Поз.
Артикул
Описание
8
PLASTIC PIPE FUEL LINE 12X1,5 MM, ORDER BY THE METER
8
HOSE , Replaced By: A0009872827
11
FITTING (PARTS KIT),LINE RUPTURE
13
UNION NUT LINE CONNECTION
13
UNION NUT LINE CONNECTION, Replaced By: N000000006239
18
SEAL CONE LINE CONNECTION
18
GLAND , Replaced By: A0019901967
23
SLEEVE LINE CONNECTION
28
BANJO UNION HOSE WIDTH, / I.D., 9/16 MM
28
BANJO UNION , Replaced By: N915052009009
30
PLASTIC PIPE. HOSE AERATION 6X8 MM, ORDER BY THE METER
31
FITTING (PARTS KIT),LINE RUPTURE
32
BANJO UNION HOSE WIDTH, / I.D., 6/16 MM
35
FITTING SHUTTLE VALVE
42
NUT BRACKET TO SIDE MEMBER
49
TEST CONNECTION BULKHEAD FITTING
49
TEST CONNECTION , Replaced By: A0004313031
56
BRAKE LINE COUPLING AT REAR CROSS MENBER
63
BRAKE LINE COUPLING AT REAR CROSS MENBER
63
BRAKE LINE COUPLING AT REAR CROSS MENBER
70
BRAKE LINE COUPLING AT REAR CROSS MENBER
119
SEAL RINGTO 000 429 75 30
133
REPAIR KITWABCO
140
FITTING SHUTTLE VALVE
140
FITTING SHUTTLE VALVE
142
FITTING REAR AXLE REGULATING SOLENOID VALVE, CONNECTIONS: "10"
147
SEAL RING LOAD/NO-LOAD VALVE,CONNECTION: "20"
147
O-RING CHECK VALVE TO AIR RESERVOIR
154
THRUST RING LOAD/NO-LOAD VALVE,CONNECTION: "20"
154
THRUST RING CHECK VALVE TO AIR RESERVOIR
154
THRUST RING , THE OLD PART MUST NO LONGER BE INSTALLED, Replaced By: A0009940203
161
NUT LOAD/NO-LOAD VALVE,CONNECTIONS: "10,20"
161
NUT BRACKET TO SIDE MEMBER
161
NUT BRACKET TO SIDE MEMBER
168
BRAKE VALVE (TRAILER CONTROL VALVE) "BOSCH"
168
BRAKE VALVE (TRAILER CONTROL VALVE), PART IS ONLY OR ALSO SUPPLIED AS RECONDITIONED PART
175
REPAIR KIT TRAILER CONTROL VALVE TO 001 431 46 05,BOSCH
175
REPAIR KIT TRAILER CONTROL VALVE TO 001 431 46 05,BOSCH
175
REPAIR KIT TRAILER CONTROL VALVE TO 001 431 52 05, WABCO
175
REPAIR KIT , Replaced By: A0014306160
182
HOLLOW SCREW FOUR-CIRCUIT PROTECTIVE VALVE, CONNECTION: "24"
189
SEAL RING LOAD/NO-LOAD VALVE,CONNECTION: "20"
196
FITTING REAR AXLE REGULATING SOLENOID VALVE, CONNECTIONS: "10"
203
O-RING CHECK VALVE TO AIR RESERVOIR
210
THRUST RING CHECK VALVE TO AIR RESERVOIR
210
THRUST RING , THE OLD PART MUST NO LONGER BE INSTALLED, Replaced By: A0009940203
217
HOLLOW SCREW FRONT AXLE REGULATING SOLENOID VALVE, CONNECTION: "10",K 009079
224
SEAL RING LOAD/NO-LOAD VALVE,CONNECTION: "20"
226
BRACKET TRAILER CONTROL VALVE TO APPARATUS SUPPORT
231
BRACKET TRAILER CONTROL VALVE
231
BRACKET TRAILER CONTROL VALVE TO BRACKET
231
BRACKET TRAILER CONTROL VALVE
231
BRACKET TRAILER CONTROL VALVE TO BRACKET
234
BRACKET TRAILER CONTROL VALVE,5 298636
234
BRACKET TRAILER CONTROL VALVE,5 298636
238
NUT STRAP TO BRACKET
238
NUT , Replaced By: N910113010000
240
SCREW BRACKET TO APPARATUS SUPPORT
241
SCREW END PIECE TO EXHAUST PIPE M 10X25
242
NUT STRAP TO BRACKET
242
NUT , Replaced By: N910113010000
245
SCREW BRACKET TO SIDE MEMBER
245
SCREW SUPPORT TO FENDER
245
SCREW , Replaced By: N304017008018
252
NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET, Replaced By: N910113008003
252
NUT , Replaced By: N913004008001
259
BRACKET DOUBLE BRAKE LINE COUPLING TO REAR CROSS MEMBER,K 119510
259
BRACKET DOUBLE BRAKE LINE COUPLING TO REAR CROSS MEMBER,K 119510
259
BRACKET , Replaced By: A3464290940
999
VALVE CONEBOSCH
999
COVERWABCO
999
REPAIR KITKNORR
999
FITTING , Replaced By: A0029905971
999
FITTING , Replaced By: A0029906171
999
BRACKET TRAILER CONTROL VALVE
999
UNION NUT , Replaced By: N915017012100
