Поз.
Артикул
Описание
5
PLASTIC PIPE AERATION, ORDER BY THE METER
5
PLASTIC PIPE. HOSE AERATION 6X8 MM, ORDER BY THE METER
8
FITTING (PARTS KIT),LINE RUPTURE
11
UNION NUT LINE CONNECTION
14
GLAND LINE CONNECTION
17
SLEEVE LINE CONNECTION
20
HOSE LEAK LINE, ORDER BY THE METER
23
SLEEVE LEAK LINE
26
BANJO UNION HOSE WIDTH, / I.D., 6/12 MM
26
BANJO UNION HEATING CONNECTION,K 169122
29
ELBOW FITTING HOSE WIDTH, 6 MM,TO M22
29
ELBOW FITTING , Replaced By: A0049905371
29
ELBOW FITTING HOSE WIDTH, 9 MM,TO M22
32
ELBOW FITTING COMPRESSED-AIR-LINE PLUG-CONNECTION
35
T-FITTING CONNECTION: 12, 10/20 FROM CHASSIS 4 270414,50/60 FROM CHASSIS 4 270290
41
CONNECTOR HOSE WIDTH, / I.D., 6 MM
44
SEALING CORD COMPRESSED-AIR-LINE PLUG-CONNECTION
50
CONNECTOR DISTRIBUTOR TO CAB
53
SEAL RING
59
T-FITTING HOSE WIDTH, 6 MM
62
CONNECTOR HOSE WIDTH, 6 MM, TO M22
62
CONNECTOR HOSE WIDTH, 6 MM,TO M16
62
CONNECTOR , Replaced By: A0029905478
65
ELBOW FITTING HOSE WIDTH, 8 MM, TO M 16
68
ELBOW FITTING HOSE WIDTH, 9 MM,TO M 22
71
LOCK RING LINE CONNECTION
71
SEAL RING , Replaced By: A0009940747
74
LOCK LINE CONNECTION
74
LOCK , Replaced By: A0009945448
77
REPAIR KIT COMPRESSED-AIR-LINE PLUG-CONNECTION TO M 16
77
REPAIR KIT , Replaced By: A0309971748
80
SCREW. UNION SCREW LINE CONNECTION
80
SCREW. UNION SCREW , Replaced By: A0009973734
