Поз.
Артикул
Описание
2
BATTERY , Replaced By: A0015417901
4
ELECTRIC CABLE , Replaced By: A6735460013
6
SOLDERING TERMINAL BATTERY POS. POLE 70 MM2
10
CABLE SHOE BATTERY CABLE 10-70 MM
12
NEG. CABLE FROM BATTERY TO CAB CROSS MEMBER
12
NEG. CABLE FROM BATTERY TO CAB REAR CROSS MEMBER
14
SCREW END PIECE TO EXHAUST PIPE M 10X25
16
WASHER , Replaced By: N009021010209
18
LOCK WASHER BRACKET TO SUPPORT AND TO END PIECE
21
NUT BRACKET TO SUPPORT AND TO END PIECE
24
GROUND STRAP , Replaced By: A3145400041
24
GROUND STRAP , Replaced By: A3525400041
24
GROUND STRAP FROM STARTING MOTOR TO SIDE MEMBER,5 193595
27
SCREW PROTECTIVE PLATE TO EXHAUST MUFFLER
30
LOCK WASHER BRACKET TO SUPPORT AND TO END PIECE
33
WASHER , Replaced By: N009021010209
36
SCREW END PIECE TO EXHAUST PIPE M 10X25
39
LOCK WASHER BRACKET TO SUPPORT AND TO END PIECE
42
WASHER , Replaced By: N009021010209
45
NUT BRACKET TO SUPPORT AND TO END PIECE
48
GROMMET , Replaced By: A3359970081
51
LOOM TIE LINE MOUNTING 280 MM
