Поз.
Артикул
Описание
20
HEXAGON HEAD BOLT BEARING BRACKET ON BEARING BRACKET M18X1.5X150, NOT INCLUDED IN RANGE OF DELIVERY OF FRAME
20
HEXAGON HEAD BOLT BATTERY/APPARATUS SUPPORT TO FRAME SIDE MEMBER M18X1.5X150
23
HEXAGON HEAD BOLT SUPPORT TO SIDE MEMBER M18X1.5X200
23
SCREW SHOCK ABSORBER BRACKET TO BEARING BRACKET M18 X 1.5 X 200 MM
26
NUT RUBBER MOUNTING TO BRACKET
26
HEXAGON NUT BEARING BRACKET TO FRONT AXLE M18X1.5
110
TORSION BAR FRONT AXLE
113
BEARING
114
BEARING
116
SCREW. HEXAGON HEAD BOLT SUPPORT TO FRAME M14X1.5X40
116
HEXAGON HEAD BOLT BATTERY/APPARATUS SUPPORT TO FRAME SIDE MEMBER M14X1.5X40
119
NUT BATTERY/APPARATUS SUPPORT TO FRAME SIDE MEMBER
119
NUT SUPPORT TO FRAME
120
HEXAGON HEAD BOLT RESONATOR TO TRANSMISSION CASE,K 138633
122
BRACKET LEFT
122
BRACKET RIGHT
125
ROD , Replaced By: A6283201089
125
ROD , Replaced By: A6283201189
125
ROD FRONT AXLE,RIGHT
125
ROD FRONT AXLE,LEFT
128
NUT STEERING WHEEL TO STEERING COLUMN
131
BEARING HOUSING. HOUSING
134
RUBBER MOUNTING , Replaced By: A6283220050
134
BUSHING
137
HEXAGON HEAD BOLT. SCREW SUPPORT TO FRAME M14 X 1.5 X 65
137
HEXAGON HEAD BOLT SUPPORT TO FRAME M14X1.5X65
