Поз.
Артикул
Описание
76
BRACKET DELIVERY AND SUCTION LINES TO ENGINE, FRONT
250
BRAKE CYLINDER , EXHAUST STOCK OF OLD PARTS NUMBER FIRST UP TO CHASSIS 4 847617, Replaced By: A0014317214
250
BRAKE CYLINDERBOSCH, MAKE BOSCH NO. 0 483 004 401 PART IS ONLY OR ALSO SUPPLIED AS RECONDITIONED PART
250
BRAKE CYLINDER , EXHAUST STOCK OF OLD PARTS NUMBER FIRST UP TO CHASSIS 4 8476174 373947, Replaced By: A0014317214
252
BRAKE CYLINDER , EXHAUST STOCK OF OLD PARTS UP TO CHASSIS 4 847617, Replaced By: A0014317514
254
PISTONTO 000 431 95 14,4 847617
258
SEAL RING , Replaced By: A0019975945
258
SEAL RINGWABCO
262
SEAL RINGTO 000 431 95 14,4 847617
266
PISTONTO 000 431 95 14,4 847617
270
SEAL RINGTO 000 431 95 14,4 847617
274
SEAL RINGTO 000 431 95 14,4 847617
278
SEAL RINGTO 000 431 95 14,4 847617
282
PISTONTO 000 439 95 14,4 847617
286
SEAL RINGTO 000 439 95 14,4 847617
290
GUIDE BUSHINGTO 000 431 69 14,BOSCH
294
PROTECTIVE CAPTO 000 431 69 14,BOSCH
298
SEAL RINGTO 000 439 95 14,4 847617
302
CUPBOSCH,5 7999995 800000 - 5 8127305 900000 - 5 936365
303
WHEEL BRAKE CYLINDER , WITH OFFSET BLEEDER CONNECTION WITH 8-MM,OR 10-MM,MOUNTING SCREWS EXHAUST STOCK OF OLD PARTS NUMBER FIRST UP TO CHASSIS 4 847617, Replaced By: A0044206818
306
REPAIR KIT , Replaced By: A0004302108
306
REPAIR KIT COMPRESSED AIR CYLINDER TO 000 431 95 14,001 431 32 14
306
REPAIR KIT COMPRESSED AIR CYLINDER TO 000 431 95 14,001 431 32 14
310
REPAIR KIT SLAVE CYLINDER TO 007 420 21 18,TEVES, 620.415 UP TO CHASSIS 5 014668 620.416 UP TO CHASSIS 5 000515 620.417 UP TO CHASSIS 4 972023
320
FITTING ,4 667210
320
ELBOW FITTING TRAILER CONTROL VALVE,CONNECTION: 1.1
323
NUT LOAD/NO-LOAD VALVE,CONNECTIONS: "10,20"
326
THRUST RING LOAD/NO-LOAD VALVE,CONNECTION: "20"
329
SEAL RING
329
SEAL RING LOAD/NO-LOAD VALVE,CONNECTION: "20"
330
HOLLOW SCREW FRONT AXLE REGULATING SOLENOID VALVE, CONNECTION: "10",K 009079
331
SEAL RING LOAD/NO-LOAD VALVE,CONNECTION: "20"
332
SCREW PLUG LOAD/NO-LOAD VALVE,CONNECTION: "22"
335
SEAL RING LOAD/NO-LOAD VALVE,CONNECTION: "20"
335
THRUST RING LOAD/NO-LOAD VALVE,CONNECTION: "20"
336
SEAL RING LOAD/NO-LOAD VALVE,CONNECTION: "20"
340
BRACKET ,4 373946
340
BRACKET , Replaced By: A3184313940
340
BRACKET BRAKE BOOSTER,4 373947
344
SCREW END PIECE TO EXHAUST PIPE M 10X25
350
SCREW CONSOLE TO SIDE MEMBER
353
NUT SUPPORT TO SIDE MEMBER
360
BRACKET (DOUBLE LEVER)
363
LEVER (DOUBLE LEVER)
367
NEEDLE BEARING , Replaced By: A0119813410
367
NEEDLE BEARING , Replaced By: A0119813410
367
NEEDLE BEARING
370
SEAL RING , Replaced By: A0069979147
370
SEAL RING , 385.068,069,FOR USE WITH MERCEDES-BENZ CAB
373
ROD , 385.068,069,FOR USE WITH MERCEDES-BENZ CAB
376
PIN PISTON ROD TO LEVER, 415 5 014668 416 5 000515 417 4 972023
379
WASHER , Replaced By: N000433010510
379
WASHER VIBRATION ABSORBER TO BRACKET
382
BUSHING , Replaced By: A3184310053
382
SPACER TUBE DOUBLE LEVER BEARING
385
SPRING , 385.068,069,FOR USE WITH MERCEDES-BENZ CAB
387
SCREW CLUTCH TO FLYWHEEL
388
NUT , Replaced By: N910113010000
388
NUT STRAP TO BRACKET
390
SCREW , Replaced By: N304017010002
390
SCREW BRACKET TO SIDE MEMBER
391
NUT BRACKET TO SUPPORT AND TO END PIECE
395
BRACKET BRAKE LEVER ASSEMBLY TO FIRE WALL,4 373946
400
SCREW PROTECTIVE PLATE TO EXHAUST MUFFLER
400
SCREW , Replaced By: N000966008031
400
SCREW FOLDING STEP TO REAR PANEL,546180
403
NUT , Replaced By: N910113010000
403
NUT STRAP TO BRACKET
403
NUT , Replaced By: N913004008001
403
NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET, Replaced By: N910113008003
406
SCREW PROTECTIVE PLATE TO EXHAUST MUFFLER
409
NUT , Replaced By: N910113010000
409
NUT STRAP TO BRACKET
415
PULL ROD FROM LEVER TO LINK
418
YOKE , Replaced By: A0009961501
418
YOKE PULL ROD TO LEVER
421
NUT BRACKET TO SUPPORT AND TO END PIECE
424
PIN PISTON ROD TO LEVER, 415 5 014668 416 5 000515 417 4 972023
427
WASHER , Replaced By: N000433010510
427
WASHER VIBRATION ABSORBER TO BRACKET
429
SPRING WASHER , Replaced By: N000137010205
429
SPRING WASHER SHIFTING ROD TO BRACKET
999
COTTER PIN STRAP TO CONSOLE 20 L
999
COTTER PIN CYLINDER TO BRACKET
999
WASHER COMPRESSED AIR LINE TO BRACKET, Replaced By: N000125006449
999
WASHER , Replaced By: N000125008443
999
WASHER EXHAUST MUFFLER TO STRAP
999
EXPANSION PLUG ,4 819869
999
SCREW , Replaced By: N000933006151
999
SCREW CONNECTOR
999
SCREW , Replaced By: N304014006005
999
SCREW COVER PLATE TO BRACKET
999
SCREW DISTRIBUTOR TO CAB
999
SCREW TEST CONNECTION TO BRACKET
999
SCREW , Replaced By: N304017008021
999
SCREW , Replaced By: N304017008034
999
SCREW , Replaced By: N304017008016
999
SCREW REAR EXHAUST PIPE TO MUFFLER
999
SCREW BRACKET TO SIDE MEMBER
999
NUT INTERMEDIATE SPEED STOP
999
GLAND LINE CONNECTION
999
SEAL RING , Replaced By: N007603010110
999
SEAL RING PNEUMATIC VALVE
999
SHEET METAL SCREW BOOT TO CAB FLOOR
999
SHEET METAL SCREW ,4 383114 ALSO INSTALLED ON 4 366280,4 366695,4 367047.
999
SCREW REFLECTOR TO BRACKET
999
SCREW , Replaced By: A0029903712
999
SCREW , Replaced By: N007985006580
999
SCREW , Replaced By: N000000001146
999
SCREW APPARATUS PLATE TO CAB,K 062140
999
SCREW PLATE TO VALVE M 6X70
999
SCREW , Replaced By: N304017006026
999
SCREW OIL-DIPSTICK GUIDE TUBE TO BRACKET
999
SCREW PIPE CLAMP
999
SCREW BRACKET TO CROSS CONNECTION STRUT
999
NUT PUMP TO BRACKET
999
NUT , Replaced By: N913004006001
999
UNION NUT LINE CONNECTION
999
UNION NUT LINE CONNECTION, Replaced By: N000000006239
999
PLUG ,4 383114 ALSO INSTALLED ON 4 366280,4 366695,4 367047.
999
BANJO UNION HOSE WIDTH, / I.D., 6/16 MM
999
BANJO UNION HEATING CONNECTION,K 169122
999
BANJO UNION HOSE WIDTH, / I.D., 8/22 MM
999
BANJO UNION FROM PRESSURE REGULATOR TO ANTI-FREEZE DEVICE,6 900001-6 900006
999
SLEEVE LINE CONNECTION
999
CLAMP ,K 147121, Replaced By: N000000000319
999
CLAMP , Replaced By: A0059970190
999
BEARING BRACKET BRAKE INTERMEDIATE SHAFT,4 819869
999
BRAKE INTERMEDIATE SHAFT ,4 819869
999
ANGLE , Replaced By: A4220980239
999
BRACKET LEFT,6028918 000001
999
BRACKET FLUID RESERVOIR,4 885755
999
CONSOLE , Replaced By: A3604301311, +001A3604300040
999
BRACKET ,4 282708 051,052,053,054,065,066,067,070,072 UP TO CHASSIS 4 383113,056,057,058,059,090,092 UP TO CHASSIS 4 373946 EXCEPT FOR 4 365508, 4 367796,4 368182,4 368578,4 368976,4 369331, Replaced By: A3184313940, +001A3184314040
999
BRACKET BRAKE BOOSTER,4 282708
999
BRACKET FLUID RESERVOIR,4 383114 ALSO INSTALLED ON 4 366280,4 366695,4 367047.
999
GUMMED LABEL INSTRUCTION FOR PARKING BRAKE VALVE
999
GUIDE SIGN LOAD-DEPENDING BRAKE
999
SEAL HOLDER
999
SEAL RING
999
LINE FROM TEST CONNECTION TO RIGHT WHEEL CYLINDER 650 MM
999
BRACKET , Replaced By: A3812950440
999
SPACER TUBE , Replaced By: A4082910153
999
REPAIR KIT , Replaced By: A3534200167
999
BALL CUP BRAKE INTERMEDIATE SHAFT BEARING
999
CLAMP , Replaced By: N916016008200
999
WASHER BRACKET TO LEFT SIDE MEMBER
999
WASHER , Replaced By: A3609902340
999
CLAMP , Replaced By: A3604300143
999
CLAMP DELIVERY AND SUCTION LINES TO ENGINE, TOP
999
BRACKET COMPRESSED AIR LINE TO FOUR-CIRCUIT PROTECTIVE VALVE,5 720506
999
ADHESIVE FOIL GUIDE SIGN
999
TUBE. BUSHING CAB FLOOR COVERING
999
SPACER TUBE
999
BRACKET , Replaced By: A4420981239
999
BRACKET , Replaced By: A4420981839
999
BRACKET COMPRESSED AIR LINES
999
SCREW CLAMP MOUNTING M 6X16
999
HEXALOBULAR BOLT WIRE CABLE TO BRACKET
999
GROMMET ,4 383114 ALSO INSTALLED ON 4 366280,4 366695,4 367047.
999
PROTECTIVE CAP , Replaced By: A0004210887
999
GROMMET BATTERY CASE
999
BRACKET , EXHAUST STOCK OF OLD PARTS NUMBER FIRST UP TO CHASSIS 4 493018, Replaced By: A3812950440
999
GASKET ,4 383114 ALSO INSTALLED ON 4 366280,4 366695,4 367047.
999
BRACKET , Replaced By: A3184280340
999
BRACKET , Replaced By: A3104280740
999
VALVE CLUTCH SLAVE CYLINDER
999
SPHERICAL PIECE , Replaced By: A3025860242
999
SEAL RING
999
HOSE LEVER TO SUPPORT
999
SEAL RINGTO 001 431 68 06,19.3X2.4 MM,GRAU37001, 620.415 UP TO CHASSIS 5 014668 620.416 UP TO CHASSIS 5 000515 620.417 UP TO CHASSIS 4 972023
999
SEAL RING , Replaced By: A0014313060
999
SEAL RING , Replaced By: A0014312960
999
SEAL RING 25.3X2.4 MM,TO 001 431 68 06, 002 431 02 06
999
SEAL RINGTO 000 429 28 95,GRAU
999
SEAL RING22.3X2.4 MM,GRAU
999
HOSE CLAMP LINE MOUNTING
999
FITTING , Replaced By: A0029906171
999
WHEEL BRAKE CYLINDER SLAVE CYLINDER, NOT FOR USE WITH MERCEDES-BENZ CAB
999
WHEEL BRAKE CYLINDER , WITH 8-MM,OR 10-MM,MOUNTING SCREWS, Replaced By: A0074202018
999
VALVE. REPAIR KIT HAND BRAKE LEVER TO 001 430 65 81
999
VALVE (RELAY VALVE) KNORR
999
VALVE (RELAY VALVE) BOSCH
999
FITTING BRAKE HOSE TO COMPRESSED AIR LINE
999
FITTING (PARTS KIT),LINE RUPTURE
999
SCREW , Replaced By: N000000001149
999
EDGE GUARD SECTION SEAT, Replaced By: A0019872272
999
REPAIR KIT BRAKE MASTER CYLINDER TO 003 430 81 01,TEVES,4 282708
999
REPAIR KITTO 001 431 12 06, KNORR 3200
999
REPAIR KIT COMPRESSED AIR CYLINDER TO 001 431 08 14,002 430 10 30
999
REPAIR KITTO BOSCH
999
REPAIR KITGRAU,5 148812
999
REPAIR KIT COMPRESSED AIR CYLINDER TO 000 431 68 14
999
REPAIR KIT , Replaced By: A0004301109
999
REPAIR KIT , Replaced By: A0004201071
999
REPAIR KIT SLAVE CYLINDER TO 006 420 15 18
999
REPAIR KITTO 000 431 13 16,4 2827084 383113 EXCEPT FOR 4 366280,4 366695,4 367047.
999
REPAIR KITKNORR
999
REPAIR KITTO 001 431 47 06,WABCO 2100, 620.415 UP TO CHASSIS 5 014668 620.416 UP TO CHASSIS 5 000515 620.417 UP TO CHASSIS 4 972023
999
REPAIR KIT BOOT TO 001 431 38 06,BOSCH, 620.415 UP TO CHASSIS 5 014668 620.416 UP TO CHASSIS 5 000515 620.417 UP TO CHASSIS 4 972023
