Поз.
Артикул
Описание
23
PROTECTIVE PLATE FRONT EXHAUST PIPE, RECOMMENDED FOR TAKING ON STOCK
26
BRACKET FRONT EXHAUST PIPE, RECOMMENDED FOR TAKING ON STOCK
36
SCREW BRACKET TO APPARATUS SUPPORT M 10X30
38
CLAMP REAR EXHAUST PIPE TO MUFFLER
41
SCREW , Replaced By: N910143008014
41
HEXALOBULAR BOLT. SCREW FRONT EXHAUST PIPE TO BRACKET M 8X120
42
WASHER BRACKET TO CAB REAR PANEL
42
WASHER , Replaced By: N009021008213
42
WASHER BRACKET TO LEFT SIDE MEMBER
43
WASHER UNDERRUN PROTECTION AND BRACKET TO FRAME
43
WASHER , Replaced By: N006902011100
43
WASHER , Replaced By: N006902011102
44
NUT , Replaced By: N913023010002
44
NUT EXHAUST PIPE AND PIPE CLAMP TO BRACKET
45
NUT BRACKET TO BRACKET
47
FLEXIBLE METAL TUBE FRONT EXHAUST PIPE
53
CLAMP EXHAUST PIPE TO MUFFLER
56
CLAMP INTERMEDIATE PIPE TO PARTICLE FILTER
62
SCREW EXHAUST PIPE TO SIDE MEMBER
65
SCREW FLEXIBLE METAL TUBE TO EXHAUST PIPE AND TO EXHAUST MUFFLER
68
WASHER , Replaced By: N000125008443
68
WASHER EXHAUST MUFFLER TO STRAP
71
NUT BRACKET TO BRACKET
74
NUT EXHAUST PIPE AND PIPE CLAMP TO BRACKET
74
NUT , Replaced By: N913023010002
