Поз.
Артикул
Описание
5
EXHAUST PIPE CONNECTING PIPE TO EXHAUST MANIFOLD,5 3373435 528482
5
EXHAUST PIPE CONNECTING PIPE TO EXHAUST MANIFOLD,K 049384
5
EXHAUST PIPE CONNECTING PIPE TO EXHAUST MANIFOLD,5 528483K 049383
8
SCREW , Replaced By: N308676012015
8
SCREW LEFT AND RIGHT CONSOLES TO CAB
11
NUT THROTTLE HOUSING AND BRACKET TO FRONT EXHAUST PIPE
11
NUT , Replaced By: N910113012006
14
PROTECTIVE PLATE , FIRST EXHAUST STOCK OF OLD PARTS UP TO IDENT NO. 5 422640, Replaced By: A6764900730, +001A6764901140, +002A1089900340, +002N000933008147, +002N913004008004
14
PROTECTIVE PLATE FRONT EXHAUST PIPE,5 502998
17
BRACKET , Replaced By: A6764901140
23
SCREW EXHAUST PIPE TO BRACKET
26
WASHER PROTECTIVE PLATE TO BRACKET,5 502998
29
NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET, Replaced By: N910113008003
29
NUT , Replaced By: N913004008001
34
PROTECTIVE PLATE ,5 379080
36
BRACKET ,5 379080
38
SCREW , Replaced By: A0079900801
38
SCREW REDUCTION VALVE TO BRACKET
40
NUT , Replaced By: N913004008001
40
NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET, Replaced By: N910113008003
42
BRACKET EXHAUST PIPE BRACKET TO BELL HOUSING,5 343490
45
BRACKET FRONT EXHAUST PIPE TO BRACKET
46
SCREW BRACKET TO SIDE MEMBER
50
CLAMP , Replaced By: N071555090502
50
CLAMP INTERMEDIATE PIPE TO PARTICLE FILTER
52
SCREW , Replaced By: N304017010002
52
SCREW BRACKET TO SIDE MEMBER
54
NUT STRAP TO BRACKET
54
NUT , Replaced By: N910113010000
56
FLEXIBLE METAL TUBE FRONT EXHAUST PIPE TO MUFFLER,K 165446
59
CLAMP EXHAUST PIPE TO MUFFLER
61
CLAMP BRACKET TO EXHAUST PIPE
62
SCREW BRACKET TO EXHAUST PIPE,5 528482
62
SCREW BRACKET TO EXHAUST PIPE,5 528482
65
WASHER EXHAUST MUFFLER TO STRAP
65
WASHER EXHAUST MUFFLER TO STRAP
68
NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET, Replaced By: N910113008003
68
NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET, Replaced By: N910113008003
71
EXHAUST MUFFLER , Replaced By: A6764900501
71
EXHAUST MUFFLER
197
REAR EXHAUST PIPE ,5 743553-5 8000005 803730
197
REAR EXHAUST PIPE ,5 7435535 803730, Replaced By: A6764928004
197
REAR EXHAUST PIPE (TAIL PIPE)
203
CLAMP BRACKET TO EXHAUST PIPE
206
SCREW , Replaced By: N304014008021
206
HEXAGON HEAD BOLT. SCREW EXHAUST PIPE TO MUFFLER
209
WASHER , Replaced By: N000125008443
209
WASHER EXHAUST MUFFLER TO STRAP
212
NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET, Replaced By: N910113008003
212
NUT , Replaced By: N913004008001
215
BRACKET EXHAUST PIPE SUSPENSION,5 743553-5 8000005 803730
221
SCREW , Replaced By: N304017008034
221
SCREW BRACKET TO CROSS CONNECTION STRUT
224
WASHER SUPPORTING RAIL TO SUPPORT,5 429712
227
NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET, Replaced By: N910113008003
227
NUT , Replaced By: N913004008001
230
SUSPENSION PROTECTIVE PLATE TO EXHAUST PIPE
233
SCREWM 8X40
236
NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET, Replaced By: N910113008003
236
NUT , Replaced By: N913004008001
242
CLAMP INTERMEDIATE PIPE TO PARTICLE FILTER
242
CLAMP , Replaced By: N071555090502
248
SCREW BRACKET TO SIDE MEMBER
248
SCREW , Replaced By: N304017010002
254
NUT EXHAUST PIPE TO SIDE MEMBER
999
BRACKET AIR INTAKE PIPE,5 551665 TO BE ADAPTED DURING ASSEMBLY
999
RUBBER BUFFER EXHAUST PIPE REAR ON BATTERY CASE
999
BRACKET FUEL LINES TO TRANSMISSION
999
SUPPORT EXHAUST MUFFLER TO BRACKET
999
WASHER , Replaced By: N006902011100
999
BRACKET , EXHAUST STOCK OF OLD PART NUMBERS FIRST UP TO IDENT NO. K 139807, Replaced By: A6744924841
999
BRACKET EXHAUST PIPE REAR ON BATTERY CASE
999
BRACKET , Replaced By: A3524920141
999
BRACKET EXHAUST MUFFLER TO BRACKET
999
BRACKET HEAT SHIELD,5 502998
999
BRACKET BRACKET TO FILTER BRACKET
999
SCREW , Replaced By: N304017008021
999
WASHER , Replaced By: N006902011102
999
WASHER UNDERRUN PROTECTION AND BRACKET TO FRAME
999
SCREW PIPE CLAMP
