Поз.
Артикул
Описание
324
ROD TORSION BAR
325
JOINT BEARING TORSION BAR
327
GREASE NIPPLE
330
BRACKET LINK
333
SPACER TUBE ROD TO BRACKET
336
SCREW TORSION BAR TO BEARING BRACKET M 16X115,5 903514
339
SPACER TUBE ROD TO BRACKET
342
SEAL RING ROD TO BRACKET
345
WASHER TORSION BAR TO BEARING BRACKET, Replaced By: N007349017003
348
NUT CONSOLE TO SUPPORT
348
NUT , Replaced By: N910113016001
351
SCREW BRACKET TO SIDE MEMBER
354
NUT TORSION BAR TO BEARING BRACKET,5 904661
357
TORSION BAR REAR AXLE
360
GREASE NIPPLE
363
JOINT BEARING TORSION BAR
363
JOINT BEARING TORSION BAR
366
LOCK RING TORSION BAR TO LINK,5 903513
369
RUBBER MOUNTING TORSION BAR,5 554755
369
RUBBER MOUNTING TORSION BAR,5 554754
370
REPAIR KIT TORSION BAR TO REAR AXLE,5 554755 MUST NOT BE USED TO REPAIR UPPER JOINT OF 393 320 07 89 ROD
370
REPAIR KIT TORSION BAR TO REAR AXLE,5 554754 MUST NOT BE USED TO REPAIR UPPER JOINT OF 393 320 07 89 ROD
370
REPAIR KIT , Replaced By: A3873200328
372
SPRING SEAT TORSION BAR TO REAR AXLE,LEFT,5 554754
372
SPRING SEAT TORSION BAR TO REAR AXLE,RIGHT,5 554754
375
SCREW BEARING BRACKET TO SHOCK ABSORBER BRACKET M 16X110,5 903513
375
SCREW ,5 903513, Replaced By: N308765016011
375
SCREW TORSION BAR TO REAR AXLE M 16X60,5 554754
375
SCREW TORSION BAR TO BEARING BRACKET M 16X115,5 903514
378
NUT CONSOLE TO SUPPORT
378
NUT , Replaced By: N910113016001
381
SPACER TUBE ROD TO BRACKET
384
SCREW TORSION BAR TO BEARING BRACKET M 16X115,5 903514
387
SPACER TUBE ROD TO BRACKET
390
SEAL RING ROD TO TORSION BAR
393
WASHER TORSION BAR TO BEARING BRACKET, Replaced By: N007349017003
395
NUT CONSOLE TO SUPPORT
395
NUT , Replaced By: N910113016001
398
WASHER ROD TO TORSION BAR
401
SHOCK ABSORBER REAR AXLE,5 301234
401
SHOCK ABSORBER , Replaced By: A0043264300
401
SHOCK ABSORBER FRONT AXLE II, UP TO IDENT NO. 5 158496, FROM IDENT NO. SEE STANDARD VERSION
401
SHOCK ABSORBER , Replaced By: A0033267400
401
SHOCK ABSORBER REAR AXLE,5 301234, Replaced By: A0063263400
401
SHOCK ABSORBER FRONT AXLE II, UP TO IDENT NO. 5 158496, FROM IDENT NO. SEE STANDARD VERSION
402
BUSHINGTO 004 323 52 00
402
BUSHINGTO 004 326 24 00
402
SPACER RINGTO 002 323 86 00,003 323 03 00,
403
RUBBER BUFFER SHOCK ABSORBER,BOTTOM TO 003 326 45 00, Replaced By: A0003238085
403
RUBBER BUFFER , Replaced By: A0003233144
403
RUBBER MOUNTINGTO 002 323 86 00,003 323 03 00,
404
SCREW RUBBER MOUNTING TO SUPPORTING ARM M16X80,5 566418
407
NUT COMBINATION CYLINDER TO BEARING BRACKET
407
NUT COMBINATION CYLINDER TO BEARING BRACKET, Replaced By: N910113016002
410
BRACKET SHOCK ABSORBER,TOP
413
SCREW DELIVERY AND SUCTION LINES TO FRAME M 12X35
413
SCREW , Replaced By: N308676012026
416
NUT SUPPORT TO SIDE MEMBER
419
SCREW SHOCK ABSORBER TO BOTTOM BRACKET M 16X85
419
SCREW , Replaced By: N000960016250
422
NUT COMBINATION CYLINDER TO BEARING BRACKET
422
NUT COMBINATION CYLINDER TO BEARING BRACKET, Replaced By: N910113016002
425
BRACKET SHOCK ABSORBER TO FRONT AXLE
428
SCREW SHOCK ABSORBER TO AIR-SPRING-BELLOWS SUPPORT,5 554755
428
SCREW BEARING BRACKET TO FRONT AXLE M 20X140,5 2903465 352763
428
SCREW , Replaced By: N000960020123
431
NUT CROSS MEMBER TO REINFORCEMENT
431
NUT , Replaced By: N913004020003
999
VALVETO 000 329 04 25,000 329 08 25,K 186867
999
REPAIR KIT CONTROL VALVE KNORR SV 3118-I/75379, NOT FOR USE WITH MERCEDES-BENZ PLATFORM5 147260
999
REPAIR KIT CONTROL VALVE KNORR SV 3111-I/83153,K 186867
999
REPAIR KIT. GASKET CONTROL VALVE KNORR SV 3118-I/86025, NOT FOR USE WITH MERCEDES-BENZ PLATFORM5 147260
999
BUSHING , Replaced By: A0003233150
999
BOOT ,5 292411
999
PROTECTIVE CAPTO 000 329 04 25,000 329 08 25,K 186867
999
PROTECTIVE CAP , Replaced By: A0003290092
999
VALVE , Replaced By: A0003290925
999
VALVE , NOT FOR USE WITH MERCEDES-BENZ PLATFORM5 1472605 314006 PLEASE REFER TO SERVICE INFORMATION NO.: 32/13, Replaced By: A0003291125, +NBA0199977582, +003N007603016401, +001N915047012203, +002N915052006010
999
VALVE CONTROL VALVE KNORR, NOT FOR USE WITH MERCEDES-BENZ PLATFORM5 314007
999
VALVE CHECK TO SV 3127-I/88810
999
GASKETTO 003 429 22 44
999
THRUST RING , THE OLD PART MUST NO LONGER BE INSTALLED, Replaced By: A0009940203
999
THRUST RING FROM 3/2-WAY VALVE TO QUICK BREATHER VALVE,5 431227
999
VALVE BODYTO 002 429 95 44
999
REPAIR KIT 3/2-WAY VALVE
999
O-RING CHECK VALVE TO AIR RESERVOIR
999
FITTING REAR AXLE REGULATING SOLENOID VALVE, CONNECTIONS: "10"
999
T-FITTING 3/2-WAY VALVE,CONNECTION: "33", UP TO IDENT NO. 5 385481 FROM IDENT NO. SEE STANDARD VERSION
999
THRUST RING CHECK VALVE TO AIR RESERVOIR
999
HANDLE ,5 292411
999
FITTING AIR RESERVOIR,CONNECTION: "11"
999
BALLTO 003 429 22 44
999
VALVE ENGINE SHUT-OFF
999
VALVE ENGINE SHUT-OFF
999
VALVE , Replaced By: A0044294944
999
VALVE (OVERFLOW VALVE)
999
VALVE (OVERFLOW VALVE) "WABCO"
999
VALVE. REPAIR KIT SHUTTLE VALVE
999
VALVE SHUT-OFF VALVE, PART IS ONLY OR ALSO SUPPLIED AS RECONDITIONED PART
999
SEAL RING FROM 3/2-WAY VALVE TO QUICK BREATHER VALVE,5 431227
999
PIN , Replaced By: A6203200228
999
NUT 4/3-WAY VALVE TO SUBSTRUCTURE
999
WASHER 3/2-WAY VALVE TO BRACKET
999
ADHESIVE FOIL GUIDE SIGN
999
PIN TORSION BAR TO BEARING BRACKET
999
BRACKET 3/2-WAY VALVE
999
BRACKET CONTROL VALVE, NOT FOR USE WITH MERCEDES-BENZ PLATFORM5 147260
999
TORSION BAR FRONT AXLE,K 054776
999
PIPE SOCKET 3/2-WAY VALVE,CONNECTION: "30"
999
BRACKET PRESSURE RELIEF VALVE AND LIFT PRESSURE BOOSTER VALVE
999
UNIT IDENTIFICATION PLATE TRAILING AXLE LIFT
999
UNIT IDENTIFICATION PLATE STARTING ASSISTANCE
999
STEP BEARINGTO 655 328 01 41/02 41
999
SPACER TUBE
999
SPACER TUBE BEARING BRACKET TO SIDE MEMBER
999
NUT , Replaced By: N308675016001
999
SCREW , Replaced By: N304017008021
999
SCREW , Replaced By: N304017008027
999
SCREW , Replaced By: N304017008016
999
STUD BOLT ,5 910760
999
SCREW , Replaced By: N308676012012
999
SCREW GUSSET PLATE TO CROSS MEMBER
999
SEAL RING , Replaced By: N007603010110
999
SEAL RING PNEUMATIC VALVE
999
SEAL RING LINE CONNECTION
999
SEAL RING FUEL LINE TO FEED PUMP
999
SEAL RING LOAD/NO-LOAD VALVE,CONNECTION: "20"
999
SCREW OIL-DIPSTICK GUIDE TUBE TO BRACKET
999
SCREW PIPE CLAMP
999
SCREW CLAMP TO CONNECTING PIPE AND TO EXHAUST HOSE M 8X30
999
NUT FOUR-CIRCUIT PROTECTIVE VALVE, CONNECTION: "22",4 821954
999
SCREW. HEXAGON HEAD BOLT VALVE TO BRACKET
999
LOCK WASHER CLAMP TO BRACKET AND TO PIPE
999
NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET, Replaced By: N910113008003
999
NUT , Replaced By: N913004008001
999
HOLLOW SCREW LINE CONNECTION
999
HOLLOW SCREW HEATING CONNECTION
999
HOLLOW SCREW FUEL LINE TO FEED PUMP
999
HOLLOW SCREW , Replaced By: N915036010108
999
HOLLOW SCREW FRONT AXLE REGULATING SOLENOID VALVE, CONNECTION: "10",K 009079
999
HOLLOW SCREW FITTING REAR AXLE REGULATING SOLENOID VALVE, CONNECTION: "1"
999
HOLLOW SCREW FITTING SHUTTLE VALVE,CONNECTION: "17", UP TO IDENT NO. 5 385481 FROM IDENT NO. SEE STANDARD VERSION
999
HOLLOW SCREW LINE CONNECTION
999
HOLLOW SCREW TWO-WAY VALVE,CONNECTIONS: "11,12"
999
HOLLOW SCREW FOUR-CIRCUIT PROTECTIVE VALVE, CONNECTION: "24"
