Поз.
Артикул
Описание
1
SUCTION TUBE WITH STUD BOLT
4
STUD BOLT FOR AIR FILTER MOUNTING
6
PIN IN SUPPORT
7
SCREWED NIPPLE. SCREW-IN FITTING FOR CONNECTION OF BOOSTER BRAKE TO INTAKE PIPE
8
PLUG REAR LID SUPPPORT, UP TO CHASSIS 014931 EXCEPT FOR SEE FOOTNOTE 10
10
EXHAUST MANIFOLD WITH HEATING FLAP AND TIGHTENING SPRING
11
BUCHSE. BUSHING
12
GROOVED PIN. DOWEL PIN
13
HALSKERBSTIFT. DOWEL PIN
15
HEATING FLAP. HOT-AIR DOOR
16
HEATING FLAP SHAFT. SHAFT
17
THERMO SPIRAL , 951 10/50 055536 951 12/52 031028 951 20/60 054223 951 22/62 030103 EXHAUST STOCK OF OLD PARTS UP TO ENGINE 938 10/50,20/60 061195 938 12/52,22/62 015693 939 10/50,20/60 009008 939 12/52,22/62 000458 954 10/50,20/60 073255 954 12/52,22/62 038921 THIS NOTE OF REPLACEMENT APPLIES ONLY TO THE ITEM LISTED OPPOSITE, Replaced By: A1151430010
18
BALANCING WEIGHT
20
SPANNFEDER FUR HEIZKLAPPENWELLE FUR HALTERUNG DER THERMOSPIRALE UND ANSCHLAG-DAMPFUNGSFEDER
21
DAMPING SPRING FOR HEATING FLAP
24
INSULATING FLANGE. GASKET , Replaced By: A1211420060
26
NUT
27
GASKET FOR SUCTION TUBE AND EXHAUST MANIFOLD AT CYLINDER HEAD
999
SUCTION TUBE WITH STUD BOLT, Replaced By: A1211401701
