Поз.
Артикул
Описание
5
HOSE BRAKE LINE COUPLING,"SUPPLY"
5
HOSE BRAKE LINE COUPLING,"BRAKE"
5
HOSE BRAKE LINE COUPLING,"BRAKE"
5
HOSE BRAKE LINE COUPLING,"SUPPLY"
5
HOSE BRAKE LINE COUPLING,"BRAKE"
5
HOSE BRAKE LINE COUPLING,"SUPPLY"
8
BRAKE LINE COUPLING LEFT
8
BRAKE LINE COUPLING SUPPLY, RED "KNORR"
8
BRAKE LINE COUPLING SUPPLY, RED "WABCO"
8
BRAKE LINE COUPLING BRAKE,YELLOW "WABCO"
12
BRACKET BRAKE LINE COUPLINGS
26
THRUST RING LOAD/NO-LOAD VALVE,CONNECTION: "20"
26
THRUST RING LOCKING VALVE TO TRAILER CONTROL VALVE,CONNECTION: "42"
26
THRUST RING LOCKING VALVE
29
SEAL RING LOAD/NO-LOAD VALVE,CONNECTION: "20"
32
REPAIR KIT SUPPLY, RED TO 000 429 86 30
35
ADAPTER FITTING AT BRAKE LINE COUPLING
38
INTERMEDIATE PIECE AT BRACKET
41
NUT LOAD/NO-LOAD VALVE,CONNECTIONS: "10,20"
44
SCREW. UNION SCREW LINE CONNECTION
47
TOOTHED WASHER AT BRAKE LINE COUPLING
56
VALVE AIR HORN 24 V PARKER
56
VALVE , Replaced By: A3869977336, +001A3454297736, +001A3509977472
56
VALVE , Replaced By: A3649977136, +001A3454297736, +001A3509977472
56
VALVE AIR HORN 24 V WABCO
57
SOLENOIDTO 386 997 73 36
58
REPAIR KITTO 388 997 88 36
59
HEXAGON HEAD BOLT. SCREW BATTERY MOUNTING M5X12
62
LOCK WASHER T-FITTING TO BRACKET
65
WASHER FUSE TO FUSE BOX
68
FITTING SOLENOID VALVE,CONNECTION: "2"
68
FITTING LINE CONNECTION
71
SCREW. UNION SCREW , Replaced By: A0009973734
74
SEAL RING , Replaced By: A0009940747
77
LOCK , Replaced By: A0009945448
80
SEALING CORD COMPRESSED-AIR-LINE PLUG-CONNECTION
83
THRUST RING LOAD/NO-LOAD VALVE,CONNECTION: "20",5 727400
83
THRUST RING , THE OLD PART MUST NO LONGER BE INSTALLED, Replaced By: A0009940103
86
CONNECTOR SOLENOID VALVE,CONNECTION: "2" TOA388 997 81 36 / 88 36
86
CONNECTOR SOLENOID VALVE,CONNECTION: "2"
89
AIR HORN
92
SCREW. HEXAGON HEAD BOLT SENDER UNIT TO BRACKET M5X25,V 214287
92
SCREW BRACKET MOUNTING
95
LOCK WASHER T-FITTING TO BRACKET
98
WASHER A. WASHER BRACKET TO LEFT SIDE MEMBER
98
WASHER FUSE TO FUSE BOX
101
NUT RELAY TO BRACKET M5
999
AIR HORN , Replaced By: A6965420121, +001N003861006007, +001N915017006100, +001N915062004000
