Поз.
Артикул
Описание
3
BRACKET FENDER
3
BRACKET , Replaced By: A6575210140
6
SUPPORT (CONSOLE),FOR FENDER
6
BRACKET , FOR USE WITH SHORT MERCEDES-BENZ CAB, Replaced By: A6575200033
6
BRACKET , Replaced By: A6575210040
9
SCREW BRACKET TO CAB CONSOLE,K 035197
9
SCREW BRACKET TO CAB CONSOLE M14X1.5X40
9
SCREW BRACKET TO CAB CONSOLE M14X1.5X40
12
WASHER FENDER BRACKET TO SIDE MEMBER
15
NUT , Replaced By: N910113014001
15
NUT BRACKET TO SIDE MEMBER
18
SCREW BRACKET TO CROSS CONNECTION STRUT
18
SCREW BRACKET TO CROSS CONNECTION STRUT
18
SCREW , Replaced By: N304017008034
18
SCREW SUPPORT TO FENDER
18
SCREW , Replaced By: N304017008018
19
SCREW CLAMP TO BRACKET AND TO PIPE
19
SCREW CLAMP TO CONNECTING PIPE AND TO EXHAUST HOSE M 8X30
19
SCREW , Replaced By: N304017008027
20
LOCK WASHER CLAMP TO BRACKET AND TO PIPE
22
WASHER FENDER BRACKET TO FENDER
22
WASHER FENDER BRACKET TO FENDER, Replaced By: A0049902582
22
WASHER , Replaced By: A6312670276
24
HEXAGON NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET
24
HEXAGON NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET
24
NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET, Replaced By: N910113008003
24
NUT , Replaced By: N913004008001
25
SUPPORT TO FRONT FENDER STOP BUFFER BRACKET,5 101103 PARTS TO BEORDERED FROM SUPPLIER,MESSRS F X MEILLER,MUNICH
25
SUPPORT TO FRONT FENDER STOP BUFFER BRACKET,5 101103 PARTS TO BEORDERED FROM SUPPLIER,MESSRS F X MEILLER,MUNICH
27
BRACKET FENDER AND SHOCK ABSORBER,RIGHT
27
BRACKET LEFT FENDER
30
SCREW BRACKET TO SIDE MEMBER M 14X1.5X35
30
SCREW , Replaced By: N308676014020
30
SCREW BRACKET TO CAB CONSOLE M14X1.5X40
33
NUT BRACKET TO SIDE MEMBER
33
NUT , Replaced By: N910113014001
36
SCREW CLAMP TO BRACKET AND TO PIPE
36
SCREW CLAMP TO CONNECTING PIPE AND TO EXHAUST HOSE M 8X30
36
SCREW , Replaced By: N304017008027
37
BRACKET (STOP BUFFER),5 101103 PARTS TO BEORDERED FROM SUPPLIER,MESSRS F X MEILLER,MUNICH
52
COVERING , Replaced By: A3875200722
54
BRACKET COVER PLATE
56
SCREW CONSOLE TO SIDE MEMBER
56
SCREW CONSOLE TO SIDE MEMBER
58
SCREW DELIVERY AND SUCTION LINES TO FRAME M 12X40
59
SCREW LEFT AND RIGHT CONSOLES TO CAB
59
SCREW , Replaced By: N308676012015
60
WASHER
60
WASHER
61
WASHER MOUNTING USED FOR FRAME CONNECTION PARTS
61
WASHER , Replaced By: N007349013005
62
WASHER LEAF SPRING TO STRUT
64
NUT SUPPORT TO SIDE MEMBER
64
NUT SUPPORT TO SIDE MEMBER
64
NUT SUPPORT TO SIDE MEMBER
66
PIPE ELBOW OIL REFILLING
68
SCREW DELIVERY AND SUCTION LINES TO FRAME M 12X40
68
SCREW PROTECTIVE PLATE TO EXHAUST MUFFLER
70
NUT SUPPORT TO SIDE MEMBER
70
NUT STRAP TO BRACKET
72
CAP OIL REFILLING
72
CAP OIL REFILLING
72
CAP OIL REFILLING
74
GASKET
74
GASKET , Replaced By: A1020180380
74
GASKET , Replaced By: A1020180080
78
HOSE FROM OIL FILLER NECK TO OIL PAN
80
CLAMP SUCTION LINE TO OIL PUMP 40-60X13 MM
80
CLAMP , Replaced By: N000000000671
166
COVER ENGINE COVERING, FOR USE WITH SHORT MERCEDES-BENZ CAB
168
SHIM COVER PLATE TO CAB REAR PANEL, FOR USE WITH SHORT MERCEDES-BENZ CAB
170
SHEET METAL SCREW COVER PLATE TO CAB REAR PANEL
999
BUFFER
999
SCREW BEARING BRACKET TO SIDE MEMBER
999
NUT CONSOLE TO SUPPORT
999
NUT , Replaced By: N910113016001
