Поз.
Артикул
Описание
8
PLASTIC PIPE RISING PIPE 4X6 MM
8
PLASTIC PIPE RISING PIPE 4X6 MM
8
PLASTIC PIPE RISING PIPE 4X6 MM
8
PLASTIC PIPE RISING PIPE 4X6 MM
8
PLASTIC PIPE RISING PIPE 4X6 MM
8
HOSE LEAK LINE 4X6 MM, ORDER BY THE METER
11
FITTING (PARTS KIT),LINE RUPTURE,5 909352K 169122
15
BANJO UNION HOSE WIDTH, / I.D., 4/10 MM
15
BANJO UNION HOSE WIDTH, / I.D., 4/10 MM
15
BANJO UNION HOSE WIDTH, / I.D., 4/12 MM
15
BANJO UNION HOSE WIDTH, / I.D., 4/12 MM
16
CONNECTOR
17
PLASTIC PIPE. HOSE AERATION 6X8 MM, ORDER BY THE METER
17
PLASTIC PIPE. HOSE AERATION 6X8 MM, ORDER BY THE METER
17
PLASTIC PIPE. HOSE AERATION 6X8 MM, ORDER BY THE METER
17
PLASTIC PIPE. HOSE AERATION 6X8 MM, ORDER BY THE METER
17
PLASTIC PIPE. HOSE AERATION 6X8 MM, ORDER BY THE METER
17
PLASTIC PIPE. HOSE AERATION 6X8 MM, ORDER BY THE METER
18
FITTING (PARTS KIT),LINE RUPTURE
18
FITTING , Replaced By: A0029905971
19
BANJO UNION HEATING CONNECTION,K 169122
19
BANJO UNION HOSE WIDTH, / I.D., 6/12 MM
19
BANJO UNION HOSE WIDTH, / I.D., 6/10 MM
23
LOOM TIE LINE MOUNTING 280 MM
29
VALVE ENGINE SHUT-OFF
29
VALVE ENGINE SHUT-OFF
29
VALVE STARTING ASSISTANCE
36
WASHER 3/2-WAY VALVE TO BRACKET
36
WASHER AT TWO-WAY VALVE
43
UNIT IDENTIFICATION PLATE STARTING ASSISTANCE
43
UNIT IDENTIFICATION PLATE STARTING ASSISTANCE
50
NUT 4/3-WAY VALVE TO SUBSTRUCTURE
57
HOLLOW SCREW LINE CONNECTION
57
HOLLOW SCREW LINE CONNECTION
64
SEAL RING PNEUMATIC VALVE
64
SEAL RING , Replaced By: N007603010110
71
VALVE , FIRST EXHAUST STOCK OF OLD PARTS UP TO IDENT NO. 5 359429, Replaced By: A0034298344
71
VALVE PRESSURE RELIEF FOR BELLOWS RESIDUAL PRESSURE
74
REPAIR KIT REDUCTION VALVE
74
REPAIR KIT REDUCTION VALVE
78
HOLLOW SCREW LINE CONNECTION
81
HOLLOW SCREW HEATING CONNECTION
81
HOLLOW SCREW HEATING CONNECTION
81
HOLLOW SCREW HEATING CONNECTION
85
SEAL RING LINE CONNECTION
85
SEAL RING LINE CONNECTION
92
SCREW PROTECTIVE PLATE TO EXHAUST MUFFLER
99
LOCK WASHER BRACKET TO SUPPORT AND TO END PIECE
106
WASHER BRACKET TO COVERING
106
WASHER , Replaced By: N009021010209
113
HOLLOW SCREW HEATING CONNECTION
120
HOLLOW SCREW LINE CONNECTION
127
SEAL RING LINE CONNECTION
135
VALVE (3/2-WAY SOLENOID VALVE)
140
REPAIR KIT 3/2-WAY SOLENOID VALVE
145
SCREW VALVE TO BRACKET M 5X40
145
SCREW 3/2-WAY VALVE TO BRACKET, UP TO IDENT NO. 5 385481 FROM IDENT NO. SEE STANDARD VERSION
150
NUT TWO-WAY VALVE TO BRACKET
155
HOLLOW SCREW LINE CONNECTION
160
SEAL RING LINE CONNECTION
165
HOLLOW SCREW FUEL LINE TO FEED PUMP
165
HOLLOW SCREW , Replaced By: N915036010108
170
SEAL RING FUEL LINE TO FEED PUMP
175
HOLLOW SCREW LINE CONNECTION
180
HOLLOW SCREW LINE CONNECTION
185
SEAL RING PNEUMATIC VALVE
185
SEAL RING , Replaced By: N007603010110
190
VALVE (OVERFLOW VALVE)
195
DIAPHRAGM
200
FITTING BRAKE LINE COUPLING TO BRACKET
205
THRUST RING CHECK VALVE TO AIR RESERVOIR
205
THRUST RING , THE OLD PART MUST NO LONGER BE INSTALLED, Replaced By: A0009940203
210
O-RING CHECK VALVE TO AIR RESERVOIR
215
HOLLOW SCREW FOUR-CIRCUIT PROTECTIVE VALVE, CONNECTION: "24"
230
SEAL RING LOAD/NO-LOAD VALVE,CONNECTION: "20"
235
FITTING TWO-WAY VALVE "12",4 4121264 691315
240
THRUST RING CHECK VALVE TO AIR RESERVOIR
240
THRUST RING , THE OLD PART MUST NO LONGER BE INSTALLED, Replaced By: A0009940203
245
O-RING CHECK VALVE TO AIR RESERVOIR
250
PIPE SOCKET 3/2-WAY VALVE,CONNECTION: "30"
999
BRACKET 3/2-WAY VALVE
999
SCREW , Replaced By: N304017008018
999
SCREW SUPPORT TO FENDER
