Поз.
Артикул
Описание
5
VALVE LONGITUDINAL DIFFERENTIAL LOCK CONTROL BOSCH
5
VALVE LONGITUDINAL DIFFERENTIAL LOCK CONTROL WABCO
8
CLAMPING SLEEVE TOP WABCO
11
SEAL RING TOP WABCO
14
SEAL RING INSIDE WABCO
17
SPRING INSIDE WABCO
20
GUIDE SIGN P.T.O. CONTROL
26
NUT 4/3-WAY VALVE TO SUBSTRUCTURE
29
HANDLE 3/2-WAY VALVE TO BRACKET
32
SCREW. UNION SCREW LINE CONNECTION
32
SCREW. UNION SCREW , Replaced By: A0009973734
35
PLASTIC PIPE RISING PIPE 4X6 MM
35
PLASTIC PIPE. HOSE AERATION 6X8 MM, ORDER BY THE METER
35
HOSE LEAK LINE 4X6 MM, ORDER BY THE METER
38
FITTING (PARTS KIT),LINE RUPTURE,5 909352K 169122
38
FITTING (PARTS KIT),LINE RUPTURE
41
BANJO UNION HOSE WIDTH, / I.D., 4/12 MM
44
HOLLOW SCREW HEATING CONNECTION
47
SEAL RING LINE CONNECTION
50
CONNECTOR
53
CONNECTOR DISTRIBUTOR TO CAB
56
CONNECTOR COMPRESSED-AIR-LINE PLUG-CONNECTION
59
SEAL RING
62
CONNECTOR
65
CONNECTOR COMPRESSED-AIR-LINE PLUG-CONNECTION
68
SEALING CORD COMPRESSED-AIR-LINE PLUG-CONNECTION
71
ELBOW FITTING COMPRESSED-AIR-LINE PLUG-CONNECTION
71
ELBOW FITTING COMPRESSED-AIR-LINE PLUG-CONNECTION TO M 16
74
LOCK RING LINE CONNECTION
74
SEAL RING , Replaced By: A0009940747
77
LOCK , Replaced By: A0009945448
77
LOCK LINE CONNECTION
80
REPAIR KIT COMPRESSED-AIR-LINE PLUG-CONNECTION TO M 16
80
REPAIR KIT , Replaced By: A0309971748
83
SCREW DELIVERY AND SUCTION LINES TO ENGINE, FRONT M 6X35
86
SCREW EXHAUST BRAKE SEPARATION POINT
89
INSULATING HOSE LINE MOUNTING, ORDER BY THE METER
92
LOOM TIE LINE MOUNTING 280 MM
