Поз.
Артикул
Описание
5
PLASTIC PIPE RISING PIPE 4X6 MM
5
HOSE LEAK LINE 4X6 MM, ORDER BY THE METER
10
FITTING (PARTS KIT),LINE RUPTURE,5 909352K 169122
15
BANJO UNION HOSE WIDTH, / I.D., 4/12 MM
15
BANJO UNION HOSE WIDTH, / I.D., 4/12 MM
20
CONNECTOR COMPRESSED-AIR-LINE PLUG-CONNECTION
20
CONNECTOR , Replaced By: A0029905378
25
ELBOW FITTING COMPRESSED-AIR-LINE PLUG-CONNECTION TO M 16
27
CONNECTOR DISTRIBUTOR TO CAB
28
SCREW COVER PLATE TO COVER PLATE M 6 X 10
28
SCREW , Replaced By: N304017006034
30
CONNECTOR LINE MOUNTING
32
LOCK RING LINE CONNECTION
32
SEAL RING , Replaced By: A0009940747
35
LOCK , Replaced By: A0009945448
35
LOCK LINE CONNECTION
40
SCREW. UNION SCREW LINE CONNECTION
40
SCREW. UNION SCREW , Replaced By: A0009973734
45
SEAL RING COMPRESSED-AIR-LINE PLUG-CONNECTION
50
REPAIR KIT COMPRESSED-AIR-LINE PLUG-CONNECTION TO M 16
50
REPAIR KIT , Replaced By: A0309971748
55
LOOM TIE LINE MOUNTING 280 MM
60
VALVE (3/2-WAY SOLENOID VALVE)
65
SHEET METAL SCREW VALVE TO WINDOW SILL
70
HOLLOW SCREW HEATING CONNECTION
75
SEAL RING LINE CONNECTION
80
AIR HORN HIGH NOTE
80
AIR HORN LOW NOTE
80
AIR HORN , Replaced By: A0005422021
80
AIR HORN , Replaced By: A0005421921
80
AIR HORN , Replaced By: A0005422421
80
AIR HORN , Replaced By: A0005422521
80
AIR HORN , Replaced By: A0005423521
80
AIR HORN , Replaced By: A0005423621
80
AIR HORN , Replaced By: A0005424221
80
AIR HORN , Replaced By: A0005424321
85
DIAPHRAGMTO 000 542 19 21/20 21
88
BRACKET HIGH-GRADE STEEL TO 000 542 42 21/43 21
88
BRACKET CHROMIUM PLATED TO 000 542 24 21/25 21/35 21/36 21
92
CAPTO 000 542 19 21/20 21
95
COVERING (PARTS KIT),AIR HORN HIGH-GRADE STEEL TO 000 542 42 21/43 21
95
COVERING (PARTS KIT),AIR HORN,CHROMIUM PLATED TO 000 542 24 21/25 21/35 21/36 21
100
SHIM HORN TO CAB ROOF
100
SHIM HORN TO CAB ROOF
104
WASHER HORN TO CAB ROOF
107
WASHER COMPRESSED AIR LINE TO BRACKET
107
WASHER , Replaced By: N009021006208
110
SCREW , Replaced By: N304017006020
110
SCREW LICENSE PLATE TO BRACKET
115
NUT PUMP TO BRACKET
115
NUT , Replaced By: N913004006001
120
HOLLOW SCREW HEATING CONNECTION
125
SEAL RING LINE CONNECTION
999
SHIM
999
BRACKET
999
CONNECTOR COMPRESSED-AIR-LINE PLUG-CONNECTION
999
CONNECTOR COMPRESSED-AIR-LINE PLUG-CONNECTION
999
SEALING CORD COMPRESSED-AIR-LINE PLUG-CONNECTION
