Поз.
Артикул
Описание
59
EXHAUST MUFFLER
62
CONSOLE EXHAUST MUFFLER TO SIDE MEMBER
62
CONSOLE EXHAUST MUFFLER,FRONT
65
CONSOLE REAR EXHAUST MUFFLER 200 MM
65
CONSOLE REAR EXHAUST MUFFLER 132 MM
71
SCREW DELIVERY AND SUCTION LINES TO FRAME M 12X35
71
SCREW , Replaced By: N308676012026
74
NUT SUPPORT TO SIDE MEMBER
77
BRACKET EXHAUST MUFFLER
80
BRACKET REAR EXHAUST MUFFLER
83
BRACKET STRAP TO FRONT CONSOLE
86
SCREW PROTECTIVE PLATE TO EXHAUST MUFFLER
89
NUT STRAP TO BRACKET
89
NUT , Replaced By: N910113010000
92
STRAP , Replaced By: A6204900042
92
STRAP EXHAUST MUFFLER TO BRACKET
95
SCREW PIPE ELBOW TO BRACKET M 10X50
95
SCREW STRAP TO BRACKET
95
SCREW , Replaced By: N304017010030
95
SCREW , Replaced By: N304017010053
96
WASHER , Replaced By: N000125010532
96
WASHER RADIATOR TO RUBBER MOUNTING
98
NUT , Replaced By: N910113010000
98
NUT STRAP TO BRACKET
101
SCREW EXHAUST MUFFLER TO STRAP
104
WASHER EXHAUST MUFFLER TO STRAP
104
WASHER , Replaced By: N000125008443
107
NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET, Replaced By: N910113008003
107
NUT , Replaced By: N913004008001
107
HEXAGON NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET
999
FLAP EXHAUST PIPE
999
SPACER TUBE EXHAUST PIPE TO PROTECTIVE PLATE
