
BRACKET RIGHT COVERING
85
BRACKET COVER PLATE
85
BRACKET OIL PAN COVERING BRACKET,REAR LEFT
85
BRACKET OIL PAN COVERING BRACKET,REAR RIGHT
91
SCREW , Replaced By: N304017008018
91
SCREW SUPPORT TO FENDER
91
SCREW REAR EXHAUST PIPE TO MUFFLER
97
NUT , Replaced By: N913004008001
97
NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET, Replaced By: N910113008003
103
SCREW CLAMP TO BRACKET AND TO PIPE
109
LOCK WASHER CLAMP TO BRACKET AND TO PIPE
115
SCREW , Replaced By: N304017006034
115
SCREW COVER PLATE TO COVER PLATE M 6 X 10
115
SCREW , Replaced By: N304017006018
115
SCREW COVER PLATE TO COVER PLATE M 6 X 12
115
SCREW COVER PLATE TO COVER PLATE M 6 X 12
121
LOCK WASHER CONTROL LEVER TO INJECTION PUMP LEVER
127
WASHER , Replaced By: N009021006208
127
WASHER COMPRESSED AIR LINE TO BRACKET
133
COVER PLATE ENGINE
139
SCREW , Replaced By: N304017006034
139
SCREW COVER PLATE TO COVER PLATE M 6 X 10
139
SCREW , Replaced By: N304017006018
139
SCREW COVER PLATE TO COVER PLATE M 6 X 12
139
SCREW COVER PLATE TO COVER PLATE M 6 X 12
145
SPRING WASHER LICENSE PLATE TO BRACKET
151
LINK TORSION BAR TO CONSOLE
151
SHACKLE TORSION BAR,FRONT,5 165467
151
SHACKLE TORSION BAR,FRONT,5 165467
154
SCREW , Replaced By: N304017008021
154
SCREW PIPE CLAMP
158
WASHER , Replaced By: N000125008443
158
WASHER EXHAUST MUFFLER TO STRAP
162
LOCK WASHER CLAMP TO BRACKET AND TO PIPE
166
SCREW CLAMP TO BRACKET AND TO PIPE
170
LOCK WASHER CLAMP TO BRACKET AND TO PIPE
174
BRACKET
178
SCREW BRACKET TO SUPPORT
182
NUT , Replaced By: N910113016001
182
NUT CONSOLE TO SUPPORT
186
BRACKET CABLE HARNESS MOUNTING
190
SCREW CONTROL UNIT TO CAB
194
NUT TWO-WAY VALVE TO BRACKET
198
LOOM TIE LINE MOUNTING
999
SHACKLE. LINK TORSION BAR
999
COVERING ,4 960378 NOT USED
999
COVERING , NOT USED
999
COVERING ,4 960378 NOT USED
