Поз.
Артикул
Описание
5
HOSE FROM RADIATOR TO THERMOSTAT
8
CLAMP , Replaced By: N000000000674
8
CLAMP HOSE 70-90X13 MM
11
HOSE FROM RADIATOR OUTLET TO WATER PUMP
11
HOSE FROM RADIATOR OUTLET TO WATER PUMP
14
PIPE ELBOW , Replaced By: A6555010756
14
PIPE ELBOW AT WATER PUMP,5 1935955 510517
14
PIPE ELBOW AT WATER PUMP,5 510518
15
PIPE ELBOW FOR SCREW FITTING
17
SCREW BRACKET TO FRAME SIDE MEMBER
18
PIN PIPE ELBOW TO BRACKET,K 023462
19
SPACER RING PIPE ELBOW TO BRACKET,K 023462
20
NUT , Replaced By: N910113010000
20
NUT STRAP TO BRACKET
23
HOSE FROM RADIATOR OUTLET TO WATER PUMP, ORDER BY THE METER
26
CLAMP , Replaced By: N000000000674
26
CLAMP HOSE 70-90X13 MM
29
CONNECTOR FOR SCREW FITTING
32
GASKET , Replaced By: A4422010480
32
GASKET CONNECTOR, Replaced By: A0002011080
32
GASKET CONNECTOR, Replaced By: A0002011180
32
GASKET CONNECTOR, Replaced By: A0002011280
32
GASKET CONNECTOR
35
SCREW END PIECE TO EXHAUST PIPE M 10X25
35
SCREW STRAP TO BRACKET
38
HOSE FROM WATER PUMP TO EXPANSION TANK AND TO HEATING PIPE
41
HOSE FROM WATER PUMP TO EXPANSION TANK AND TO HEATING PIPE
44
INTERMEDIATE PIECE FROM WATER PUMP TO EXPANSION TANK AND TO HEATING PIPE
47
SCREW BRACKET ON LOAD SENSOR
50
NUT , Replaced By: N913004006001
50
NUT PUMP TO BRACKET
53
HOSE , THE OLD PART MUST NO LONGER BE INSTALLED IN THIS PLACE, Replaced By: A6555013382
53
HOSE FROM WATER PUMP TO EXPANSION TANK AND TO HEATING PIPE
56
HOSE FROM WATER PUMP TO EXPANSION TANK AND TO HEATING PIPE
59
CLAMP , Replaced By: N000000000670
59
CLAMP
59
CLAMP , Replaced By: N000000000667
59
CLAMP HOSE TO SUCTION LINE AND TO OIL TANK 20-32X13 MM
62
BREATHER PIPE ENGINE BREATHING
68
GASKET. SEAL DE-AERATION PIPE TO ENGINE
71
SCREW END PIECE TO EXHAUST PIPE M 10X25
86
HOSE DE-AERATION PIPE TO EXPANSION TANK
95
CLAMP HOSE TO FITTING AND TO OIL TANK
95
CLAMP HOSE TO FITTING AND TO OIL TANK 16-27X13 MM
999
WASHER , Replaced By: A1894660751
