Поз.
Артикул
Описание
8
REAR SPRING (PARABOLIC SPRING),NUMBER OF LEAVES: "3"
11
SHIM BETWEEN THE SPRING LEAVES, TO BE ADAPTED DURING ASSEMBLY
11
BUSHING SPRING EYE,REAR
11
BUSHING SPRING EYE,FRONT
14
SHIM , Replaced By: A9703210184
14
SHIM BETWEEN THE SPRING LEAVES, TO BE ADAPTED DURING ASSEMBLY
14
SHIM , Replaced By: A9703210184
17
SHIM BETWEEN THE SPRING LEAVES
23
RUBBER BUFFER BETWEEN THE SPRING EYES
26
SPRING BOLTM 12X90
29
HEXAGON NUT. NUT SPRING BOLT
29
NUT , Replaced By: N910113012005
35
SPRING CLAMP TO SPRING LEAF NO.4,5 484790
38
SPACER TUBE SPRING CLAMP
41
SCREW SPRING CLAMP,5 533057
47
NUT END PIECE TO EXHAUST PIPE
50
RIVET SPRING CLAMP TO SPRING LEAF
53
THRUST WASHER REAR SPRING TO REAR SPRING FRONT BRACKET
56
NUT INTERMEDIATE LEVER TO STEERING SUPPORT
56
NUT , Replaced By: N910113018004
59
SHACKLE SPRING SHACKLE TO SPRING REAR BRACKET
62
BUSHING REAR SPRING TO REAR SPRING REAR BRACKET
65
SCREW VIBRATION ABSORBER TO CONSOLE
68
NUT INTERMEDIATE LEVER TO STEERING SUPPORT
68
NUT , Replaced By: N910113018004
71
SHIM REAR SPRING
74
CENTERING BOLT (CENTERING CONE),5 361887
74
DOWEL PIN (CENTERING CONE),5 361887, Replaced By: A9303230574
77
PLATE REAR SPRING TO REAR AXLE
80
U-BOLT FRONT SPRING TO FRONT AXLE,FRONT 300MM
83
SPHERICAL WASHER FRONT SPRINGS TO FRONT AXLE,5 468450
86
NUT FRONT SPRINGS TO FRONT AXLE
89
BRACKET AXLE STOP
98
HELPER SPRING RUBBER BUFFER
101
PIN RUBBER BUFFER
104
SCREW BRACKET TO SIDE MEMBER
104
SCREW , Replaced By: N304017010002
119
NUT STRAP TO BRACKET
119
NUT , Replaced By: N910113010000
